ALL MANUFACTURERS

INSULATION MONITORING

IRDH275427
ISOMETER
IRDH SERIES
INSULATION MONITORING
LED DISPLAY
19.2-72 VDC
19.2-55 VAC
(POSSIBLE REPLACEMENT SERIES IS ISO685)

Horizontal IO bus transfer board

Voltage: 24 V DC (±10%)
Power Consumption: ≤10 W (typical)
Isolation: 1500 V AC
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Storage Temperature: -50°C to +85°C (-58°F to +185°F)
Humidity: 5–95% RH (non-condensing)

I/O Extender Module

Space requirements:4 TE, 3 HE (= 4 HP, 3U)
current: max. 10 mA (WD1in + WD2in)
Number of outputs:18
power requirements:100 mA
current: + 5V_load of all (18) IO boards
+ WD_load of all (18) IO boards
voltage drop:0.2V < V < 0.8V

TRANSMITTER

R11XJ107G
TRANSMITTER
5 KHZ
0.95 TR
+/- 7 MIN
WITH CONN

C-plug

C-plug
removable data storage medium
For simple device replacement in case offault,
for recording configuration or engineering and application data
can be usedin the following
SIMATIC NET products with C-plug
slot: SCALANCE XC-200,
XP200, XM-400, XR-500,
M-800, W-700, SC-600 and S615

PROGRAMMABLE SAFETY CONTROLLER

1756L82ES
PROGRAMMABLE SAFETY CONTROLLER
GUARDLOGIX 5580
5 MB STANDARD MEMORY
2.5 MB SAFETY MEMORY
175 ETHERNET/IP NODE CAPACITY
1 USB 2.0 PORT
1 ETHERNET/IP PORT (10/100 MBPS/1 GB SPEED)
0 TO 60 DEGREE C OPERATING TEMPERATURE

MICROMASTER 440 without filter

MICROMASTER 440 without filter
380-480 V 3 AC +10/-10% 47-63 Hz
constant torque 0.37 kW overload 150% 60 s
200% 3 s square-law torque 0.37 kW
protection IP20 ambient
temperature -10+50 °C without AOP/BOP

COMMUNICATION INTERFACE MODULE

1771ACN15
COMMUNICATION INTERFACE MODULE
1 PORT CONTROLNET
SINGLE-PORT NON-REDUNDANT MEDIA
CONTROLNET 1.5 AND BEYOND
1 AMP
5 VDC

Exciter DC Feedback Board

Voltage Feedback: 0–500 V DC
Current Feedback: 0–10 A DC
Accuracy: ±0.25% of full scale
Frequency Response: Up to 100 Hz
Signal-to-System Isolation: 1500 V AC
Common-Mode Rejection: >60 dB at 50/60 Hz
Analog Output: 4–20 mA or 0–10 V DC

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread,without armor
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread,without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 11 mm Proximity Probes

3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

4 Meter Armored Cable

3300XL 8MM
4 Meter Armored Cable
Insulation Rating: ≥250 V AC
Bend Radius: ≥100 mm
PVC: -40°C to +105°C (-40°F to +221°F)
PUR: -40°C to +90°C (-40°F to +194°F)

Proximity Sensor

10204400281002
PROXIMITY SENSOR
MODEL: 3300 XL 8 MM
1 M LENGTH
OUTPUT RESISTANCE: 50 O
OPERATING TEMP: -51 C TO +177 C
(060-987-158)

Universal Input Output Module

Fast Scan (Priority I/O Module Scan)
Electronic short circuit protection
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (analog IO)
Extended Temperature Range -40 to +70°Cmodule ambient

Redundant Power Supply

Primary/Secondary Inputs: Dual 24 V DC (±20% range)
Voltage: 24 V DC (regulated, ±1%)
Per Module: 5 A continuous (10 A peak)
Redundant Capacity: 15 A total
Efficiency: ≥85% (typical load)
Ripple/Noise: <100 mV peak-to-peak

Multiplexed I/O Module

Occupies one slot in the I/O chassis
Two isolated RS-422 serial
ports for remote multiplexed I/O
Analog Input: 4–20 mA, 0–10 V DC, RTD (Pt100)
Analog Output: 4–20 mA, 0–10 V DC
Channels: 16–32 multiplexed channels
Scan Rate: <10 ms per channel
Analog: 16-bit ADC/DAC
Channel-to-channel: 250 V AC
Input Voltage: 24 V DC ±10%

Monitored Digital Input Module

Sixteen input points
Hot-replaceable
Complete, automatic testing of all input circuits
Automatic line monitoring detects
open and short field wiringfaults
2500 volt minimum electrical
isolation between field and logiccircuits

Bus module

Bus module for ET 200PA SMART
for holding two 40 mm wide I/Omodules
for insertion and removal function

Double format PL7 processor

TSXP57303AM
PROCESSOR
PL7 DOUBLE-FORMAT
1000 MA
5 VDC
IP20

SYNCHLINK BASE BLOCK

1751SLBA
SYNCHLINK BASE BLOCK
CONVERTS SYNCHLINK TO ELECTRICAL SIGNALS
TO INTERFACE UP TO 4 FIBER 4-PORT SPLITTER BLOCKS
1.2 AMP
600 MA
24 VDC
OPEN STYLE
MOUNTABLE

Digital output module

1769OG16
OUTPUT MODULE
COMPACTLOGIX
DC DIGITAL
4.5-5.5VDC
TTL OUTPUT
16 POINT
16 CURRENT SINKING (LOW TRUE) POINT

SynchLink Block

1751SL4SP
SYNCHLINK
4 PORT SPLITTER BLOCK
CONVERTS ELECTRICAL
SIGNALS FROM SYNCHLINK BASE
BLOCK TO 4 FIBER
OPTIC
PORTS

I/O SCANNER

900S75S0460
I/O SCANNER
2 PORT
1 PER I/O RACK
Input Voltage: 24 V DC (±10%)
Current Consumption: ≤100 mA
Power Isolation: 1500 V AC

POWER STATUS MODULE

900PSM0200
POWER STATUS MODULE. 5 VDC
22 MA MAX
Operating Voltage: 5 V DC (±10%)
Power SupplyLoading:5V; 22mA max
Current Consumption: ≤22 mA (max)
