Procontrol P14

Control Board

Supply Voltage:24V DC (±10%)
Power Consumption:15W (typical)
Isolation:1500V AC (field-to-logic)
Processor:32-bit DSP
Cycle Time:25µs
Memory:64MB Flash

Control Module

Supply Voltage:24V DC (±10%)
Power Consumption:20W (max)
Isolation:1500V AC
Digital Inputs:24V DC
Analog Inputs:0-10V/4-20mA,
Processor:Dual-core 32-bit DSP
Control Cycle:25µs (torque control)
Memory:128MB Flash

Universal Input Module

Number of Channels: 8
Voltage: 0–10V
Current: 0–20mA, 4–20mA
Resolution: 16-bit
Sampling Rate: 10 samples/sec per channel
Common-Mode Rejection (CMRR): >120 dB @ 50/60 Hz
Voltage Mode: >1 MΩ
Current Mode: 250 Ω

Control Board

Clock Speed:150MHz (DSP), 100MHz (FPGA)
Memory:512kB Flash, 68kB SRAM
Operating Voltage:24V DC ±10%
Power Consumption:12W typical
Isolation:2500V AC
Control Loop Update: 62.5μs (speed)
Analog Inputs:2 ch (16-bit, ±10V/4-20mA)
Digital Inputs:6 ch (24V DC, 3ms filter)
Relay Outputs:3 ch (250V AC/5A)
PTC Input:2 ch (Motor temp sensors)

Control board

Input Voltage:24V DC (±10%)
Power Consumption;25W (typical)
Isolation :1500V AC (field to logic)
Vector control
Torque/speed regulation
PID controllers
Communication;Ports 2x Ethernet, 1x RS-485

88TK05 Station- Bus Coupler Module

Supply Voltage:24V DC (±15%)
Power Consumption:1.8W (typical)
Interface:9-pin D-Sub
Bus Termination:Integrated
Bus Protocol:PROFIBUS DP (EN 50170)
Transmission Rate:9.6Kbps to 12Mbps
Address Range:0-125
Max Number of Slaves:125
Electrical Isolation:500V AC

Analog Control Module

Operating Voltage:24V DC (±10%)
Power Consumption:6W (typical)
Input Channels:16 digital (24V)
Output Channels:8 relay (5A @ 230V AC)
Isolation Voltage:1500V AC (field to logic)
Processor:32-bit RISC
Clock Speed:100MHz
Memory:2MB Flash, 512KB RAM
Scan Time:1ms (typical)

81AB03E-E Output Module

Monitoring Module

Monitoring Module

89 NG 03 Power Supply

83SR05E Module

Control Module

89AR30 Relay Unit

89AR30 Relay Unit

Control Module

Control Module
