Control board
Voltage: Typically 24 VDC (±10%)
Power Consumption: <5–10 W
Digital Inputs: 8–16 channels
Analog Inputs: 4-20 mA/0-10 V
Temperature Range: -20°C to +70°C
Power Supply Rack
Overvoltage:28V DC
Input Voltage:400-480V AC, 3-phase (±10%)
Output Voltage:24V DC regulated
Output Current:50A (continuous), 60A (peak)
Power Rating:1.2kW (per module)
Efficiency:>93% (at 50% load)
Power Factor:>0.95
Diode Module
Input Voltage:24V DC nominal
Input Current:3-8mA per channel
Isolation:1500V AC (field to logic)
Response Time:<1ms (ON/OFF)
Number of Channels:32
Voltage Rating:1600V (V_RRM)
Current Rating:300A (I_FAVM)
Surge Current:8kA (I_FSM, 10ms)
Forward Voltage:1.25V @ 300A (typical)
