Safety Remote Output Module

Response time :≥ 20 ms
Current input max. 0.6 A
Fuse (external) 10 A time-lag (T)
Back-up battery None
Operating voltage 24 VDC, -15...+20 %, rPP ≤ 15 %
Switching voltage  5 V,  250 VAC / 250 VDC
Number of channels 8 potential-free normally open contacts

8 Channel Safety-Related Input Module

8xCh DI, (Ex)i, Safety-related SIL 3
prox. switches P+F, NAMUR, LS and LB
Ambient temperature: Ta = 0°C ... + 60°C
Un = 24VDC (-15%, +20%), max. ≤ 30
Um = 40V
Un = 5VDC (±10%), max. ≤ 6V
Um = 7V

I/O Bus Coupling Module

Safety-Ethernet protocols
Cycle times ≤ 10 ms
Operating Voltage: 24 V DC (±20%)
Power Consumption: ≤ 5 W
Operating Temperature: -40°C to +70°C

Cable Plugs

Rated Voltage: 24 V DC
Rated Current: 2 A per contact
Contact Resistance: ≤ 50 mΩ
Insulation Resistance: ≥ 100 MΩ
Dielectric Strength: 500 V AC
Operating Temperature: -25°C to +70°C
Storage Temperature: -40°C to +85°C
Humidity Resistance: 5% to 95% (non-condensing)

SAFETY CENTRAL MODULE

Voltage: 24 VDC
Power Consumption: 10–15 W
8-Channel Output Module
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 5–95% RH (non-condensing)

Safety-Related Controller

Number of counters:2
Inputs:3 on each
Input currents:1.4 mA at 5 V
Input impedance:3.7 kΩ
Counter resolution:24 bit
Min. pulse length:5 µs
Max. input frequency:100 kHz

Safety-Related Controller

Fuse (external) 10 A time-lag (T)
Buffer for date/time Gold capacitor
Temperature class T4 (Zone 2)
Operating temperature 0 °C...+60 °C
Storage temperature -40 °C...+85 °C

Ethernet communication module

F8627X
COMMUNICATION MODULE
FASTETHERNET COMMUNICATION
MODBUS TCP

K7214
PANEL
