Technical specifications for FC-RUSLS-3224
-
Product ModelFC-RUSLS-3224
-
Product ParametersUniversal Safe Logic Solver
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size17.4x8.6x1.8cm
-
ManufacturerHoneywell
-
Weight0.12 kg
-
Operating temperature–40°C ... +70°C (–40°F ... +158°F)
-
Storage temperature–40°C ... +85°C (–40°F ... +185°F)
-
Relative humidity10 ... 95% (non condensing)
-
PollutionPollution degree 2 or better
-
ApprovalsCE, UL, TÜV
-
Supply voltage24 V DC -15% ... +30%
-
Supply currentmax 300mA (without field load)
-
Number of channels32
-
Channel typUniversal safe
-
Digital inmax. 32
-
ESD inmax. 1 (with line-monitoring)
-
Analog inmax. 32
-
Digital outmax. 32
-
Analog outmax. 16
Description
RUSLS-3224
32 channels, 24 V DC
Universal Safe Logic Solver
0-20mA or 4-20mA active
32 channels, 24 V DC
Universal Safe Logic Solver
0-20mA or 4-20mA active
Information
Overview
Manuals
Technical notes
Product Applications
Internal dissipation calculation
Features:
- Integrated Logic Processing and I/O
- Software-Configurable Universal I/O
- Redundant Safe-Loop Technology
- SIL 3 Certified Safety Performance
- HART Pass-Through Capability
- Advanced Line and Load Diagnostics
The RUSLS-3224 module is capable of logic solving. Logic solving by the module enables localizedsafeguarding of equipment under control (EUC). This is achieved by the execution of the application logic(FLDs) that is assigned to the module. for relevant details see the Software Reference Localized safeguarding offers distinct benefits. A major advantage is that logic solving by the RUSLS3224 module is unaffected when:l communication with Safety Manager is lost,l Safety Manager experiences a shutdown.
The FC-RUSLS-3224 Honeywell Universal Safe Logic Solver may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell FC-RUSLS-3224 Universal Safe Logic Solver Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The RUSLS-3224 module has one channel that can be configured as Emergency ShutDown (ESD) input;this is channel 32. To configure channel 32 as ESD input in Safety Builder, the two pins fork on the CN4terminals on the IOTA must be in the ENABLE position (connecting pins 1 and 2).Channel 32 must be configured for the ESD function in the software also, in order to execute the propertests for the ESD channel.
When the (field) switch on the ESD input opens, the Safety Manager universal IO watchdogs switch offand all digital outputs of the connected RUSLS-3224 module(s) will go off and remain off. There is nosoftware action required to do this; also there is no software action that can prevent this.See detail A of the below figure for a block diagram of this ESD input.See detail B of the below figure for the ESD input field connection.The ESD input is line monitored (for short circuit in the field wires).Place the (1kOhm) line termination resistor on (or near) the switch.
- Oil & Gas :ESD, flare monitoring & LNG anti-surge valve control
- Chemical & Petrochemical Processing:Reactor safety & hazardous substance handling to prevent failures
- Power Generation:Turbine overspeed, boiler interlocking & generator ESD
- Pharmaceutical & Life Sciences:GMP compliance: ventilation interlocking & reactor safety
- Pulp & Paper Industry:Safety interlocking for high-pressure systems & rotating equipment
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
To calculate the maximum outside module temperature, you need the configuration. The maximumdissipation caused by the logic of the RUSLS-3224 module is a fixed value. Other dissipation
contributions depend on the channel configuration. The maximum dissipation per channel type dependson the applicable supply voltage.Select the appropriate table to carry out the calculation, based on the supply voltage:
25 V or less: 25 V (default) - shown in the below table,
More than 25 V or unknown: 31.2 V (maximum) - shown in the below table.
FAQs
-
What is the FC-RUSLS-3224？
+The Honeywell FC-RUSLS-3224 is a Universal Safety Logic Solver module within the Safety Manager system -
What is the function of the FC-RUSLS-3224?
+It serves as a Remote Universal Safe Logic Solver, allowing safety logic to be executed locally or remotely with 32 configurable IO channels, acting as a remote safe controller. -
What safety rating does it have?
+The module is designed for safety-critical applications up to SIL 3. -
How does it improve flexibility?
+Each of its 32 channels can be independently configured via Safety Builder to act as Digital Input (DI), Digital Output (DO), Analog Input (AI), or Analog Output (AO), reducing the need for specific hardware spare parts. -
What is the difference between RUSLS-3224 and RUSIO-3224?
+Both are part of the Universal Safety IO family, but RUSLS (Logic Solver) provides local safety logic solving capability, while RUSIO is typically for remote safe IO.
