Siemens Simatic S7

OPTICAL LINK MODULE

OPTICAL LINK MODULE
PROFIBUS OLM/G12-EEC V4.0
1 RS 485 AND 2 GLASS FIBER OPTIC CABLE INTERFACES
(4 BFOC SOCKETS)
FOR EXTENDED
TEMPERATURE RANGE -20 TO +60 DEG C

CPU MODULE

6ES73152EG100AB0
CPU MODULE
SIMATIC S7-300
CPU 315-2 PN/DP
WITH 128 KBYTE WORKING MEMORY
1. INTERFACE MPI/DP 12MBIT/S
2. INTERFACE ETHERNET PROFINET
MICRO MEMORY CARD NECESSARY

CPU MODULE

CPU MODULE
SIMATIC S7-300
313C-2 PTP
COMPACT
WITH MPI
16 DI/16 DO
3 HIGH-SPEED COUNTERS (30 KHZ)
INTEGRATED INTERFACE RS485
INTEGR. POWER SUPPLY 24 V DC
WORK MEMORY 128 KB

LINE REACTOR

LINE REACTOR
CHOCK
6SE SERIES
MICRMASTER 4
SINAMICS
2 HP RATED
1.5 KW
THREE-PHASE
380-480 VAC SUPPLY
47-63 HZ
IP20 ENCLOSURE

SMART REGULATED POWER SUPPLY

SIMATIC PM207/1AC/24VDC/5A
SIMATIC S7-200 smart
Regulated power supply
input: 100-240 V AC
output: 24V/5 A DC

CPU CONTROLER

CPU CONTROLER
SIMATIC S7-400
CPU 416-3
WORK MEMORY 3.2 MB
(1.6 MB CODE1.6 MB DATA)
1ST INTERFACE MPI/DP 12 MBIT/S
2ND INTERFACE PROFIBUS DP
3RD INTERFACE FOR IFM

CENTRAL PROCESSING UNIT

CPU
SIMATIC S7-400
417-4 CENTRAL PROCESSING UNIT
WORK MEMORY 30 MB / 15 MB CODE-15 MB DATA
1ST INTERFACE MPI 12 MBIT/S
2ND INTERFACE PROFIBUS DP
3RD/4TH INTERFACE PLUG-IN IFM MODULE

CPU 414-3 Centralprocessing unit

SIMATIC S7-400
CPU 414-3 Centralprocessing unit
with: work memory 2.8 MB, (1.4 MB code, 1.4 MB data)
1stinterface MPI/DP 12 Mbit/s
2nd interface PROFIBUS DP
3rd interfaceplug-in IFM module

CPU551 64-bit processor module

SIMATIC TDC
CPU551 64-bit processor module
with digital inputs

Electronic module

SIMATIC DP
Electronic modules for ET 200
PRO 8 DO 24 V DC,
0.5 A Modulediagnostics;
incl. bus module,
Connection module

PROFIBUS DP SLAVE MODULE

SIMATIC DP,5
ELECTRON. MODULES FOR ET 200S
2 DO RELAY 24V DC - 230V AC/5A
15 MM WIDTH FIRSTUP SIGNAL
WITH LED SF (GROUP FAULT)
5 PIECES PER PACKAGING UNIT

PROFINET interface module

SIMATIC ET 200AL
PROFINET interface module
IM 157-1 PN
Degree ofprotection IP67

Electronic modules

SIMATIC DP
Electronic modules
for ET 200 PRO 8 DO 24 V DC
0.5 A Modulediagnostics
incl. bus module
Connection module
IO 6ES7194-4..00-0AA0 orderseparately

Digital output module

SIMATIC DP
ET 200ECO PN
16 DO 24 V DC/1.3 A; 8xM12
duplicateassignment
Degree of protection IP67

TERMINAL BLOCK

SIMATIC DP
TB32L TERMINAL BLOCK
32CHANNELS FOR ET 200L
SCREW-TYPE TERMINAL

MICRO MEMORY CARD

SIMATIC S7
MICRO MEMORY CARD
FOR S7-300/C7/ET 200
3.3V NFLASH
64 KB

DIGITAL INPUT MODULE

DIGITAL INPUT MODULE
SIMATIC S7-300
24 VDC
20 PIN
OPTICALLY ISOLATED
16DI
REPLACED BY: 6ES7321-1BH02-0AA0

INTERFACE MODULE

INTERFACE MODULE
S7-1200 SERIES
10 MA
24 VDC
WITH DIAGNOSIS
PM-E FOR ET 200S
SIMATIC DP

POWER MODULE

POWER MODULE
SIMATIC DP
PM-E F PROFISAFE
24 VDC
SUITABLE FOR UNGROUNDED SETUP RELAY
FOR SWITCHING THE VOLTAGE BUSES P1
AND P2 UP TO CATEGORY 3 (EN 954-1)
SIL2 (IEC61508)/PLD (ISO13849)
2 FAIL-SAFE DIG. OUTPUTS UP TO CATEGORY 4
Isolation tested with 500 V DC

POWER MODULE

SIMATIC DP
POWER MODULE
PM-E F
PROFISAFE
24VDC

ELECTRONIC MODULE

ELECTRONIC MODULE
SIMATIC DP
FOR ET200S
2 POINT
ANALOG CURRENT
15MM WIDTH
13 BIT + SIGN
4-20 MA
SUCCESSOR: 6ES7135-4GB01-0AB0

Digital electronic module

Digital electronic module with four outputs
Output current 2 A per output
Rated load voltage 24 VDC
Short-circuit protection
Suitable for solenoid valves
DC contactors, and indicator lights
Extended temperature range
from 0 to 55° C with vertical installation

Electronics module

SIMATIC DP
ELECTRONIC MODULE FOR ET200S
2 AI STAND. I-4DMU 15 MM WIDE
+/-20MA; 13 BIT +SIGN,4 .. 20MA
12 BIT FOR 4-WIRE TRANSDUCER
CYCLE TIME65 MS/CHANNEL
WITH LED SF (GROUP FAULT)

Electronics module

SIMATIC DP
Electronics module for ET 200S
2 AI TC standard
15 mm width
15 bit+sign +/-80 mV
Characteristic linearization for
thermocouples of the types: B, E, J, K, L, N, R, S, T Cycle
time 65 ms/channel
with SF LED (group fault)

Electronics module

SIMATIC DP
ELECTRONIC MODULE FOR ET200S
2 AI TC 15 MM WIDE
15 BIT + SIGN +/-80MV
CHARACTERISTICS LINEARIZATION FOR
THERMOELEMENTSOF: B, E, J, K, L, N, R, S, T TYPES
CYCLE TIME 65 MS/CHANNEL
WITH LED SF (GROUP FAULT)
