Airflow monitor

Effective solution without costly electronics
Dependable mechanical operating principle
Direct monitoring of the cooling air
Extremely compact dimensions
Versatile mounting options
Indication of malfunctions or correct operation

Relay module

Nominal input voltage
24 VDC
2 changeover contacts
Limiting continuous current
8 A; with gold contacts
Red status indicator
Module width: 15 mm 2,50 mm²
gray

Switched-mode power supply

Pro; 1-phase
48 VDC output voltage
5 A output current
TopBoost + PowerBoost
DC OK contact

Intelligent travel transmitter

One-touch zero or full position setting
Sensor disconnect self-diagnosis function
Standard 35mm DIN rail mounting
When the transmitter is used with our sensors,
the cable length between the two can reach up to 100m

INDUSTRIAL COMPUTER

INDUSTRIAL COMPUTER
APC810 SYSTEM UNIT 1 SLOT
(PCI EXPRESS / PCI / DEPENDS ON BUS)
1 SLIDE-IN COMPACT SLOT
SMART DISPLAY LINK/DVI/MONITOR
2X RS232
5X USB 2.0
2X ETH 10/100/1000
24 VDC

Aluminum Electrolytic Capacitors

1500 µF 350 V
Aluminum Electrolytic Capacitors Radial,
Can - Screw Terminals 47mOhm @ 100Hz
12000 Hrs @ 85°C

Thyristor Modules

POWER BLOCK MODULE
1400V 410A DUAL
641-TT210N14KOF
Infineon Technologies
Gate Trigger Current - Igt:200 mA
Holding Current Ih Max:300 mA
Output Current:410 A

Thyristor Board

PCB
COMMUNICATION INTEGRATED TYPE
THYRISTOR ARRAY

Torque-RPM Adapter

Model Number:1-G070A-2
Type:Torque-RPM Signal Conditioner
Application:Motor Drive Systems
Compatibility:Reliance Electric DCS/DC Drives
Power Requirement:120V AC ±10%, 50/60Hz
Power Consumption:15VA max
Isolation:1500V AC (input-to-output)

Operator Panel System PP250

Model No.:4PP250.0571-K19
Type:PP250 Industrial HMI Panel
Display Type:TFT LCD with resistive touch
Protection Rating:IP65 (front panel)
Screen Size:5.7-inch
Resolution:320 × 240 pixels (QVGA)
Brightness:250 cd/m²
Color Depth:64K colors
Touch Technology:4-wire resistive

Data Logging Cards

Product: Cards
Type:DAQ
Analogue / Digital:Analog
Display Type:None
Connection Method:D-Sub
Interface Type:PCI
Current Rating:100 mA, 600 mA
Number of Channels:32 Channel
Brand:ADLINK Technology

3300 XL 11 mm Extension Cable

3300 XL 11 mm Extension Cable
080 8.0 meters (26.2 feet)
13 Armored FluidLoc cable
withconnector protector
00 Not required

MICROSET INPUT MODULE

Thermocouples:Type J, K, T, etc.
RTDs:Pt100, Pt1000, etc
Analog Voltage:±10V, 0-10V
Analog Current:4-20mA
Resolution: 16-bit or higher
Sampling Rate: Up to 1 kS/s
Accuracy: ±0.1% FS (Full Scale)

MICROSET INPUT MODULE 8 TEMPERATURES

Analog Voltage:0-10V
Current:4-20mA
Input Resolution: 16-bit ADC
Accuracy: ±0.1% FS (Full Scale)
Sampling Rate: 10–100 samples
Thermocouples (Type J, K, T, E, R, S, B, N)

PSU power module

Input Voltage Range:100–240V AC
DC input:24V DC
Output Voltage(s):24V DC
24V Output: 5A–10A
Total Power: 120W–250W
Voltage Regulation: ±1%
Ripple & Noise: <1% of output voltage

MICROSET INPUT MODULE

MICROSET INPUT MODULE 12 DO
Channels: Typically 4-8 differential
Input Range: ±10V, 0-20mA
Resolution: 16-bit
Sampling Rate: Up to 1 MS/s
Isolation:250V AC/DC
Accuracy: ±0.1% FS (full scale)

DIGITAL OUTPUT MODULE

IMI220-418A001: 12 DO 24 VDC 2 A
Number of Outputs: 12 channels
Output Type: 24V DC
Output Voltage: 24V DC
Output Current per Channel: 2A (max)

24 digital inputs module

IMI220-411A001: 24 DI
Model Number: IMI220-411A001
Type: Digital Input Module
Number of Inputs: 24 channels
Input Voltage Range: Typically 24V DC
Input Current per Channel: 5-10 mA

Electric actuator power board

3-Phase AC: 380V–690V AC
Current Rating: 10A peak
DC Bus Voltage: 540V–930V DC
Switching Frequency: 8kHz PWM
Logic Voltage: 24V DC

Electronic card

3-Phase AC: 380V–690V AC
Current Rating: 10A peak
DC Bus Voltage: 540V–930V DC
Switching Frequency: 8kHz PWM
Logic Voltage: 24V DC

Power board

Voltage Range: 50/60Hz
Single-Phase Option: 230V AC
Current Rating: Up to 5A continuous
Inrush Current: ≤20A
Frequency: 0–400Hz
Logic Voltage: 24V DC

Electric actuator power board

Standard: 24V AC/DC ±10%
Optional: 110V AC
Power Consumption: ≤25W
Digital Inputs:24V DC
Analog Inputs:4-20mA / 0-10V
Relays Outputs:5A, 250V AC
Analog Outputs:4-20mA

Electric Actuator Control Panel

Standard: 24V AC/DC ±10%
Optional: 110V AC
Power Consumption: ≤25W
Digital: 24V DC

Electric actuator Economic motherboard

Supply Voltage: 24V AC/DC ±10%
Power Consumption: <15W typical
Digital inputs:24V DC
Analog inputs:4-20mA/0-10V optional

Panel Controller

RPC420 Panel Controller for each manual lever
RAM: 512MB (minimum)
Flash Storage: 4GB
2x Ethernet (10/100/1000 Mbps)
4x RS-232/RS-485 (configurable)
1x CAN bus
1x USB 2.0
Input Voltage: 24VDC
Power Consumption: 50W (typical)
