Allen-Bradley CompactLogix

CompactLogix 5370 L1 controller

Ethernet nodes:8 Nodes
No. of Task:32 Task
No. of Program per Task:100
No. of Embedded Inputs:(16) 24 VDC
Module Type:Processor Module
Communication:Ethernet
Input Power:24 Volts DC
Memory:512KB
Communication Cable:6 Point
Shipping Weight:3 pounds

Compact GuardLogix Controller

Application Memory:4 MB
Safety Memory:2 MB
Non-volatile memory:2GB via 1784-SD2
Local I/O modules:31 I/O modules
Communication Ports:1 Type B 2.0
Full-Speed USB and 2 Ethernet/IP Ports
Communication rate, Ethernet:10 Mbps / 100 Mbps / 1 Gbps
User Memory:4 MB + 2 MB safety
Ports:2 Ethernet

Flex I/O Pulse counter module

ON state Voltage, min:6VDC
ON state Voltage, max.26.4VDC
ON state Voltage, nom:24VDC
Enclosure:Open-type
Operating Temperature:0 to 55 C (32 to 131 F)
Storage Temperature:-40 to 85 C (-40 to 185 F)
Vibration: 5g @ 10 to 500 Hz
Operating Shock:30 g
Product Type:Flex I/O 4 Channel Pulse Counter Module
Inputs:2 per Interface
Pulse Counter Interfaces:4

FLEX I/O module

Part Number:1794-IF8IH
Outputs:None
Inputs:8
Input type:single-ended, non-isolated
Operating temperature:32 to 131 degrees Fahrenheit
Enclosure:Open
Conversion:Sigma Delta
Dimensions:3.7 x 3.7 x 2.6 inches
External DC voltage rating:19.2 to 31.2 Volts DC

Compact 5000 Discrete high-current output module

Series:Compact 5000 I/O
No. of Outputs Eight (8) DC output channels
Output Voltage signal, nominal:24VDC
Output Voltage Signal range:10-32VDC
Pulse width, min:200 µs @ 0.5 A @ 25 °C (77 °F)
No. of output groups:Two (2)
Number of Outputs:8 (2 Groups of 4) Channels
Voltage Category:24 Volts DC
Input Voltage Range:N/A
Output Voltage Range:10-32 Volts DC
Power Dissipation:3.2 Watts

Compact 5000 Ethernet I/P communication module

Series:Compact 5000 Ethernet I/P Adapter
No. of Ethernet ports:Two (2)
Ethernet topologies Linear and Ring
Transmission Rate:10 Mbps / 100 Mbps / 1Gbps
Protected Mode:Not supported
Implicit Mode:Supported
Operating Temperature:0-60 Degree Celsius
Maximum surrounding temperature:60 Deg. Celsius

CompactLogix packaged controller

Product Type:Programmable Automation Controller
Module Type:Processor Module
Communication:Ethernet
Communication ports:(1) USB; (2) Ethernet I/P; 1 RS232
Supported Protocols:ASCII; DH485; DF1; Ethernet
No. Of Axes over Ethernet:2 axes
Shipping Weight:3 pounds
No. of Task:32 Task
Shipping Dimensions:11X8X6 inches
No. of Program per Task:100
Series:A and B

CompactLogix packaged controlle

Product Line:CompactLogix
Product Type:Programmable Automation Controller
Module Type:Processor Module
Communication:Ethernet
Communication ports:2 Ethernet I/P; 1 USB
Motion Control over Ethernet I/P:Included
Integrated Motion:4 Axes
Memory:1MB
Shipping Weight:3 lbs.
Maximum number of I/O modules supported: 8 Modules

CompactLogix Processor Module

Product Type: Controller
Module Type:Processor Module
Integrated Memory: 3MB
Shipping Weight:2 pounds
Communication ports:One (1) RS232
Shipping Dimensions:8x8x5 inches
Series:A and B

