Modicon Premium

Voltage transformer

ABL6TS25U
voltage transformer
230..400 V
1 x 230 V
250 VA

POWER SUPPLY

POWER SUPPLY
PACDRIVE
10/16 AMP
220-240 VAC
48-62 HZ

Connecting cable

connecting cable
Modicon Premium - 5 m
for sub-base ABE7H16R20

Terminal Block Interface Module

Rated Voltage: 300V AC/DC
Rated Current: 8A per terminal
Contact Resistance: ≤ 5mΩ
Dielectric Strength: 2500V AC (50/60Hz, 1 min)
Insulation Resistance: ≥ 100MΩ (at 500V DC)

Safety dc discrete input module

Discrete input number:16
Group of channels:1
Logic input:Positive (sink)
Discrete input voltage:24 V DC
Voltage state 1 guaranteed:11...30 V DC
Voltage state 0 guaranteed:-3...5 V DC
Current state 1 guaranteed:>= 3 mA
Current state 0 guaranteed:<= 1.5 mA
Sensor power supply:19.2…30 V
Addressing requirement:7 input words
Input impedance:3675 Ohm
Absolute maximum input:30 V

Soft starter

Altistart 48
ATS48
Soft starter
Asynchronous motors
Heavy duty industry and pumps
230...415 V - 15...10 %

Double format PL7 processor

TSXP57303AM
PROCESSOR
PL7 DOUBLE-FORMAT
1000 MA
5 VDC
IP20

Double format PL7 processor

Current consumption:1110 mA 5 V DC
Module format:Double
Operating altitude:0...6561.68 ft (0...2000 m)
Protective treatment:TC
Analogue I/O processor:80 I/O
Discrete I/O processor:1024 I/O
Concept:Transparent Ready
Software Designation:PL7 Junior/Pro

Processor Module

Software designation:PL7 Junior/Pro
Number of racks:6 4/6/8 slots;8 12 slots
Discrete I/O processor:1024 I/O
Number of application specific channel:32
Current consumption：1360 mA at 5 V DC
Module format：Double
Operating altitude：0...2000 m

Processor Module

Input Voltage: 24 V DC
Input Range: 10–30 V DC
Number of Input Points: 32 points
Input Current: 3–5 mA per point
Isolation: 1500 V AC
Backplane Power: 5 V DC
Field Power: External 24 V DC supply for I/O
Input Delay: ≤ 1 ms

SRAM file memory extension

SRAM file memory extension
Memory extension
Memory type:SRAM
Memory capacity:4096 kB application
Slot:Slot 0 or 1

Printed circuit board

Input Power Voltage: 24V DC (±15%)
Power Consumption: <10W
Digital I/O: 24V DC logic levels for start/stop
Analog Inputs: 0–10V or 4–20mA
Temperature: -10°C to +50°C (derating above 40°C).
Humidity: <95% non-condensing (IEC 60721-3-3).
Vibration Resistance: ≤5.9 m/s²

CONTROL GATE TRIGGER BOARD

Isolation Voltage: ≥2500V AC
Gate Voltage: +15V/-8V typical
Peak Output Current: ≤10A
Auxiliary Voltage: 24V DC (±10%)
Temperature: -10°C to +50°C (derating above 40°C)
Humidity: <95% non-condensing

INVERTER CONTROL POWER BOARD

Voltage: 380–690V AC (±10%), 3-phase
Frequency: 50/60 Hz.
Nominal: 930V DC
Control Circuit Voltage: 24V DC (±15%)
Analog inputs :0–10V, 4–20mA
Temperature: -10°C to +50°C (derate 2% per °C above 40°C)
Humidity: <95% non-condensing

INVERTER CONTROL POWER BOARD

Rated Voltage: 3-phase AC 380–690V
Frequency: 50/60 Hz
Nominal: 930V DC
Temperature: -10°C to +50°C
Humidity: ≤95% non-condensing
Altitude: ≤1000m

Drive Board

Rated Voltage: 520–690V AC
DC Bus Voltage: ~900–950V DC
Frequency Range: 0–400 Hz
Operating Temperature: -10°C to +50°C
Storage Temperature: -40°C to +70°C.
Humidity: ≤95% non-condensing.
Vibration Resistance: ≤5.9 m/s²

Drive Board

Nominal Voltage: 690V AC (±10%)
Frequency: 50/60 Hz
Temperature: -10°C to +50°C (derating above 40°C).
Humidity: <95% non-condensing.
Altitude: <1000m without derating.
Signaling: I/O integration for drive control

Frequency converter 690V dedicated power board

Nominal Voltage: 690V AC (±10%)
Frequency: 50/60 Hz
Temperature: -10°C to +50°C (derating above 40°C).
Humidity: <95% non-condensing.
Altitude: <1000m without derating.
Signaling: I/O integration for drive control

Variable speed drive

Range of product:Easy Altivar 610
Product or component type:Variable speed drive
Device short name:ATV610
Variant:Standard version
type of cooling:Forced convection
Supply frequency:50...60 Hz +/-5 %
Network number of phases:3 phases
rated supply voltage:380...460 V - 15...10 %

Variable speed drive

Easy Altivar 610
Variable speed drive
Fan, pump, compressor, conveyor
ATV610
Standard version
Cabinet mount

Modbus Plus option adaptor

Communication port protocol:Modbus Plus
Communication port type:Single
rated supply voltage:5 V DC
Input voltage tolerance:+/- 5 %
Supply:Via I/O base
Clock drift+/- 13 s/day accuracy
Battery size2/3 AA

Backplane extension cable

Accessory:Connection accessories
Product compatibility
BMXXBE1000
To chain rack and transport local bus signal
2 male connectors SUB-D 9
0.8 m

VDC Logic I/O Module

I/O Type: 32-channel
Nominal: 24 VDC
Operating Range: 19.2–30 VDC
Field-to-Logic Isolation: 1500 VAC
Backplane Power: 120 mA @ 5 VDC (typical).
Field Power: 32 x 7 mA = ~224 mA @ 24 VDC (max).

Counter module

Counter modules
Modicon Premium
2 channels modularity
thermal tripping protection
4.5 to 6W, 40kHz

PROCESSOR MODULE

Double format PL7 processor,
Modicon Premium,
Internal RAM
48Kwords program & data
PL7 Junior/Pro
