Siemens Simatic S7

TOUCH PANEL

6AV78120BB201AA0
OPERATOR INTERFACE
PC877 15INCH
115/230VAC 2.8GHZ

CENTRAL PROCESSING UNIT

6ES73183FL000AB0
CENTRAL PROCESSING UNIT
SIMATIC S7-300 CPU319F-3 PN/DP
W/ 1400 KB WORK MEMORY
1ST INTERFACE MPI/DP 12 MBIT/S
2ND INTERFACE DP MASTER/SLAVE 3RD
INTERFACE ETHERNET PROFINET
SUCCESSOR: 6ES7318-3FL01-0AB0

Membrane Keyboard

COMPACT MODULE
SIMATIC HMI C7-633 Membrane Keyboard
SIMATIC C7-633/P
WITH INTEGRATED COMPONENTS S7-300 CPU 315
OP7
IM360 16DI
16DO
4AI
4AO

Touch Panel

SIMATIC HMI IPC677C
Touch Panel
2x10/100/1000 Mbit/s Ethernet
4 x USB V2.0
1x serial (COM1)

Power Rail

6ES79724AA020XA0
POWER RAIL BOOSTER
SIMATIC DP
SIGNAL AMPLIFIER FOR
THE TRANSFER OF THE PROFIBUS DP
VIA SLIDING CONTACTS
MAX 500 KBIT/S

Synchronization module

6ES79601CB000AA5
S7 SYNC-MODULE FOR S7-1500H
AUTOMATION - SIMATIC S71500 CPU
PLC AND IPC

COMUNICATION MODULE

6GK75425DX000XE0
COMUNICATION MODULE
FOR CONNECTION OF S7-1500 TO PROFIBUS DP
DPV1 MASTER OR DP SLAVE
S7 AND PG/OP COMMUNICATION
DATA RECORD ROUTING
TIME-OF-DAY SYNCHRONIZATION
DIAGNOSTIC
IP20
SUCCESSOR: 6GK7542-5DX10-0XE0

BusAdapter

SIMATIC ET 200SP

BusAdapter BA 2xFC

2x FastConnect connections

FOR USE WITH PROFINET

Multi-fieldbus interface module

6ES71555MU000CN0
ET 200MP. IM 155-5 MF HF
AUTO SMTIC S71500 INPUT/OUTPUT MOD
IO AND SAFETY

Central processing unit

6ES75173HP000AB0
SIMATIC S7-1500H
CPU 1517H-3 PN
CENTRAL PROCESSING UNIT
WITH 2 MB WORK MEMORY
FOR PROGRAM AND 8 MB FOR DATA
1ST INTERFACE: PROFINET RT WITH 2-PORT SWITCH
2ND INTERFACE: PROFINET
3RD/4TH INTERFACE: H-SYNC
SIMATIC MEMORY CARD REQUIRED

INTERFACE-MODULE

INTERFACE-MODULE
UP TO 12 I/O MODULES
W/O ADDITIONAL PS
UP TO 30 I/O MODULES W/ PS

DIGITAL INPUT MODULE

SIMATIC S7-1500
Digital input module DI 32x24 V DC HF
32 channels in groupsof 16
of which 2 inputs as counters can be used
input delay 0.05..20 ms inputtype 3 (IEC 61131)
diagnostics; hardware interrupts
front connector (screwterminals or push-in)
to be ordered separately

DIGITAL INPUT MODULE

DIGITAL INPUT MODULE
SIMATIC S7-1500
DIGITAL INPUT 32 X 24 VDC BA
32 CHANNELS (IN GROUPS OF 16)
INPUT DELAY TYPE 3.2MS
INPUT TYPE 3 (IEC 61131)
FRONT CONNECTOR
PUSH-IN

System Screen

Simatic IPC677D
6AV7260-5GA10-0BX0
2x10/100/1000 Mbit/s Ethernet

INDUSTRIAL COMPUTER

6ES76477BA202XM0
INDUSTRIAL COMPUTER
MICROBOX PC
SIMATIC IPC427
CELERON M 1.2 GHZ
800 MHZ FSB
1MBYTE SLC MEMORY
1 GB DDR3

DIGITAL ELECTRONIC MODULE

6ES71330BN010XB0
ELECTRONIC MODULE DIGITAL
0.5 AMP
24 VDC
24 DIGITAL INPUTS
8 DIGITAL OUTPUTS
3 MS INPUT DELAY

Simatic IPC627C Box PC

6ES76476CH300AB0
BOX PC
SIMATIC IPC627C
HD GRAPHIC ONBOARD
X2 10/100/1000 MBIT/S ETHERNET RJ45
X4 USB V2.0 HIGH CURRENT
X1 SERIAL COM 1
RAID CONTROLLER ONBOARD
WATCHDOG
PRODUCT WAS DELETED WITHOUT REPLACEMENT

INTERFACE MODULE

6ES71511BA000AB0
INTERFACE MODULE IM15-1
SIMATIC DP
HIGH FEATURE F. ET200S
TRANSMISS. RATE UP TO 12MBIT/S
DATA VOLUMEN 244 BYTE FOR I/O
MAX. 63 MODULES CONNECTABLE: ISOCHRONE MODE

ANALOGUE OUTPUT MODULE

6ES71354MB010AB0
OUTPUT MODULE
ANALOGUE
2AO
SIMATIC ET 200S
SIMATIC S7

POWER MODULE

POWER MODULE
SIMATIC DP
FOR ET200S
24-48 VDC
24-230 VAC
DIAGNOSTICS AND BACKUP
SUCCESSOR: 6ES7138-4CB11-0AB0

Expansion Card

6ES76532CE000XB0
(PRICE/PC) PCS 7 SYSTEM
EXPANSION CARD PO 1000
PROCESS AUTOMATION - PCS 7 410-5H

CPU MODULE

COMPACT CPU
SIMATIC S7-300
CPU 314C-2 PTP
24V DC
64 KB
24 DIGITAL INPUT
16 DIGITAL OUTPUT
4 ANALOG INPUT
2 ANALOG OUTPUT
4 FAST COUNTERS 60 HZ

MOBILE RADIO MODEM

MOBILE RADIO MODEM
SINAUT MD720-3 GSM/GPRS
RS-232 INTERFACE

DIGITAL INPUT MODULE

6ES72211BF220XA8
DIGITAL INPUT
8 INPUT
24VDC

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
CPU 317F-2 DP
SIMATIC S7-300
1.5 MB WORKING MEMORY
1ST INTERFACE MPI/DP 12 MBIT/S
2ND INTERFACE DP MASTER/SLAVE
SUCCESSOR TO 6ES7317-6FF03-0AB0
