ALL MANUFACTURERS

Analog Input Module

8 differential input channels for thermocouple/mV.
Channel 8 can be designated as
the CJ-channel (4-wire Pt100 RTD)
Variety of thermocouples with the following characteristics:
B, C, E, J, K, N, R, S and T for AI835A also D, L and U
15 Bit resolution (A/D)
Inputs are monitored for wire-break open-circuit

AC 800M Controllers

ISA Secure certified - Read more
Reliability and simple fault diagnosis procedures
Modularity, allowing for step-by-step expansion
IP20 Class protection without the requirement for enclosures
The controller can be configured with 800xA control builder
The controller has full EMC certification
Sectioned CEX-Bus using a pair of BC810 / BC820
Hardware based on standards for optimum communication connectivity
(Ethernet, PROFIBUS DP, etc.)
Built-in redundant Ethernet Communication ports

AC 800M Controllers

ISA Secure certified - Read more
AC 800M High up to SIL 3 certified using PM857/SM812,PM863/SM812
PM865/SM811 or PM867/SM812
Supports S800 I/O High Integrity
(PM857, PM863, PM865, PM866A and PM891)
The controller can be configured with 800xA control builder
The controller has full EMC certification
TÜV Certified SIL 2 and SIL 3
Built-in redundant Ethernet Communication ports

Safety CPU module

Use with PM857, PM863 and PM867
Package including
SM812, Safety Module
TP868, Baseplate
TK852V10, Syncronization link cable

RM100-24TX NETWORK SWITCH

DeltaV
RM100-24TX
Smart 24-Port Switch

Drive Control Unit

DCC2324B
3EST000214-2059
Drive Control Unit
Supply Voltage:24 V DC
Power Consumption:60 W
Isolation:Reinforced 1.5 kV between logic and traction power

Digital input submodule

Rated Voltage:24 V DC (18 … 30 V)
Input Current:4 mA @ 24 V
Thresholds:ON ≥ 15 V, OFF ≤ 5 V, 2 V hysteresis
Minimum Pulse:200 µs
Isolation:500 V AC channel-to-back-plan

120V Cabinet Fan Assembly

Supply Voltage:120V AC (±10%), 50/60 Hz
Power Consumption:20 - 40 W
typical for a multi-fan assembly
Motor Type:Single-Phase
Brushless DC or AC Induction

FTA I/O Cable (5 m)

POWER CABLE
5 METER
FTA I/O Cable

DIGITAL OUTPUT CARD

MC-TDOY62
DIGITAL OUTPUT CARD
24 VDC

DIGITAL INPUT MODULE

PC BOARD
DIGITAL INPUT
MC-TDID72
24VDC

Analog Output Module

51204174175
ANALOG OUTPUT
16 CHANNELS
FTA CARD

Redundant Power Supply

AC-Only
Redundant Power Supply
120 Vac (16 A) MU
32-channel digital-input processor

DIGITAL OUTPUT RELAY

DIGITAL OUTPUT RELAY
125-240 VAC
16 POINT
COMPATIBLE IOP - MU/MC-PDOY22

ANALOG OUTPUT PROCESSOR CARD

ANALOG OUTPUT PROCESSOR CARD
16 CHANNELS
4-20 MA
MC-PAOY22

HIGH LEVEL ANALOG INPUT MODULE

PLC MODULE
SIZE A
HIGH LEVEL ANALOG INPUT
16 INPUTS
SCREW TERMINALS
USED W/ MU-PAIH03/ MC-PAIH03 IOP

POWER SUPPLY

TK-FPCXX2
POWER SUPPLY
120/240 VAC

Fibre optic cable

Fibre optic cable
Length:1 m (standard)
Fibre Type:62.5/125 µm multimode
Core / Clad:2 cores (duplex)
Attenuation:≤ 3.0 dB km⁻¹ @ 850 nm

CONTROL PROCESSOR MODULE

CONTROL PROCESSOR MODULE
C200
EXPERION PKS
24 VDC
CONFORMAL COATING
(51404305-475)

FEEDER PROTECTION AND CONTROL

Three-phase non-directional overcurrent protection
Double earth-fault protection
Non-directional earth-fault
Non-directional sensitive earth-fault
Directional earth-fault protection
Transient/intermittent earth-fault protection
Negative-phase-sequence protection
Phase discontinuity
Three-phase transformer inrush detector
Three-phase thermal overload, lines and cables
Circuit breaker failure protection
Electrically latched lockout relay

I/O BUS CPCHAS TO IOCHAS Module

FS-IOBUS-CPIO
IO Bus from Controller Chassis
to IO Chassis
UL, CSA
34 pole latch (female)

IO bus from the Controller chassis

IO bus (34-wire flat cable)
from the Controller chassis
Characteristic Impedance:100 Ω ±10%
Max. Data Rate:100 Mbps
Dielectric Withstand:500V AC

I/O Bus cable

Characteristic Impedance:100 Ω ±10%
Max. Data Rate:100 Mbps
Conductor Gauge:24-26 AWG
DC Loop Resistance:< 100 Ω per 100m
Dielectric Withstand:500V AC

Coverplate

FS-BLIND-CHA3HE
Coverplate
Coverplate/Blind Module
Covers unused ports or slots

Coverplate

FS-BLIND-CHA1HE
Coverplate
Coverplate/Blind Module
Covers unused ports or slots
