SEW

CONTROL AND POWER UNIT

3-Phase
With or Without Radio Interference Suppression
Varied Supply Voltages
SEW Eurodrive MOVIDRIVE MCH4xA Series
Compact Drive Inverters offer varied supply supplies
with a 3-Phase connection type

FREQUENCY INVERTER CONTROL UNIT

MDX60A00555A3400
POWER SUPPLY
MOVIDRIVE MDX60
380/500V
50/60 HZ
11.3/12.5 AMP
8.7 KWATT
3 PHASE

AC DRIVE

MDX60A01105A3400
AC DRIVE
AC INVERTER
POWER SUPPLY
500 VAC
50/60 HZ

VARIABLE FEQUENCY DRIVE

VARIABLE FEQUENCY DRIVE
30HP 380-500VAC
50-60HZ
39AMPS
CHASSIS/PANEL MOUNT

Variable speed drive

Supply voltage:3 × 380 VAC -10 %...3 × 500 VAC +10 %
Supply frequency:.50 Hz...60 Hz ±5 %
Rated system current: 5.0 AAC  6.2 AAC
Rated output power: 3.8 kVA
Rated output current:5.5 AAC
Minimum permitted brake:68 Ω
PWM frequency:Adjustable: 4/8/16 kHz
Speed range / resolution:-5000...0...+5000 rpm
0.2 rpm across the entire range
Power loss at PNPVmax: 105 W

AC Motor Drive Inverter

DRIVE INVERTER
3.5 AMP
3 PHASE
380-500 V AC
50/60 HZ
1.5 KW
(18215033)

AC Motor Drive Inverter

Guarantee in months12
Power1,1 kW
Temperature-30 ... +40 °C
Input3 x 300 ... 500 V AC
2,4 A / 50 ... 60 Hz
Output3 x 0 ... Uin
3,2 A / 2 ... 120 Hz

Interface Module

Serial Interface Module

UFP11A PROFIBUS DP-V1 Fieldbus Interface

Interface Adapter

DeviceNet Module

MoviSafe 100A Safety Monitor

MOVITRAC Drive

Line Filter

MOVIAXIS Servo Drive

MOVIAXIS Servo Drive

Set-Point Converter

MOVIMOT Setpoint Converter

MOVIDYN Servo Drive

MOVIDYN Servo Controller

Movitron DC Drive

Movitron DC Drive

Movitron 109 Drive

Movitron 108 Converter
