ALL MANUFACTURERS

REMOTE I/O Module

I/O MODULE
REMOTE
F3
20 DIGITAL INPUTS
CONFIGURABLE WITH LINE CONTROL
8 DIGITAL OUTPUTS
ADD. 2 PORT-SWITCH
100 BASE-TX
SAFE ETHERNET

Velomitor CT Velocity Transducer

02 Stud 3/8-in 24 to 1/2-in 20
00 MIL-C-5015 connection interface
04CSA/NRTL/C (Class I, Division 1)
ATEX/IECEx/CSA (Class I, Zone0/1)

3300 XL Proximitor Sensor

1 1.0 meter (3.3 feet) system length
51 5.0 meters (16.4 feet) system length
91 9.0 meters (29.5 feet) system length
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 60 mm
Minimum case length: 100 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe,
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 50 mm
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 11 mm Proximity Probes

330704   3300 XL 11 mm Probe
M14 x 1.5 thread,with armor
Minimum unthreaded length:0 mm
Minimum length:40 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 Multiple Approvals

990 Vibration Transmitter

05 0-5 mils pp (0-125 μm pp)
70 7.0 meters (23.0 feet)
03 DIN clips and screws
00 Not required

Universal Input-Output Module

Thermocouple
RTD
4-20 mA current input with HART option
5 V or 10 V input
0-20 mA current output with HART option
Digital inputs and outputs
Pulse accumulators

Controller Interface

10.4" TFT LCD (1024×768)
with resistive touch (glove-compatible)
Controller Interface Premium
Communication : Modbus
Data file Transfer(FTP)
USB, SD card

Controller Interface

15.6" TFT LCD (1920×1080)
with projected capacitive touch
Controller Interface Premium
Communication : Modbus
Data file Transfer(FTP)
USB, SD card

Controller Interface Premium

10.1" TFT LCD (1280×800)
with projected capacitive touch
Controller Interface Premium
Communication : Modbus
Data file Transfer(FTP)
USB, SD card

Controller Interface Premium

10.1" TFT LCD (1280×800)
with projected capacitive touch
Controller Interface Premium
Communication : Modbus
Data file Transfer(FTP)
USB, SD card

Controller Interface Premium

10.1" TFT LCD (1280×800)
with capacitive touch
Controller Interface Premium
Communication : Modbus
Data file Transfer(FTP)
USB, SD card

Operator interfaces

HCiRX Series
15.0” Color TFT LCD (65,536 colors)
Screen Size  15.0 ”
LCD Color TFT 16M Colors
Resolution 1024 x 768
Brightness 450 cd / m2
Touch Type Analog Resistive
Touch Cell  1024 x 768
CPU  32 bit RISC
Flash Memory 128MB

Operator interfaces

HCiRX Series
12.1” Color TFT LCD (65,536 colors)
Screen Size  12.1 ”
LCD Color TFT 16M Colors
Resolution 1024 x 768
Brightness  350 cd / m2
Touch Type Analog Resistive
Touch Cell  1024 x 768
CPU  32 bit RISC
Flash Memory 128MB

Operator interfaces

HCiRX Series
12.1” Color TFT LCD (65,536 colors)
Screen Size  12.1 ”
LCD Color TFT 16M Colors
Resolution 1024 x 768
Brightness  350 cd / m2
Touch Type Analog Resistive
Touch Cell  1024 x 768
CPU  32 bit RISC
Flash Memory 128MB

Operator interfaces

HCiRX Series
10.2” Wide Color TFT LCD (65,536 colors)
Screen Size  10.2 ” Wide
LCD Color TFT 16M Colors
Resolution 800 x 480
Brightness  350 cd / m2
Touch Type Analog Resistive
Touch Cell 800 x 480
CPU  32 bit RISC
Flash Memory 128MB

Operator interfaces

HCiRX Series
10.4” Color TFT LCD (65,536 colors)
Screen Size  10.4”
LCD Color TFT 16M Colors
Resolution 800 x 600
Brightness  400 cd / m2
Touch Type Analog Resistive
Touch Cell 800 x 600
CPU  32 bit RISC
Flash Memory 128MB

Operator interfaces

HCiRX Series
8.4” Color TFT LCD (65,535 colors)
Screen Size 8.4 ”
LCD Color TFT 16M Colors
Resolution 800 x 600
Brightness  350 cd / m2
Touch Type Analog Resistive
Touch Cell 800 x 600
CPU  32 bit RISC
Flash Memory 128MB

Operator interfaces

HCiRX Series
7” Wide Color TFT LCD (65,535 colors)
Screen Size 7.0” wide
LCD Color TFT 16M Colors
Resolution 800 x 480
Brightness 350 cd / m
Touch Type Analog Resistive
Touch Cell 800 x 480
CPU  32 bit RISC
Flash Memory 128MB

Operator interfaces

HCiRX Series
Screen Size 5”
5.” Wide Color TFT LCD (65,536 colors)
LCD Color TFT 16M Colors
Resolution 800 x 480
Brightness 350 cd / m
Touch Type Analog Resistive
Touch Cell 800 x 480
CPU  32 bit RISC
Flash Memory 128MB

Controller Interface

HCiRX Series
5.7” Color TFT LCD
Screen Size 5.6 ”
Resolution 640 x 480
LCD Color TFT 16M Colors
Brightness 450 cd / m2
Touch Type Analog Resistive
Touch Cell 640 x 480
CPU 32 bit RISC
Flash Memory 128MB

I/O Interface Module

ExpansionDrive
I/O Interface Module
Fiber Optic

I/O Interface Module, Fiber Optic

ExpansionDrive
I/O Interface Module
Fiber Optic

Ethernet Slave Adapter Module

Modbus TCP, EtherNet/IP Adapter
PROFINET Device
1500V AC
24V DC (18–36V) via backplane
±8kV contact / ±15kV air (IEC 61000-4-2)
