Technical specifications for FX3U-4AD-PT-ADP
-
Product ModelFX3U-4AD-PT-ADP
-
Product ParametersINPUT MODULE
-
Tariff Code8537101190
-
Country of originJAPAN
-
Place of shipmentXiamen, China
-
Estimated Shipping Size2.3x9x10.5cm
-
ManufacturerMitsubishi
-
Weight0.1 kg
-
Dielectric withstand voltage500 V AC for one minute
-
Insulation resistance5 MΩ or higher by 500 V DCinsulation resistance tester
-
A/D conversioncircuit driving power24 V DC +20 %/-15 %, 50 mA for 24 V DC
-
Interface drivingpower5 V DC, 15 mA
-
Input signal3-wire platinum
-
Ratedtemperaturerange-50 °C to +250 °C
-
Digital output-500 to +2500
-
Resolution0.1 °C
Description
FX3U4ADPTADP
INPUT MODULE
FOR FX3U SERIES
4 CHANNEL
24 VDC
4 PT100 INPUTS
INPUT MODULE
FOR FX3U SERIES
4 CHANNEL
24 VDC
4 PT100 INPUTS
Information
Overview
Manuals
Technical notes
Product Applications
Installation & Wiring
Features:
- FX3U-4AD-PT-ADP Pt100 temperature sensor input special adapter
- FX3U Analog input module for Pt100 elements; 4 Pt100 inputs
- ANALOG TEMP I/P ADAPTER, 4CH, PT100, 24V
The FX3U-4AD-PT-ADP Mitsubishi INPUT MODULE may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Mitsubishi FX3U-4AD-PT-ADP INPUT MODULE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Mitsubishi Electric FX3U-4AD-PT-ADP is an analog special adapter designed to measure temperature via four channels using Pt100 platinum resistance thermometers. It is a compact, left-side expansion module compatible with the MELSEC FX3U series PLC, though it requires a function extension board for connection
- Food and packaging industry: Real-time monitoring of constant-temperature oil frying/baking equipment during food processing.
- Plastic and rubber machinery: Monitoring the heating temperatures of each section of the material barrels of small injection molding machines/extruders.
- HVAC: Monitor indoor and outdoor temperatures or duct temperatures of constant temperature and humidity air conditioning units.
- Medical and laboratory equipment: Controlling the precise temperature inside the sterilization chamber of pressure steam sterilizers.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Mounting: Connected to the left side of the PLC main unit or another special adapter.
Wiring Precautions:
Use 3-wire Pt100 sensors to prevent errors from voltage drops in the cable.
Tighten terminal screws to a torque between 0.22 and 0.25 N·m.
Keep analog cables at least 100mm (3.94") away from high-voltage or power lines to minimize noise.
Ground the shield of the analog cable at one point on the signal receiving side.
