      Siemens 6ES7521-1BL00-0AA0
      · Product image is representative; revision or series may vary. Contact us to request a specific version.

      6ES7521-1BL00-0AA0

      DIGITAL INPUT MODULE

      Require for Quote:

      Shipping Information

      • For inventory products, we support same day shipping upon payment.
      • For urgent needs, we offer same-day shipping on most items for orders placed before 2:00 PM UTC+8 Simply mention your preferred next-day shipping when place the order, and your order will be prioritized to minimize downtime.
      • For indent items, typical turnaround is 1-3 weeks, depending on parts availability and scarcity.
      Quantity
      Mobile *
      Country/Region *
      E-mail *
      Company
      Content *
      Upload
      (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Amikong please read our privacy policy.

      • 20+

        years in automation

      • ISO 9001

        certified quality system

      • 12 months

        amikon warranty

      • 2-hour reply

        from your account manager

      • Success Story

        solutions in action
      PART NUMBER SEARCH

      Find another automation part

      • Please try to be as accurate as possible with your search.
      • We can quote you on 1000s of specialist parts, even if they are not listed on our website.
      • We can't find any results for “”.
        SEE MORE
          SEE PRODUCTS IN SEARCH PAGE ()
          SIMATIC S7-1500
          Digital input module DI 32x24 V DC HF
          32 channels in groupsof 16
          of which 2 inputs as counters can be used
          input delay 0.05..20 ms inputtype 3 (IEC 61131)
          diagnostics; hardware interrupts
          front connector (screwterminals or push-in)
          to be ordered separately

          Technical specifications for 6ES7521-1BL00-0AA0

          • Product Model
            6ES7521-1BL00-0AA0
          • Product Parameters
            DIGITAL INPUT MODULE
          • Tariff Code
            8537101190
          • Country of origin
            GERMANY
          • Place of shipment
            Xiamen, China
          • Estimated Shipping Size
            3.4x12.5x14.6cm
          • Manufacturer
            Siemens
          • Weight
            0.28 kg
          • Product type designation
            DI 32x24VDC HF
          • HW functional status
            from FS04
          • Rated value (DC)
            24 V
          • permissible range, lower limit (DC)
            19.2 V
          • permissible range, upper limit (DC)
            28.8 V
          • Current consumption, max
            40 mA; 20 mA per group with 24 V DC supply
          • Power available from the backplane bus
            1.1 W
          • Power loss, typ.
            4.2 W
          • Number of digital inputs
            32
          • Counting frequency, max.
            6 kHz; FS04 and FW V2.2.1 or higher
          • Isolation tested with
            707 V DC
