Quad Elephant Inverter Rectifier Power Board

DC Output:DC 500-800V
Current Rating:100A to 200A
Continuous Current Rating:150A
Switching Frequency:10-20 kHz
Storage Temperature:-20°C to +70°C
Operating Temperature Range:-10°C to +55°C

KONE Elevator Pulse Encoder Interface Module

Power Supply: Typically 24 V DC
Max Input Frequency: Typically 100 kH
Input Voltage Level: Usually 5V or 24V
Operating Voltage Range: 18-30V DC
Operating Temperature: -10°C to +55°C
Storage Temperature: -20°C to +70°C

ANALOG IO EXTENSION

Supply Voltage:
Typically 24V DC or 48V DC
Voltage: 0-10 V, ±10 V, 0-5 V.
Current: 4-20 mA
Operating Temperature: Typically -10°C to +55°C
Storage Temperature: Around -40°C to +70°C

Interface Board

Supply Voltage:Likely 24V DC or 48V DC
Current Consumption:150 mA to 500 mA
Operating Temperature:  -10°C to +55°C
Storage Temperature: -40°C to +70°C

DRIVE MOTION CONTROL

DRIVE MOTION CONTROL
4AMP
3PHASE
48-63HZ
480V

Frequency Converter

Standard: -10°C to +40°C
Extended: -20°C to +50°C
Storage Temperature Range:-40°C to +70°C
Humidity:5% to 95% non-condensing
Current Rating:Approximately 28 A

Inverter Memory Card

Memory Type: Flash memory
Memory Capacity: Typically, 4 GB
Operating Temperature: Typically, -20°C to +85°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95%

2-port Modbus/TCP adapter module

2 x RJ45 connectors
Data rates: 10/100 Mbps
Maximum Nodes: Up to 32 nodes
Power Supply Voltage: 24 V DC
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

Control Unit

Power Supply Voltage: 24 V DC ±10%
Power Consumption: Typically 5 W
RAM: 64 MB (typical)
Analog Outputs: 2 channels, 0-10 V or 4-20 mA
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

EtherNet/IP adapter module

Supports 10 Mbps and 100 Mbps
Maximum Nodes: Up to 64 nodes
Operating Voltage: 24 V DC ± 10%
Power Consumption: 2.5 W (typical)
Operating Temperature: -25°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

PROFIBUS DP adapter module

Baud Rates Supported: 9.6 kbps to 12 Mbps
Communication Connector: 9-pin D-Sub
Operating Voltage: 24 V DC ± 10%
Power Consumption: Typically 2.5 W
Operating Temperature Range: -25°C to +60°C
Storage Temperature Range: -40°C to +85°C
Relative Humidity: 5% to 95%

CANopen interface Module

Operating Voltage: 24 V DC
Interface Type: CAN 2.0A and CAN 2.0B
Standard CAN: Up to 1 Mbps

EMC FILTER 3 PHAS

Type: 3-Phase EMC Filter
Rated Voltage: 480 VAC or 400 VAC
Rated Current: 16 A to 29 A
Frequency Range: 50 Hz to 60 Hz
Attenuation:150 kHz to 30 MHz
Operating Temperature Range: -25°C to +85°C
Storage Temperature Range: -40°C to +85°C

Inverter Drive

Power Rating:5.5 kW
Phase:3
Supply Voltage:400 V ac
Current Rating:13.8 A
For Use With:AC Motors
Series:ACS310
Field Bus Communication Type:ModBus
IP Rating:IP20
Output Frequency:0 → 500Hz
STO:No
Drive Type:AC
Mounting Type:Module For Cabinet Building

TACHOMETER CARD

Type: Tachometer Card
Series: SADC
Input Type:0-10 V or 4-20 mA output
Input Voltage Range:0 to 10 V DC
Operating Temperature Range:-20°C to +70°C
Storage Temperature Range:-40°C to +85°C

Panel Keyboard Operator

Input Voltage Range: 0–30 VDC
Output Voltage Range: 0–30 VDC
Output Current: Up to 2 A per channel
Input Voltage: 24 VDC ±10%
Power Consumption: ≤10 W
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +100°C
Humidity: 5–95% RH

Inverter Protection Board

Analog Inputs:0–10 VDC or 4–20 mA
Relay Outputs:250 VAC, 8 A
Power Supply: 24 VDC ±10%
Power Consumption: <10 W
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% RH

Control Board

Input Voltage: 24 V DC
Operating Temperature:0°C to +55°C
Storage Temperature:-20°C to +70°C
Humidity:5% to 95%

VARISTOR BOARD MODULE

THICK FILM HYBRID
VARISTOR
BOARD MODULE
58926451

liquid-cooled inverter module

Voltage Rating: 400–690 VAC ±10%
Input Current: 1,100 A (maximum)
Frequency Range: 0–1000 Hz
Operating Temperature:-20°C to +50°C
Storage Temperature: -40°C to +70°C.
Humidity: 5% to 95% (non-condensing)

PULSE AMPLIFIER BOARD

Voltage Rating:24V DC
Input Signal Type:24V
Operational Temperature Range: -20°C to +70°C
Part Number:61073027C

Drive Board

24V DC for logic power
230V to 690V AC
Approximately 10-20W
0 Hz to 200 Hz
Standard range: -10°C to +50°C
Storage Temperature:-40°C to +85°C
5% to 95% RH, non-condensing

DU/DT Filter

Input Voltage: 380–690 V AC, 3-phase
Rated Current: 65 A
Protection Rating: IP22

CANopen adapter module

Power Supply:24V DC
Input/Output Voltage:24V DC
Operating Temperature Range:
-20°C to +60°C
Humidity:
5% to 95% relative humidity

Drive Board

Voltage Range:  24V DC
Operating Frequency: 50Hz or 60Hz
Operating Temperature Range: -10°C to +50°C
Storage Temperature Range: -20°C to +70°C
