Modicon Quantum

PROFINET fieldbus module

Product or component type:Communication module
Product compatibility:Lexium 32M
Accessory / separate part destination:Servo drive
Number of addresses:256
Electrical connection:2 connectors RJ45
4 LEDs (green/red) for communication status

Servo motor

Range compatibility:PacDrive 3
Device short name:SH3.....P
Product or component type:Servo motor
Maximum mechanical speed:8000 rpm
rated supply voltage:115...480 V
Network number of phases:Three phase
Continuous stall torque:1.25 N.m at 115...480 V three phase
Continuous power:690 W
Maximum current Irms:5.7 A

Servo motor

Maximum mechanical speed 8000 rpm
 rated supply voltage 115...480 V
Continuous stall current 2.9 A
Continuous power 1130 W
Speed feedback resolution 128 periods
Torque constant 0.7 N.m/A at 120 °C
Back emf constant 48 V/krpm at 20 °C
Maximum axial force Fa 80 N

Servo motor

Device short name:BMH
Maximum mechanical speed:8000 rpm
Range compatibility:Lexium 32
rated supply voltage:240 V
Continuous stall current:5.55 A
Continuous power:1.68 W
Maximum permanent current:17.84 A
Holding torque:3 N.m holding brake
Torque constant:0.61 N.m/A at 120 °C
Back emf constant:39.3 V/krpm at 120 °C

Servo motor

Range Compatibility:PacDrive 3
Maximum mechanical speed:9000 rpm
Continuous stall current:0.73 A
Continuous power:290 W
Maximum current Irms:2.9 A
Speed feedback resolution:128 periods
Torque constant:0.58 N.m/A 248 °F (120 °C)
Back emf constant:40 V/krpm 68 °F (20 °C)

Servo motor

Range Compatibility PacDrive 3
Device short name SH3.....P
Maximum mechanical speed 8000 rpm
rated supply voltage 115...480 V
Continuous stall current 1.8 A
Continuous power 690 W
Maximum current Irms 5.7 A
Speed feedback resolution 128 periods

Servo motor

Range Compatibility PacDrive 3
Maximum mechanical speed 4000 rpm
rated supply voltage 115...480 V
Phase Three phase
Continuous stall current 7.8 A
Continuous power 2900 W
Maximum current Irms 20.8 A

Servo motor

Range Compatibility PacDrive 3
Maximum mechanical speed 6000 rpm
rated supply voltage 115...480 V
Phase Three phase
Continuous stall current 3.5 A
Continuous power 1190 W
Maximum current Irms 12 A

Quantum I/O

CPU Module

Profibus DP Master Module

CRP Ethernet Head Adapter

Topology:Daisy chain loop
Communication Port Protocol:
Ethernet IP/Modbus TCP
Number of port:4

Digital Input Module

RIO Networking Module

140CRP93200C
S908 DUAL-CHANNEL HEAD CC

Power Supply

Premium CPU

Communication Interface Module

Relay Output Module

Repeater Module w/Dual Port

Accessory

Accessory

Accessory

Accessory

Accessory

Accessory
