GE Multilin

POWER METER

Operating Voltage:85–265V AC/DC
Nominal: 120/208V
Maximum: 690V AC
Burden: <0.2VA per phase
Standard CTs: 1A or 5A
Burden: <0.1VA at 5A
Voltage/Current: ±0.2% of reading
Power/Energy: ±0.5%
Frequency: ±0.01Hz

PROTECTION RELAY

Ambient Humidity Maximum:Up to 95% non condensing
Dimensions:approx: 11.5 in H x 5.5 in W x 8.5 in L
Display Version:Enhanced
Fuse:3.15 A H 250 V
Input Power:110-250VDC 100-240VAC
Manufacturer:GE Multilin
Model Number:369-HI-R-M-0-0-0-E
Phase Current Input:1 A and 5 A secondary

PROTECTION RELAY

369 Motor Management Relay
369 - Basic unit (no RTD)
HI-50-300 VDC / 60-265 VAC control power
R-Optional 12 RTD inputs (built-in)
M-Optional metering package
0-No optional Fiber Optic Port
E-Optional Modbus/TCP protocol interface
0-No Harsh environment option

Digital I/O Module

Nominal Voltage Options:
24 VDC, 48 VDC, 125 VDC, or 250 VDC.
Input Voltage Range: ±20% of nominal value
Logic 0 (Low): 0-3 V
Logic 1 (High): 15-250 V
Operating Temperature Range: -40°C to +70°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

Feeder Distribution Protection Relay

Ambient Storage
Temperature Range -40°F to +176°F
Frequency 25 to 60 Hz nominal
Insulation Voltage 300 V
Manual 1601-0120-AE
Operating Temperature Range -40°F to +140°F

Motor Management Relay

non-isolated RS232 port, RS485 port
<200 ms
2000 m (max)
-40°F (-40°C) to +140°F (+60°C)
1 A and 5 A secondary

POWER QUALITY METER

PQMIIT20CA
POWER QUALITY METER
20-60VDC/20-48VAC
50/60HZ
20VA
ONE 4 TO 20 MA ANALOG INPUT
FOUR (4) OUTPUT RELAYS / FOUR (4) SWITCH INPUTS
FOUR (4) ISOLATED ANALOG OUTPUTS SETPOINTS FOR ALARM OR CONTROL
MODBUS COMM 2 REAR RS485 PORTS 1 FRONT RS232 PORT

Communications Module

UR7HH
DISCONTINUED BY MANUFACTURER
INTER-RELAY COMMUNICATIONS MODULE
HORIZONTAL UNIT
820 NM
MULTI MODE
LED
2 CHANNELS

Motor Management Relay

SR469CASE
DISCONTINUED BY MANUFACTURER
GENERAL ELECTRIC
CASE FOR GE MULTILIN

FEEDER MANAGEMENT RELAY
