Technical specifications for 3AXD50000439638
-
Product Model3AXD50000439638
-
Spare ModelR8I 500V 2 IGBT
-
Product ParametersIGBT ASSEMBLY KIT
-
Tariff Code8537101190
-
Country of originsweden
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size57.7x22x7cm
-
ManufacturerABB
-
Weight2.6 kg
-
Insulation Voltage≥ 2500 V
-
ConfigurationBuilt for 2 IGBT
-
Rated Current Range200–400 A per module
-
Gate Drive Voltage±15 V DC
-
Operating Temperature Range−20°C to +60°C
-
Storage Temperature Range−40°C to +85°C
-
Relative Humidity5% to 95% RH (non-condensing)
Description
The ABB 3AXD50000439638 is an IGBT Assembly Kit designed for use in ABB industrial drive and power conversion systems. The kit contains the components required for the installation, replacement, or maintenance of an Insulated Gate Bipolar Transistor (IGBT) assembly, which serves as a key switching element in variable frequency drives (VFDs), inverter systems, and power converters.
Alternative Names
3AXD5OOOO439638
3AXO50000439638
3AXD5 0000439638
Information
Overview
Manuals
Application Notes
Product Applications
Pre-Installation Safety
Features:
- ABB variable frequency drives (VFDs)
- Suitable for ABB inverter and converter systems
- High reliability under continuous-duty operation
- Supports efficient motor control operation
IGBT technology combines the high-current handling capability of bipolar transistors with the fast switching characteristics of MOSFET devices, making it a widely used solution in modern variable frequency drives and converter systems. The components included in the assembly kit are intended to restore the functionality of the drive power stage during repair or scheduled maintenance procedures.
The 3AXD50000439638 ABB IGBT Assembly Kit may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB 3AXD50000439638 IGBT Assembly Kit Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The kit is intended for use in ABB ACS800-104 R8i frame size inverter modules and associated RBI (regenerative braking inverter) configurations. It serves as a critical spare part for preventive maintenance programs and system repairs, allowing rapid restoration of drive functionality without requiring complete module replacement. The assembly features screw-terminal or busbar connection options, facilitating installation within the existing power stage architecture of ABB multidrive systems.
- Synchronous Generators:Regulates terminal voltage & reactive power for large generators
- Hydro, Thermal, & Nuclear Plants:Grid sync & turbine generator control
- Mining & Minerals:High-torque crushers, grinders, conveyors & draglines
- Metal & Steel Mills:Rolling mills, arc furnaces & blast furnace blowers
- Cement & Material Processing:Rotary kilns & large material mills
- Propulsion Drives:Gate switching for marine frequency converters
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Isolate Power: Disconnect all AC and DC power lines feeding the system. Lock out and tag out the main breaker.
Discharge Capacitors: Wait at least 15 to 20 minutes for the internal DC busbar capacitors to completely discharge.
Verify Zero Voltage: Use a calibrated multimeter to test the DC bus bars and ensure no hazardous voltage remains before touching components.
ESD Protection: Wear a grounded Anti-Static Wrist Strap. The internal gate driver boards (such as the AINT, APOW, and AGBB series) are highly sensitive to electrostatic discharge.
Technical notes
Operating across a temperature range from −20°C to +60°C, with storage capability from −40°C to +85°C, the kit is suitable for industrial environments including metallurgy, mining, oil and gas, pulp and paper, and chemical processing facilities. The compact PCB-based construction enables direct mounting within the drive module housing, maintaining the original equipment's form factor and thermal management characteristics.
FAQs
-
What is the 3AXD50000439638?
+The ABB 3AXD50000439638 is a specialized industrial spare part, specifically identified as a PCB Assembly Kit (R8i 500V 2 IGBT Type) used in ABB ACS800 series frequency inverter drives. -
Which frame size does it fit?
+It is explicitly engineered for R8i frame sizes within ABB's modular drive systems -
Which inverter models use this kit?
+It is primary infrastructure for ABB drive modules such as the ACS800-104A and other liquid-cooled or air-cooled R8i inverter modules. -
Can this be interchanged with 3-IGBT systems?
+No. If your R8i drive framework uses a 3-IGBT module variant, you must use part number 3AXD50000439706 instead.
