MPC60x 32-Bit Microprocessors
Two 32/64-Bit PMC Expansion Slots with Front-Panel and P2 I/O
64-bit PCI Expansion Mezzanine Connector
Asynchronous Serial Debug Port
Four 32-Bit Timers, One 16-Bit Timer, One Watchdog Timer
10/100Mb/s Ethernet Transceiver Interface
32 MHz MC68040 Microprocessor
with Floating-Point Coprocessor
8 MB DRAM
512 KB SRAM
(4) IndustryPack Ports
Ethernet Transceiver Interface
with 32-Bit Local Bus DMA
Processor:Typically powered by a PowerPC 7448
Memory:512 MB to 2 GB DDR2 RAM
CompactFlash or Solid-State Drive (SSD)
Bus Speed: 40 MHz
Voltage: Typically 5V DC
Power Consumption: 20-50W
Operating Temperature: Typically 0°C to 70°C (-40°C to +85°C)
Storage Temperature: Typically -40°C to +85°C.
Humidity: 5% to 95% relative humidity
MPC60x Class of Microprocessors
16KB/16KB or 32KB/32KB L1 cache
256KB L2 cache
Up to 512MB ECC DRAM On-Board Memory
8MB on-board Flash, 1MB Socketed
Ethernet Transceiver Interface
with 32-Bit PCI Local Bus DMA
8- or 16-bit Fast SCSI-2 Bus Interface
Parallel, Floppy, Keyboard
and Mouse Interfaces
MPC8240 32-bit microprocessor
L1 cache—16KB/16KB MPC60x class
32MB of on-board SDRAM
with optional ECCprotection
Two 32-pin PLCC/CLCC sockets for Flash memory;
upto 1MB capacity for on-board firmware
or userspecified requirements
Part Number: 08001-4247 01-W3726F 31A
Type: PLC Control Board
Manufacturer: Motorola (now part of Broadcom)
Functionality: This is a part of the Motorola 31A series of PLC board
Input/Output:
Digital I/O for controlling ON/OFF processes.
Analog I/O for monitoring and controlling processes requiring continuous measurement
