ACS 355

VOICE FREQUENCY TELEGRAPHY DEVICE

Carrier Frequencies: 300–3400 Hz
Channel Spacing: 120 Hz or 240 Hz
Shift Range: ±30 Hz, ±60 Hz, or ±120 Hz
Baud Rate: 50 Bd or 200 Bd
Voltage: 48/60 VDC
Power Consumption: <15 W
Operating Threshold: -30 dBm
Voltage: 48/60 VDC nominal
Operating Temperature: -20°C to +65°C.

Frequency Converter Communication Board

Input Voltage: 24 V DC
PROFIBUS DP: Up to 12 Mbps
Modbus RTU: Typically 9600 bps – 115.2 kbps
Operating Temperature:-25°C to +70°C (-13°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)
Humidity:5% – 95% (non-condensing)
Typical current consumption: < 200 mA

CONTROL UNIT

Processor:32-bit/64-bit microprocessor
Clock Speed: 500 MHz to 1 GHz
RAM: 512 MB – 2 GB
Flash Storage: 1–4 GB
Max I/O Points: Configurable up to 1,000+ points
Fieldbus: PROFIBUS DP
Standard: -25°C to +70°C (-13°F to +158°F)

Frequency Converter Power Board

Input Voltage Range: 230 V AC to 690 V AC
Frequency Range: 0–300 Hz
Efficiency: ≥ 98% under standard load conditions
Operating Temperature: -10°C to +55°C
Storage Temperature: -40°C to +70°C
Humidity: 5% to 95% (non-condensing)

Driver board

Input Voltage Range: Typically 24V DC
Output Voltage Range: Dependent on the connected load
Current Rating: Up to 10A
Power Rating: Typically around 240W
Operating Frequency: 1kHz to 20kHz

Interface Board

Supply Voltage:Likely 24V DC or 48V DC
Current Consumption:150 mA to 500 mA
Operating Temperature:  -10°C to +55°C
Storage Temperature: -40°C to +70°C

Inverter Drive

Power Rating:5.5 kW
Phase:3
Supply Voltage:400 V ac
Current Rating:13.8 A
For Use With:AC Motors
Series:ACS310
Field Bus Communication Type:ModBus
IP Rating:IP20
Output Frequency:0 → 500Hz
STO:No
Drive Type:AC
Mounting Type:Module For Cabinet Building

Drive Board

Voltage Range:  24V DC
Operating Frequency: 50Hz or 60Hz
Operating Temperature Range: -10°C to +50°C
Storage Temperature Range: -20°C to +70°C

Low Voltage AC Drive 46.2 A 15 Hp

Low Voltage AC Drive 44 A 30 Hp

Low Voltage AC Drive 38 A 25 Hp

Low Voltage AC Drive 31 A 20 Hp

Low Voltage AC Drive 31 A 10 Hp

Low Voltage AC Drive 24.4 A 7.5 Hp

Low Voltage AC Drive 23.1 A 15 Hp

Low Voltage AC Drive 17.6 A 5 Hp

Low Voltage AC Drive 15.6 A 10 Hp

Low Voltage AC Drive

Low Voltage AC Drive - 2.2 KW (3 Hp)

Low Voltage AC Drive 8.8 A 5 Hp

Low Voltage AC Drive 7.5 A 2 Hp

Low Voltage AC Drive 6.7 A 1.5 Hp

Low Voltage AC Drive 5.6 A 3 Hp

Low Voltage AC Drive 5.6 A 3 Hp

Low Voltage AC Drive 4.7 A 1 Hp
