SEW Eurodrive MOVIDRIVE MCH4xA Series
Compact Drive Inverters offer varied supply supplies
with a 3-Phase connection type

FREQUENCY INVERTER CONTROL UNIT

MDX60A00555A3400
POWER SUPPLY
MOVIDRIVE MDX60
380/500V
50/60 HZ
11.3/12.5 AMP
8.7 KWATT
3 PHASE

AC DRIVE

MDX60A01105A3400
AC DRIVE
AC INVERTER
POWER SUPPLY
500 VAC
50/60 HZ

VARIABLE FEQUENCY DRIVE

VARIABLE FEQUENCY DRIVE
30HP 380-500VAC
50-60HZ
39AMPS
CHASSIS/PANEL MOUNT

Variable speed drive

Supply voltage:3 × 380 VAC -10 %...3 × 500 VAC +10 %
Supply frequency:.50 Hz...60 Hz ±5 %
Rated system current: 5.0 AAC  6.2 AAC
Rated output power: 3.8 kVA
Rated output current:5.5 AAC
Minimum permitted brake:68 Ω
PWM frequency:Adjustable: 4/8/16 kHz
Speed range / resolution:-5000...0...+5000 rpm
0.2 rpm across the entire range
Power loss at PNPVmax: 105 W

Movidrive Inverter Unit

MDX61B01105A340T
INVERTER DRIVE
MOVIDRIVE
INPUT: 21.6 AMP / 3 PHASE / 380-500 VAC +/-10% / 50/60 HZ +/-5%
OUTPUT: 24 AMP / 0-380/500 VAC / 0-180 HZ
INTERGRATED BRAKE CHOPPER
0 TO 50 DEGREE C
IP20

Movidrive Inverter Drive

DRIVE
INVERTER
3-6 AMP
3 PHASE
380-500 VAC INPUT
50/60 HZ
6.3 AMP
0-180 HZ OUTPUT
7 AMP
4.8 KVA

Movidrive Inverter Unit

MDX61B00145A3400
DRIVE INVERTER
3.6AMP
500VAC
1.5KW

AC DRIVE INVERTER

AC DRIVE INVERTER MOVITRAC B
2.2 KW (3 HP)
380-500 VAC SUPPLY
50/60 HZ, SUPPRESSION C2
3 PHASE, 4Q WITH BRAKE CHOPPER
Model Series: MOVITRAC B
MC07B0022: 2.2 kW (3 HP) output power.
5A3: 380–500 VAC 3-phase supply voltage.
4-00: 4-quadrant operation

Movitrac B Drive

MC07B00115A3400
AC DRIVE
INVERTER
MOVITRAC B
1.1 KW (1.5 HP)
380-500 VAC SUPPLY
50/60 HZ
SUPPRESSION C2
3 PHASE
4Q WITH BRAKE CHOPPER
STANDARD

Frequency Inverter type Movitrac

DRIVE INVERTER
3 PHASE
380/500V
6.7AMP
50/60HZ
4HP