GuardLogix 5580 Safety Controller

User memory:10 megabytes
Safety memory:5 megabytes
Digital I/O / Analog I/O:128,000 / 4000 max
Ethernet performance:10/100/1000 megabits per second
Current draw at 1.2 Volts DC:5.0 milli Amps
Current draw at 5.1 Volts DC:1.2 Amps

AC Servo Controller

Product Type AC Servo Controller
Nominal Bus Output Voltage 300V DC
Continuous Current(RMS) 45A
Peak Current(RMS) 90A
Continuous Power Output 15 KW
Peak Power Output 30 KW
Input Circuit Breaker Rating 38A RMS
Circuit Breaker Interrupt Rating 1300A
Static Gain 1.5x Rated Motor I/RPM

Programmable Automation Controller

10/100/1Gbps
0.6 MB Standard
1000 per task
32 Tasks
16 Ethernet/IP Nodes
Device Level Ring, Star, and Linear

Programmable Automation Controller

1 Megabytes
0.5 MB
2GB via 1784-SD2
31 Standard tasks; 1 Safety Task
8 I/O modules
10 Mbps / 100 Mbps / 1 Gbps
12 Mbps
256 Motion Axes

Programmable Automation Controller

16 Ethernet/IP Nodes
0.6 Megabytes
2GB via 1784-SD2 (ships with the controller)
8 I/O modules
10 Mbps / 100 Mbps / 1 Gbps
12 Mbps
256 Motion Axes
2 Motion Axes

Programmable Automation Controller

2 Megabytes
2 GB via 1784-SD2 (ships with the controller)
16 I/O modules
10 Mbps / 100 Mbps / 1 Gbps
12 Mbps
40 Ethernet/IP Nodes
16 I/O

Programmable Automation Controller

4 Megabytes
2 GB via 1784-SD2 (ships with the controller)
Device Level Ring, Star, and Linear
31 I/O modules
10 Mbps / 100 Mbps / 1 Gbps
Process Module

Programmable Automation Controller

Controller Tasks 32
Programs/task 1000
User Memory 2 MB
Ports 2 Ethernet
Port 1 USB
Network Nodes 40

Programmable Automation Controller

3 Megabytes
2 GB via 1784-SD2 (ships with the controller)
31 I/O modules
10 Mbps / 100 Mbps / 1 Gbps
12 Mbps
50 Ethernet/IP Nodes
31 I/O

Motion control

4 Megabytes
2 GB via 1784-SD2 (ships with the controller)
10 Mbps / 100 Mbps / 1 Gbps
31 I/O modules
12 Mbps
20 Motion Axes
55 Ethernet/IP Nodes

Programmable Automation Controller

180 Ethernet/IP Nodes
10 Megabytes
2GB via 1784-SD2 (ships with the controller)
8 I/O modules
10 Mbps / 100 Mbps / 1 Gbps
256 Motion Axes
31 I/O
32 Motion Axes

Safety Controller

10 Megabytes
2GB via 1784-SD2 (ships with the controller)
31 Standard tasks; 1 Safety Task
31 I/O modules
10 Mbps / 100 Mbps / 1 Gbps
256 Motion Axes
10 MB + 5 MB safety

Safety Controller

10 Megabytes
2GB via 1784-SD2 (ships with the controller)
31 Standard tasks; 1 Safety Task
31 I/O modules
10 Mbps / 100 Mbps / 1 Gbps
12 Mbps
256 Motion Axes
32 to 140 degrees Fahrenheit
-40 to 185 degrees Fahrenheit

CompactLogix 5370 L1 Ethernet Processor Module

Product Family:5370 L1
Product Type:CompactLogix Controller
Communication ports:(1) USB; (2) Ethernet I/P
Ethernet topologies:Linear, Star and Device level Ring (DLR)
Ethernet nodes:8 Nodes
Maximum number of I/O modules supported: 8 Modules - Point I/O
No. of Task:32 Task
No. of Program per Task:100
No. of Embedded Inputs:(16) 24 VDC
Mounting:DIN Rail
Current draw @ 5V DC:1A
Integrated Motion:Supported
Motion Axes:1 or 2

Output Module

CompactBlock I/O Module
