ABB Drives

CONTROL UNIT

Supply Voltage: 24 V DC
Power Consumption: ≤ 5 W
Isolation Voltage: 500 V AC
Voltage range: 0–30 V DC
Logic thresholds: ≤ 5 V DC
Ethernet/IP: TCP/IP, IPv4,

Drive Control Unit

CCU23H
3AXD50000018707
250 V AC
30 V DC
2A

CONTROL UNIT

ACH580
CCU-24-H+N2000 AHVK4.
ACH580 drive systems
Temperature: -20°C to +55°C (full function)
Humidity: 5–95% non-condensing

Safety functions module

Supply Voltage: 20–29 VDC
Power Consumption: 8 W (max)
Response Time: ≤15 ms
Isolation: 2500 VAC
Operating Temperature: -25°C to +60°C

CHARGING CONTROL BOARD

AC Input: 380–480 VAC
DC Input:500–750 VDC
Output Charging Voltage: 24/48/110 VDC
Range: 10–50 A
Current Accuracy: ±1%
Efficiency: ≥92% under full load
Full performance: -10°C to +50°C
Humidity: ≤95% RH (non-condensing)

CONTROL UNIT

ACH580 HVAC Drives
ACH580-31-CCU-24-H+N2000-AHVK4
I/O Expansion:24 VDC
Power Supply:±5% 24 VDC tolerance
Temperature Range: -15°C to +50°C (non-condensing).
Humidity: ≤95% RH.

GATE DRIVER BOARD

3AXD50000049025
GATE DRIVER BOARD
BGDR-01C
MODEL: ACS880-04
4 X CONNECTORS
REPLACED PART# 3AUA0000074145

CONTROL UNIT

CPU BOARD
CCU-24
FOR ACS580 SERIES
ACS580-CCU-24-S+N2000-ASCK4

Control Board

Remote Keypad Mount Kit
Interface Option
Keypad Power Supply:24 VDC
Max Cable Length: ≤ 10 m
Operating Temperature: -25°C to +55°C
Humidity: ≤ 95% RH

ADAPTER BOARD

Electrical Rating:24V DC (±10%)
Compatibility:ACS880-04
Communication Ports:RS485
Operation: 0°C to +55°C
Storage: -40°C to +85°C

OUTPUT FILTER BOARD

68295505
System Voltage:380–500V AC
Frequency Range:10–20 kHz
Filter Topology:LC filters (inductors + capacitors)
Operating Temperature:-15°C to +50°C
ACS880 Liquid-Cooled Multi-Drives

Interface Board

BINT12C
INTERFACE BOARD
CIRCUIT BOARD
PCB
ACS880-104-R8I FOR R8I

VARISTOR UNIT

ACS600 Single Drives
VARISTOR UNIT
Protects ACS600 single drives
Protection DutyAC Input Line Transients
Voltage Rating:380–500V AC (50/60 Hz)
Energy Absorption:≥ 120 joules
Clamping Voltage:1.3–1.5x V
Maximum Continuous Voltage:550 V DC link

PROGRAMMED MODULE

PROGRAMMED
ZINT-571
3AXD50000037997P
Key Function:DCS/SCADA
integrated safety relays
Voltage Supply:24V DC (±10%)
Operating Temp.:-25°C to +60°C

CONTROL UNIT

Input Voltage:24V DC (±15%)
Fieldbus: PROFIBUS DP, PROFINET
Digital I/O: ≥16 configurable
Analog I/O: 2x ±10V/4–20mA inputs
Safety I/O: Safe Torque Off
Compatible Drives:ABB ACS880 series
RPBA/PXG01 I/O Boards
Operating Environment:-15°C to +55°C

MEMORY UNIT KIT

MEMORY UNIT KIT
AINF6 3.42 +ZMU-03 SP
Signal Compatibility: 4–20 mA, 0–10 V, ±10 V
Resolution: 16-bit precision
Storage Capacity:2–32 GB
Analog Input Module (AINF6): 24 V DC (±10%)
Voltage Range:300–500 V AC

Main Interface Board

3AUA0000031096
ACS800 Main Board
frequency converter communication board
Auxiliary Power Input: 24 V DC (±10%)
Power Consumption: ≤5 W (typical)
Digital I/O:24 V DC
Analog Inputs: 0–10 V or 4–20 mA

Interface Main Circuit Board

ACS600 Fiber-optic communication board
MAIN CIRCUIT INTERFACE BOARD
GIVES CONTROL COMMANDS
SENDS MEASUREMENT SIGNALS
Number: Up to 16 channels
Connectors: ST/SC-type
Isolation Voltage: 2500 V

Matching Board

PCB MATCHING BOARD
CIRCUIT BOARD MODULE
58908096
Operating Voltage: 24 V DC (±10%)
Power Consumption: <5 W
Analog: +/-10 V DC or 4–20 mA
Digital: 24 V DI/DO

INTERFACE BOARD

ACS880-XINT INTERFACE BOARD
KIT A-4-8-290
R8i DC BUSB
W400

IGBT MODULE KIT SP

IGBT MODULE KIT SP
IGBT MODULE ED3 225A/1700V SP
Semiconductor spare part kit
to be used with ACS880-104 modules

Communication Board Kit

Remote Monitoring
Communication Board Kit
Input Voltage: 24 V DC (±20%)
Power Consumption: < 5 W
Ethernet Port:10/100 Mbps RJ45
Serial Port(s):RS-485 / RS-232

Surface Mounting Kit

Installation Type: Surface mounting
Aluminum or stainless steel
IP Rating: IP65
Adapter plate: 300 x 220 mm
Depth Adjustment:1–5 mm

Circuit Board

GVAR5511
DRIVE BOARD
CIRCUIT BOARD
Input Voltage:24 V DC
Tolerance: ±10%

Frequency Converter Communication Board

Input Voltage: 24 V DC
PROFIBUS DP: Up to 12 Mbps
Modbus RTU: Typically 9600 bps – 115.2 kbps
Operating Temperature:-25°C to +70°C (-13°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)
Humidity:5% – 95% (non-condensing)
Typical current consumption: < 200 mA
