Infi 90

ANLOG TERM CABLE FLAME

Signal termination for 4–20 mA
Current: 4–20 mA
Voltage: 0–10 V DC, ±5 V DC
Temperature: RTD (Pt100/1000)
Cable Length: 10 meters (indicated by "-10" suffix)
Bend Radius: ≥8x cable diameter

ANALOG INPT TERM CABLE

Current: 4–20 mA
Voltage: 0–10 V DC, ±10 V DC
Gauge: 18–22 AWG
Cable Length: 30 meters
Bend Radius: ≥10x cable diameter

Analog Input Termination Unit

Number of Channels: 8 or 16
Current: 4–20 mA
Voltage: 0–10 V DC, ±10 V DC
Channel-to-channel: ≥250 V AC
Field-to-system: 1500 V AC
Supply Voltage: 24 V DC (±10%)
Power Consumption: ≤5 W

TERMINATION UNIT CABLE

Gauge: 18–24 AWG
Voltage Rating: ≤60 V DC
TERMINATION UNIT CABLE
infi-90 Termination Loop Cable

OUTPUT MODULE

OUTPUT MODULE
SYMPHONY PLUS
DIGITAL
16 CHANNEL
OPEN COLLECTOR

Digital Input Module

DIGITAL INPUT MODULE
SYMPHONY PLUS
INFI 90
DI Module. 16 CH
Universal, 32 Jumpers

MODEM CABLE 9PIN MALE-MALE

MODEM CABLE 9PIN MALE-MALE
Codex 2111 Modem to CSKb
CRT - 8' (OIS & MCS) serial cable

MCS Power Supply

Input Voltage Range:24 V DC
Input Connection:2-pin removable terminal block
Input Current :3.0 A max @ 24V DC
Output Voltage:5.1 V DC
Output Current:4.0 A max
Power Rating:20 W

Console Distribution Panel

Expandable /0 Options
RS-232 & RS-485 Communication Options
Easy to Install
Rugged, NEMA 4 Packaging

Micro-DCI Panel Controller Assembly

High-Power, Extra-Compact Controller
8 Standard Control Templates
Flexible Control Logic
Easy setup = front panel or industry's
easiest configuration software
Easy-TuneTM PID self-tuning algorithm
Expandable /0 Options
RS-232 & RS-485 Communication Options
Easy to Install
Rugged, NEMA 4 Packaging

Isolated Digital Input

Isolated Digital IO
+24vdc 0.45A
+48 vdc 0.2 A
 IEC-E96-416

TERMINATION CABLE 8FT

TERMINATION UNIT CABLE
I/O Modules Termination
I/O Module to Termination Unit Cable

TERMINATION CABLE 18FT

TERMINATION UNIT CABLE
I/O Modules Termination
Infi 90 Termination Cable Assy
I/O Module to Termination Unit Cabl

CABLE TERMINATION LOOP 19FEET

TRMNTN UNIT CABLE
19FT
I/O Module to TU Cable
I/O Module to Termination Unit Cable

Analog Module Termination Cable

NKAS013
TERMINATION UNIT CABLE
MMU-TU
3FT CABLE LENGTH

Terminal Module

Select I/O
Terminal Module
Module Termination Unit for Select I/O IS
Two slots for connection of Generic I/O modules

Digital Output Module

NTRO05-A
Digital Output Module
5 channels
Relay output or transistor output
4 V DC or 120 V AC output, depending on configuration
Maximum output current per channel: 1 A
24 V DC power supply

Termination Loop Cable

NKSD01-15
Termination Loop Cable
Shielded twisted pair or other cable
types suitable for industrial applications
15 meters

SOE clock module

Input Voltage:24 V DC
Power Consumption:≤ 8 W
Time Sync Input:IRIG-B (modulated/dc level)
Signal Voltage:TTL/RS-422 compatible (0–5 V DC)
Accuracy:±1 ms
Time Resolution:1 ms
Isolation:1500 V AC

SOE Master Module

SPSEM11
SOE Master Module
Sequence of Events Recording
Accurate to millisecond level
Typically supports Ethernet, MODBUS, or other industrial protocols
Operating temperature range: -20°C to +60°C

Fiber Optic Remote I/O Termination Unit

Isolation Voltage:1.5 kV AC
Power Supply:24 V DC (±15%), 5 W typical
Redundancy:Dual fiber ports
Fiber Interface:2x ST/PC connectors
Data Rate:10 Mbps
Max. Distance:2 km

Turbine Auto Sync Module

Input Voltages:100–120V AC
Voltage Diff: ±0.5%
Slip Freq: ±0.05 Hz
Operating Voltage:24/48/125V DC
Response Time:<20 ms

Turbine Protection Module

Operating Voltage:24/48/125V DC (±20%)
Response Time:<20 ms
Speed Range:0–9999 RPM
Redundancy:2-out-of-3 (2oo3) voting logic
Overspeed Thresholds:2x Adjustable
Input Signals:3x Magnetic Pickups (MPU) / Proximity Sensors
Trip Outputs:3x Relay Contacts (NO/NC, 5A @ 250V AC)

Analog Control Station

Operating Voltage:24V DC (±10%), 3W typical
Accuracy:±0.5% of full scale
Resolution:0.1% (for bargraph display)
Update Rate:100 ms
Isolation: 1.5 kV AC
MODE Switch: Toggle MAN/AUTO/CAS

S+ Infi-net to Computer Interface Module

Processor: 32-bit RISC processor
Memory:8MB RAM
Power Supply: 24V DC ±10%
Power Consumption: <15W
Operating Voltage Range: 18-30V DC
Screw terminals for power
BNC or ST-type fiber for Infi-net
DB9 or DB25 for serial
RJ45 for Ethernet (if equipped)
