CONTROL UNIT
RDCU12C
CONTROL UNIT
DRIVE CONTROL ASSEMBLY
SCREW CLAMP TERMINALS
WITH COMMS ADAPTER PORT
(3AUA0000036521)
Frequency Converter
ACF601025500R1200000
Frequency Converter
U1: 3~, 380...500V
U2: 3~, 0-380...500V
Insq: 41A, f1: 48...63Hz
f2: 0...300Hz
Frequency Converter
ACN6340040500000300902
Frequency Converter
U2: 0...U1V
I2n: 47A
f2: 0...300Hz.
ACS550-01-023A-4 3AUA0000002417-D
ACS550-01-023A-4
3AUA0000002417-D
3-phase
47.5 ... 63 Hz
23A,380V,IP21
Variable Speed/Frequency Drive
LV AC industrial wall-mounted single drive
Variable Speed/Frequency Drive
IEC: Pn 90 kW, 156 A, 500 V,
UL: Pld 125 Hp, 156 A, 460 V
(ACS880-01-156A-5)
Standard I/O and Modbus module
BMIO01
(3AXD50000021262)
COMMUNICATION MODULE
STANDARD I/O AND MODBUS
FOR ACS380 VARIABLE FREQUENCY DRIVES
Combined overcurrentand earth-fault relay
Protection Functions:3-Phase Overcurrent (OC)
Rated Frequency:50/60 Hz
Rated Current (Iₙ):1 A or 5 A
Auxiliary Supply:24/48/110/125 V DC
Rated current:1 A
continuously:4 A
Input impedance:<100 mΩ
IGCT Module
Nominal On-State Current (ITAV):2000A*
Maximum Surge Current (ITSM):20kA (1ms)
Critical di/dt:500A/μs
Maximum Blocking Voltage (VDRM):1700V
Repetitive Peak Reverse Voltage (VRRM):1700V
Gate Trigger Voltage (VGT):1.5-2.5V
Recommended Switching Frequency:≤500Hz
IGCT Module
Nominal On-State Current (ITAV):2500A
Peak Surge Current (ITSM):25kA (1ms)
Critical di/dt:800A/μs
Maximum Blocking Voltage (VDRM):4500V
Repetitive Peak Reverse Voltage (VRRM):4500V
Gate Trigger Voltage (VGT):1.5-2.5V
IGCT Module
Repetitive Blocking Voltage:4500V
Non-Repetitive Blocking Voltage (VDSM):4500V
Gate Trigger Voltage (VGT):1.5-2.5V
Average On-State Current (ITAV):3500A
Peak Surge Current (ITSM):30kA (1ms)
Critical di/dt:1000A/μs
Peak Gate Current (IG):50A
Gate Power Dissipation:20W
IGCT Module
Blocking Voltage : 4500V
Maximum Repetitive Off-State Voltage: 4500V
Gate Trigger Voltage (VGT): 1.5-2.5V
Average On-State Current : 3500A
Turn-On Time (ton): <5μs
Turn-Off Time (toff): <10μs
Switching Frequency: Up to 500Hz
IGCT Module
Blocking Voltage:4500V
Gate Trigger Voltage (VGT): 1.5V to 2.5V
Peak Surge Current (ITSM):30kA
Turn-On Time (ton): <5µs
Turn-Off Time (toff): <10µs
Switching Frequency: Up to 500H
Gate Current (IG): 50A
CONTROL BOARD
Ethernet (2 ports):10/100 Mbps
Voltage: 24 V DC
Power Consumption: 5-7 W (typical)
I/O Handling:up to 64 I/O channels
IGCT Module
Turn-off Time: ≤ 8 µs.
dv/dt: 1,000 V/µs (min)
Supply Voltage: +15V
Gate Current: 60 A
Capacitance: 5 µF (±10%)
Voltage: 2,000 V DC
Thermal Resistance: 0.008 K/W
Mounting Pressure: 12–15 kN
CONTROL UNIT
CPU: 32-bit RISC processor.
Clock Speed: 120 MHz.
Work Memory (RAM): 2 MB
Retentive Memory: 1 MB
Program Memory: 8 MB Flash
Driver Board
Input Voltage (Logic):24V DC (±10%)
Output Drive Voltage:15V–20V
Max. Switching Frequency:20 kHz
Isolation Voltage:2500V AC
Propagation Delay: <500 ns
Operating Temperature:-20°C to +70°C
Storage Temperature:-40°C to +85°C
APPLICATION BOARD
Supply Voltage:24V DC
Power Consumption:< 2W
Isolation:500V AC
Operating Temp:-25°C to +70°C
Storage Temp:-40°C to +85°C
Humidity:5–95% (non-condensing)
MEASUREMENT BOARD
Input Types: 4–20 mA
Resolution: 16-bit ADC
Power Supply: 24 V DC ±10%
Voltage/Current: ±0.05%
RTD/Thermocouple: ±0.1°C
Operating Temperature: -25°C to +70°C
Vibration: 2 g @ 10–150 Hz
Relative Humidity: ≤95% RH (non-condensing)
