ALL MANUFACTURERS

PROXPAC XL Proximity Transducer

2 8 3300 XL 8 mm probe with Multiple Approvals
0 4 40 mm
150 150 mm
0 6 One 3/4-14 NPT fitting
one 3/4-14NPT to 1/2-14 NPT
SST reducerand two plugs
0 2 3/4-14 NPT

PROXPAC XL Proximity Transducer

2 8 3300 XL 8 mm probe with Multiple Approvals
0 4 40 mm/ 2 0 200 mm
060 60 mm
0 0No fittings; two plugs and twowashers
0 2 3/4-14 NPT

PROXPAC XL Proximity Transducer

2 8 3300 XL 8 mm probe with Multiple Approvals
0 4 40 mm/ 2 0 200 mm
150 150 mm
0 6One 3/4-14 NPT fitting
one 3/4-14NPT to 1/2-14
NPT SST reducerand two plugs
0 2 3/4-14 NPT

PROXPAC XL Proximity Transducer

2 8 3300 XL 8 mm probe with Multiple Approvals
0 4 40 mm/ 2 0 200 mm
110  110 mm
0 6One 3/4-14 NPT fitting
one 3/4-14NPT to 1/2-14
NPT SST reducerand two plugs
0 2 3/4-14 NPT

PROXPAC XL Proximity Transducer

2 8 3300 XL 8 mm probe with Multiple Approvals
0 4 40 mm
145 145 mm
0 3 One M20 fitting, two plugs
0 2 3/4-14 NPT

PROXPAC XL Proximity Transducer

2 8 3300 XL 8 mm probe with Multiple Approvals
0 7 70 mm
155  155 mm
0 3 One M20 fitting, two plugs
0 23/4-14 NPT

ACCELEROMETER

ACCELEROMETER
100 MV/G 5% SENSITIVITY
80 G PEAK ACCELERATION RANGE
1/4-28 MOUNTING THREAD
C1D2 CAPABLE IN CONJUNCTION
WITH CAPABLE INSTRUMENT
787A-IS

3300 XL Proximitor Sensor

11 1.0 meter (3.3 feet) system length
51 5.0 meters (16.4 feet) system length
91 9.0 meters (29.5 feet) system length
05 CSA, ATEX, IECEx  Approvals

3300 XL 50 mm Proximitor Sensor

9 09.0 meters (29.5 feet) systemlength
panel mount
0 5 Multiple Approvals
3300 XL 50 mm Proximitor Sensor

Velomitor Piezo-velocity Sensor

060 6.0 meters (19.7 feet)
02 Standard cable with connectorprotector
05 CSA, ATEX, IECEx  Approvals
3300 XL Standard Extension Cable

3300 XL Standard Extension Cable

060 6.0 meters (19.7 feet)
02 Standard cable with connectorprotector
05 CSA, ATEX, IECEx  Approvals
3300 XL Standard Extension Cable

Proximity Probe HousingAssemblies

28 3300 XL 8 mm probe
multiple approvals
10 1.0 m (39 in)
No standoff adapter = 00
14.6in (370.84 mm) = 146
00 Without fittings
02 3/4-14 NPT

MODULE CARRIER

MODULE CARRIER
POWER SUPPLY CARRIER
USE WITH 8718-CA-NS OR 8715-CA-BI
WITH DC POWER FEED
DIN RAIL OR PANEL MOUINT
PAC8000 I/O is a completely modular I/O solution

Compact current relay

1MRK001987-AA
Compact current relay
3-phase CT input

3BHE012551R0001
UAD142A01
HVDC power module
Application | ±525 kV
Nominal DC Voltage | 4 200 V DC

Servo Driver

SERVO DRIVE
INTEGRATED LINE FILTER
BRAKING RESISTOR
ELECTRONIC SAFE RESTART INTERLOCK
3.2 AMP
230 V
0.7 KW

RESOLVER / DRIVE MODULE

RESOLVER / DRIVE MODULE
I/O PMI
W/ FEEDBACK

Compact universal controller

Digital controller
48 x 48 mm
with analog output
with special functions for burner
and cooling applications
single packs
RWF50.3 Continuous controller

CPU Processor Module

CPU PROCESSOR
1 GHZ
64 MEG OF MEMORY
2 SERIAL PORTS
OCCUPIES TWO SLOTS
REDUNDANT CPU
EXTERNAL HIGH CAPACITY BATTERY
IC693ACC302 REQUIRED

CPU MODULE

6ES73152EG100AB0
CPU MODULE
SIMATIC S7-300
CPU 315-2 PN/DP
WITH 128 KBYTE WORKING MEMORY
1. INTERFACE MPI/DP 12MBIT/S
2. INTERFACE ETHERNET PROFINET
MICRO MEMORY CARD NECESSARY

PROXPAC XL Proximity TransducerAssembly

Probe Tip:3300 XL 8 mm
AISI 4140 steel target calibrated
Linear Range 2.0 mm (80 mils)
start 0.25 mm (10 mils) from tip
7.87 V/mm (200 mV/mil) ±5 %, 0–45 °C
≤ ±25 µm (±1 mil)
0 – 10 kHz (–3 dB) with up to 305 m (1 000 ft) field wiring
–1 V to –17 V across full range
50 Ω

Standard ArmoredInterconnect Cable

Construction 2-conductor
Conductor:22 AWG
Cable Length Option in feet, 40, 40 ft
Velomitor Interconnect Cable

3300 XL 8 mm Proximity Probes

330104  3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 50 mm
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable

3300 XL Extended Temperature Range(ETR) Extension Cable

085 8.5 meters (27.9 feet)
00 Standard cable
05 CSA, ATEX, IECEx  Approvals
3300 XL Extended Temperature Range(ETR)
Extension Cable

TELEPERM MODULE

6DS17278AA
Analog I/O Module
TELEPERM MODULE
24 V DC ±10 %
