Analog Input Module

Channels: 8
Signal Type: 4–20 mA DC
nput Range:4–20 mA DC (configurable for 0–20 mA)
Overrange Capability: -1 mA to +25 mA
Input Impedance:≤ 250 Ω (typical)
Accuracy:±0.05% of span (at 25°C)
Temperature Drift:±0.005% of span/°C (-40°C to +70°C)
Resolution:24-bit

AO 8-Channel 4-20 mA HART Card

AO 8-CHANNEL 4-20MA HART CARD
12P4704X032
Channels: 8
Signal Type: 4–20 mA DC
Output Range:4–20 mA DC
Load Resistance:300–1100 Ω
Accuracy:±0.1% of span (25°C)
Temperature Drift:±0.02% of span/°C (-40°C to +70°C)
Resolution:15 bits (including sign)

Redundant AI 8-Channel TerminalBlock

Signal Type: 4–20 mA DC
Standard: 4–20 mA DC
Overrange: -5 mA to +25 mA
Input Impedance: ≤ 250 Ω (typical)
Field Power 30 VDC at 200 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec

8-Channel Terminal Block

TERMINAL BLOCK REDUNDANT INTERFACE
Field Power   30 VDC at 100 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec

DIGITAL INPUT MODULE

DIGITAL INPUT MODULE
NAMUR CARD
8-CHANNEL
LOCALBUS POWER 12 VDC AT 150 MA
(12P4692X042)

Safety Remote Output Module

Response time :≥ 20 ms
Current input max. 0.6 A
Fuse (external) 10 A time-lag (T)
Back-up battery None
Operating voltage 24 VDC, -15...+20 %, rPP ≤ 15 %
Switching voltage  5 V,  250 VAC / 250 VDC
Number of channels 8 potential-free normally open contacts

PANEL INTERFACE

64532588
Interface  Board
ADPI-01 PANEL INTERFACE
Power Supply:24V DC
Consumption: 15W (typical)
Operating Voltage:18–30V DC (±10%)
Isolation :500V AC between ports and power

MQ Controller

CONTROLLER
MQ SERIES
5VDC@1.4A LOCALBUS POWER
13P0072X062-233C

Operation Keyboard

Interface Connector: USB A type x 2
Operation Keyboard Function : USB 2.0
Sound Function : USB 1.1
Input Voltage: 5 V±5 %
Maximum Consumption Current: 1 A
Chassis Color: Black

Control board

Processor:Dual-core CPU
Memory:512 MB RAM
Flash Storage:1 GB internal
Power Supply:24 V DC
Communication Ports
2x Ethernet (RJ45): 10/100/1000 Mbps
1x Serial (RS-232/485): For legacy devices (MODBUS RTU).
1x USB 2.0: For engineering access.

POWER SUPPLY BOARD

POWER SUPPLY BOARD
WITH JUMPER WIRE
Primary Input: 18–32 V DC
Backup Input: 24 V DC
Output Voltage: 24 V DC
Output Current: 6 A
Holdup Time: ≥48 hours
Efficiency: >85% (typical).
Ripple & Noise: <100 mV peak-to-peak

CONTROL BOARD

Ethernet (2 ports):10/100 Mbps
Voltage: 24 V DC
Power Consumption: 5-7 W (typical)
I/O Handling:up to 64 I/O channels

BW GasAlert Connectivity Kit

GA-USB1-IR IR
Connectivity Kit with
Fleet Manager II
Software

IGCT Module

Turn-off Time: ≤ 8 µs.
dv/dt: 1,000 V/µs (min)
Supply Voltage: +15V
Gate Current: 60 A
Capacitance: 5 µF (±10%)
Voltage: 2,000 V DC
Thermal Resistance: 0.008 K/W
Mounting Pressure: 12–15 kN

CIRCUIT BOARD CARD

I / O BOARD
DIGITAL BUFFER
CARD CAGE
Analog Inputs: 8–16 channels
Digital I/O: 16–32 channels

VOICE FREQUENCY TELEGRAPHY DEVICE

Carrier Frequencies: 300–3400 Hz
Channel Spacing: 120 Hz or 240 Hz
Shift Range: ±30 Hz, ±60 Hz, or ±120 Hz
Baud Rate: 50 Bd or 200 Bd
Voltage: 48/60 VDC
Power Consumption: <15 W
Operating Threshold: -30 dBm
Voltage: 48/60 VDC nominal
Operating Temperature: -20°C to +65°C.

PLC BOARD

Power Supply:24V DC (±10%)
Power Consumption:≤ 5W
Isolation:1500V AC
 Digital: 16–32 channels
Analog: 4–8 ch

USB-Hardlock Key for ECT

USB-Hardlock Key for ECT with 1 licence
Encryption:AES-128/256-bit
Hardware ID:Unique 64-bit serial number
Operating Voltage:5V DC
Power Consumption:≤ 100 mA

PCB Board

Fiber Optic Ports: 6–12 channels
Power supply pins:+24V DC, +5V DC
Operating Voltage: 24V DC
Power Consumption: ≤ 15W
Reinforced isolation:2.5kV

CONTROL UNIT

CPU: 32-bit RISC processor.
Clock Speed: 120 MHz.
Work Memory (RAM): 2 MB
Retentive Memory: 1 MB
Program Memory: 8 MB Flash

Digital Governor Turbine Control

Input Voltage:+24 Vdc at 1 A
Keypad/Display:30 Key Multi-function Keypad
Operating Temperature:–20 to +60 °C
Outputs:2 Actuator Outputs, 8 Relay Outputs
6 Programmable Current Outputs
Slot Type:Supports RS-232, RS-422, and RS-485 hardware
Software Version:OpView™ and 505View
Storage Temperature:–40 to +85 °C

DIGITAL INPUT PROCESSOR

DIGITAL INPUT PROCESSOR
MU-PDIS12
REDUNDANCY SUPPORT
32 INPUT CHANNELS
20/30 VDC
90/132 VAC RMS

XLCNE2 Paddle Board

PC BOARD
MULTIMODE
NON-CE
TDC 3000 LCN Extender Paddle Board

Earth-fault relay

Rated Current:1 A or 5 A
Rated Voltage:48–250 V AC/DC
Burden:< 0.5 VA
Contact Rating:5 A @ 250 V AC
Mounting:Panel-mounted
Operating Temperature:-25°C to +55°C

8 Channel Safety-Related Input Module

8xCh DI, (Ex)i, Safety-related SIL 3
prox. switches P+F, NAMUR, LS and LB
Ambient temperature: Ta = 0°C ... + 60°C
Un = 24VDC (-15%, +20%), max. ≤ 30
Um = 40V
Un = 5VDC (±10%), max. ≤ 6V
Um = 7V
