Control Board
Voltage Inputs:24 V DC
Power Consumption:5 W
Relay Outputs:8 A up to 250 V AC
Digital Inputs:24 V DC inputs
Operating Temp:-25°C to +70°C
Binary Control Module
Range: Typically 20.4 V DC
Series: 83SR Safety Relay System
Channel-to-Backplane/Logic: Yes
Isolation Voltage: Typically 250V AC
Safety Certification: TÜV Rheinland certified
83SR06E Binary and Analog Control Module
Overload (49):20-100% of In
Short Circuit (50):2-15×In
Phase Loss (46):Fixed/Adjustable
Ground Fault (51G):20-40% of In
Rated Current (In):6A (CT 5-100A)
Control Voltage:24-240V AC/DC
Contact Rating:5A @ 250V AC (resistive)
Communication:RS-485
Analog Output Module
Accuracy:±0.1% of span
Galvanic isolation:1500V AC channel
Range:4-20mA / 0-20mA
Resolution:16-bit
Load Capacity:≤750Ω
Update Rate:10ms per channel
Power Supply:24V DC ±10%
Power Consumption:5W (max)
Isolation Voltage:1500V AC
81EU01 Universal Input Module
81EU01 Input Module universal
16 fold for Binary and Analog Transmitters
ValueUnavailable
16 Channels
Analog Output Module
Range:4-20mA / 0-20mA
Resolution:16-bit
Accuracy:±0.05% of span
Load Capacity:≤750Ω
Update Rate:5ms per channel
Power Supply:24V DC ±10%
Isolation:1500V AC
Control Module
Channels:16
Voltage/Current:24V DC, 0.5A
Isolation:1500V AC
Response Time:<1ms
Power Supply:24V DC ±10%
Power Consumption:8W (typical)
Analog Output Module
Power Supply:24V DC ±10%
Power Consumption:4W (typical)
Isolation:1500V AC
Range:4-20mA / 0-20mA
Resolution:16-bit
Accuracy:±0.1% of span
Load Capacity:≤750Ω
Update Rate:10ms per channel
Control Board
Power Supply:24V DC ±10%
Analog Input:4-20mA / 0-10V
Digital Output:Relay, 5A @ 250V AC
Overcurrent:5-100A
Ground Fault;1-10A
Protocol: Modbus RTU (RS-485)
Baud Rate: 1200-19200 bps
Coupler Module
Application:Interfacing a computer
Transmission:Serial acc. to RS 232c
Transmission rate:300 - 19200 baud
Transmission distance, max.:20 m
Industrial Control Board
Processor:Dual-core PowerPC @ 800MHz
Memory:64MB Flash, 32MB RAM
Control Loops:Up to 128 PID loops
Ethernet: 2x 10/100BASE-T
Serial: 1x RS-485
Fieldbus: PROFIBUS DP
Digital Input:24V DC
Digital Output:Relay, 2A @ 30V DC
Analog Input:4-20mA/0-10V
Coupling Module
Power Supply:24V DC ±10%
Power Consumption:5W
Isolation:1500V AC
PROFIBUS Connector:9-pin D-sub
Protocol:PROFIBUS DP
Address Range:0-125
I/O Capacity:244 bytes input
Response Time:<1ms
Control I/O Module
Analog Input:4-20mA
Digital Input:24V DC, 3mA
Analog Accuracy:±0.1% of span
Digital Isolation:1500V AC
Update Rate:10ms (all channels)
Power Supply:24V DC ±10%
Power Consumption:8W (max)
Backplane Interface: S800 I/O bus
Analog Input Module
Power Supply:24V DC ±10%
Power Consumption:6W (max)
Isolation:1000V AC
Range:4-20mA
Resolution:16-bit
Accuracy:±0.05% of span
Input Impedance:250Ω
Update Rate:10ms/channel
Analog Input Module
Power Supply:24V DC ±10%
Power Consumption:8W (max)
Current:0-20mA/4-20mA
Voltage:0-10V/±10V
RTD:Pt100/Pt1000
Sampling Rate:50Hz/channel
Common Mode Rejection:>120dB @ 50/60Hz
Normal Mode Rejection:>60dB
Input Impedance:250Ω (current)
Coupling Module
Power Supply:24V DC ±10%
Power Consumption:5W (typical)
Isolation:1500V AC
Protocol:PROFIBUS DP
Data Rates:9.6kbps - 12Mbps
Address Range:0-125
Response Time:<1ms
Digital Output Module
Power Supply:24V DC ±10%
Power Consumption:4W (typical)
Isolation:500V AC (channel-to-channel)
Backplane Current:100mA (max)
Output Voltage:24V DC
Output Current:0.5A per channel
Switching Frequency:Up to 100Hz
Digital Output Module
Power Supply:24V DC ±10%
Power Consumption:5W (max)
Isolation:500V AC
Backplane Current:120mA (max)
Output Type:Solid-state
Output Voltage:24V DC
Output Current:0.5A per channel
Switching Frequency:Up to 100Hz
Leakage Current:<1mA
Binary Input Module
Power Supply:24V DC ±10%
Power Consumption:3W (typical)
Backplane Current:80mA (max)
Update Rate:10ms
Input Type:Sink/Source (configurable)
Input Voltage:12-60V DC
Threshold Voltage:8V DC (ON), 5V DC (OFF)
Input Current :3mA @ 24V DC
Response Time:<1ms
Isolation :1500V AC
Station bus coupling module
Power Supply:24V DC ±20%
Power Consumption:15W (typical)
Isolation:1500V AC
Data Rates:10/100 Mbps
Latency: <100μs
I/O Capacity:Up to 1024 signals
Universal Control Module
Memory:128MB Flash
Control Loops:Up to 64 PID loops
Scan Time:<1ms
Analog Input:4-20mA/0-10V
Digital Input:24V DC, 3mA
Analog Input Module
Power Supply:24V DC ±10%
Power Consumption:8W (max)
Sampling Rate:50Hz/channel
CMRR:>120dB @ 50/60Hz
NMRR:>60dB
Input Impedance:250Ω
Bus Coupling Module
Power Supply:24V DC ±10%
Power Consumption:5W (typical)
Isolation :1500V AC
Protocol :PROFIBUS DP
Data Rates:9.6kbps to 12Mbps
Temperature Input Module
Power Supply:24V DC
Power Consumption:3.5W (typical)
Isolation :500V AC
Channels:8
Input Resolution:16-bit
Accuracy:±0.1% of span (RTD)
Sampling Rate:10 samples/sec
Temperature Input Module
Power Supply:24V DC
Power Consumption:4W (max)
Isolation :500V AC
Input Impedance:>1MΩ
Channels:8
Resolution:24-bit ADC
Sampling Rate:10 samples/sec
Common Mode Rejection:>120dB @ 50/60Hz
mV Input:±50mV
