Elevator Control Board

Input Voltage:24V DC
Operating Current:2A max
Isolation:2500V AC
Relay Ratings:5A @ 30V DC / 250V AC
I/O Channels:16+ digital I/O

SAFETYNET CONTROLLER CARRIER

SAFETYNET CONTROLLER CARRIER
WITH EARTH LEAK DETECTION
GE INTELLIGENT PLATFORMS
(PAC8000)

POWER SUPPLY MONITOR

POWER SUPPLY MONITOR
PAC8000 I/O
NODE SERVICES
12 V DC
30 MA

Intelligent Fire Alarm Control Panel

CONTROL PANEL
INTELLIGENT ADRESSABLE
FIRE ALARM CONTROL PANEL
120VAC
30-120WATT HIGH-EFFICIENCY AMPLIFIERS
DAY/NIGHT AUTOMATIC ADJUSTMENT
EIA-485 ANNUCIATOR
AND TERMINAL MODE PORTS
REPLACED BY CPU2-640

Reflective Memory PCI Node Card

PC BOARD
REFLECTIVE MEMORY
PCI NODE CARD
128 MBYTE MEMORY
MULTIMODE TRANSMISSION
Low Latency, Deterministic Transfer Rates
Operating System and Bus Structure Independence

Serial Modbus Communication I/O Module

Dual-port RS-232/RS-485
Baud rates up to 115.2 kbps
Voltage Levels: ±5V to ±15V
Max Cable Length: 15m (50 ft)
Supply Voltage: 24V DC (±10%)
Power Consumption: 3W typical

Wind Top Box A Module

Power Supply: 28 VDC
Communication Ports: Ethernet, Serial
Operating Temperature: -40°C to +70°C
Storage Temperature: -55°C to +85°C
Humidity: 5–95% non-condensing

High Capacity power supply

Series:90-30 PLC
Brand:GE Fanuc
Product Type:High-capacity power supply
Protocol Support:RS485
Nominal Rated Voltage:24VDC / 48VDC
Input Voltage Range, DC:Start: 21 to 56 VDC Run: 18 to 56 VDC
Voltage:24 Volts DC
Standard:UL, CE
Full load power rating:50 Watts

VIBRATION MODULE

Velocity: 0–20 mm/s
Displacement: 0–500 µm
Frequency Range:10 Hz – 10 kHz
A/D Resolution:16-bit
Sampling Rate:Up to 50 kHz
Power Supply:24V DC
Power Consumption:5W typical

I/O Protection Module

Accessory Boards:8 Boards
Ambient Temperature Rating:-30 to 65 Degrees Celsius
Base Circuitry Coating:Special Protection
Assembly Type:IS220 Standard Modular
Chassis Style:Rough Vented
Port Styles:2 Ethernet (Pictured)
Operating temperature: -30 to 65oC
Power Supply Voltage: 24 V dc

Rack Power Supply Module

Number of channels: 6
Input span: 4-20 mA
Termination resistors: 121 Ohm
Technology: Surface Mount
Common Mode Voltage Range: ±5 V
Maximum Lead Resistance: 15Ω
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C

Turbine I/O Module

Operating Voltage:24 VDC (±10%)
Power Consumption:12W (typical), 18W (max)
Isolation :1500 VAC (field-to-logic)
MPU Input Impedance:100 kΩ (differential)
Speed Resolution:1 RPM (0.0167 Hz)
Accuracy:±0.02% of reading

Backup Protection I/O Module

Operating Voltage:24 VDC (±10%)
Power Consumption:10W (typical), 15W (max)
Isolation:1500 VAC (field-to-logic)
Backplane Current:5VDC: 1.2A max
Range: 0–250 mV / ±10V (software-selectable)
Resolution: 16-bit
Accuracy: ±0.1% FS

Flame Detector Power Supply

IS220PSFDH1A
POWER SUPPLY
335V
IO PACK

ARCNET Interface I/O Module

ARCNET INTERFACE MODULE
OPTIMIZED FOR MARK VI AND MARK VIE SYSTEMS
Voltage Range: 11–30 VDC (sinking)
Operating Voltage:24 VDC
Isolation:1500 VAC

POWER METER

Operating Voltage:85–265V AC/DC
Nominal: 120/208V
Maximum: 690V AC
Burden: <0.2VA per phase
Standard CTs: 1A or 5A
Burden: <0.1VA at 5A
Voltage/Current: ±0.2% of reading
Power/Energy: ±0.5%
Frequency: ±0.01Hz

Current Source I/O Block

I/O MODULE
GENIUS BLOCK
CURRENT SOURCE ANALOG
4 INPUT / 2 OUTPUT
24/48 VDC POWER
4-20 MA CURRENT INPUTS AND OUTPUTS

Servo Driver Board

Input Voltage:24V DC (±10%)
Power Consumption:15W (typical)
Isolation Voltage:1500V AC
Analog Inputs:±10V
Control Bandwidth:1kHz (typical)
Resolution:16-bit
Update Rate:62.5μs (16kHz)

Printed Circuit Board

Series:Mark VI Speedtronic
Functional Acronym:BPPB
Input Voltage: 24V DC
Output Voltages:+5V DC @ 20A max
Efficiency: >90% typical
Ripple: <50mV p-p on all outputs
Multi-Voltage Power Distribution: Provides +5V, ±15V

Optional Auxiliary Board

Input Voltage: 24V DC ±10%
Power Consumption: 8W typical
Analog Inputs:8 channels
Digital I/O:8 channels
Vibration: 5-500Hz
Extended I/O Capacity: 16 analog/digital channels

Printed Circuit Board

Input Voltage: 24V DC
Output Voltages:+5V DC @ 20A max
Power Efficiency: >90% typical
Ripple & Noise: <50mV
Vibration: 5-500Hz

Optional Auxiliary Board

Input Voltage: +24V DC
Power Consumption: <10W
Channels: 8 or 16
Signal Range: 4-20mA
Resolution: 16-bit ADC
Voltage Levels: 24V DC

Power Converter

Input Voltage:24 V DC
Output Voltage:±15 V DC or +5 V DC
Output Current:Up to 10 A
Power Rating:120–150 W
Efficiency:≥85% (typical)
Ripple & Noise:<1% of output voltage
Voltage Regulation:±1% (line and load)

DC Power Supply Feedback Board

PC BOARD
DC POWER
FEEDBACK
MARK 5
TURBINE CONTROL
MULTI INPUT/ OUTPUT
ON BOARD RAM
