PRODUCT DESCRIPTION
6ES7523-1BL00-0AA0 Digital Input Output Module
Siemens 6ES7523-1BL00-0AA0 is a digital input output module in the SIMATIC S7-1500 DI16/DQ16 BA range. It connects sixteen digital inputs and sixteen transistor outputs to the configured automation station.
The BA module combines sixteen digital inputs and sixteen current-sourcing transistor outputs with a supplied push-in front connector. Output channels are arranged in two groups of eight and protected against short circuits. Match the hardware functional status for any documented safety-oriented load-group shutdown; this is not a fail-safe signal module.
The BA module combines sixteen digital inputs and sixteen current-sourcing transistor outputs with a supplied push-in front connector. Output channels are arranged in two groups of eight and protected against short circuits. Match the hardware functional status for any documented safety-oriented load-group shutdown; this is not a fail-safe signal module.
BEFORE YOU BUY
Confirm the complete digital input output module
ACTUAL APPLICATIONS
Application context for 6ES7523-1BL00-0AA0
6ES7523-1BL00-0AA0 is a digital input output module for SIMATIC S7-1500 DI16/DQ16 BA. Its application scope includes automotive, industrial manufacturing, packaging. Match the installed module and electrical configuration.
-
01 · AUTOMOTIVE
Automotive Manufacturing and Vehicle Component Production
Vehicle Component ManufacturingAutomotive Assembly Production -
02 · INDUSTRIAL MANUFACTURING
Industrial Manufacturing and Automated Product Assembly
Industrial Component ManufacturingAutomated Assembly Production -
03 · PACKAGING
Packaging Manufacturing and Industrial Filling Production
Industrial Packaging ProductionContainer Filling and Sealing
Technical specifications for 6ES7523-1BL00-0AA0
-
Product Model6ES7523-1BL00-0AA0
-
Product ParametersDigital Input Output Module
-
In stock7 units
-
ManufacturerSiemens
-
Digital input allocation16, one group
-
Digital output allocation16, groups of 8
-
Supply operating range24 V DC, 19.2–28.8 V
-
Maximum electronics current30 mA
-
Backplane power1.1 W
-
Typical heat loss3.45 W
-
Input standardIEC 61131 type 3
-
Input signal thresholdsZero: −30 to +5 V; one: +11 to +30 V
-
Typical input current2.7 mA on state
-
Input filter delay3–4 ms
-
Output channel rating24 V DC, 0.5 A
-
Maximum output group load4 A
-
Total output load8 A maximum
-
Output response delays100 µs on, 500 µs off maximum
-
Isolation test707 V DC
View all additional
Alternative Names
6ES7523-1BL00-0AA0
SIMATIC S7-1500 DI16/DQ16 BA
Digital Input Output Module industrial assembly
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM INTEGRATION
Integrate 6ES7523-1BL00-0AA0 digital input output module
Match 6ES7523-1BL00-0AA0 to the accepted SIMATIC S7-1500 DI16/DQ16 BA configuration and associated parts before integration.
The BA module combines sixteen digital inputs and sixteen current-sourcing transistor outputs with a supplied push-in front connector. Output channels are arranged in two groups of eight and protected against short circuits. Match the hardware functional status for any documented safety-oriented load-group shutdown; this is not a fail-safe signal module.
Follow the applicable manufacturer instructions for 6ES7523-1BL00-0AA0. Compare connection assignments, retain the accepted wiring record and test the affected signals before returning the equipment to service.
Features:
- Digital input allocation: 16, one group
- Digital output allocation: 16, groups of 8
- Supply operating range: 24 V DC, 19.2–28.8 V
The 6ES7523-1BL00-0AA0 digital input output module requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify 6ES7523-1BL00-0AA0 digital input output module
Confirm the complete 6ES7523-1BL00-0AA0 identity and SIMATIC S7-1500 DI16/DQ16 BA execution before replacement. Match the documented connection and electrical ratings.
Record the existing digital input output module connections, companion modules and configuration. Isolate the affected circuits according to the site procedure before removing the installed part.
After fitting 6ES7523-1BL00-0AA0, restore the accepted arrangement and test the affected signals. Retain the component identity and final functional test results with the equipment record.
Features:
- Digital input allocation: 16, one group
- Digital output allocation: 16, groups of 8
- Supply operating range: 24 V DC, 19.2–28.8 V
The 6ES7523-1BL00-0AA0 digital input output module requires replacement verification against the complete installed configuration and current manufacturer documentation.
