Procontrol P13 System

Analog Input Module

Input Range: 0-10V (voltage),
4-20mA (current)
Resolution: 16-bit
Sampling Rate: 1000 samples per second per channel
Accuracy: ±0.1% of full scale
Isolation: 1500V isolation between channels and the system
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range: -40°C to +85°C
Power Supply Voltage: 24V DC
Power Consumption: Maximum 5W

83SR11E Module

Power Supply:24V DC ±10%
Power Consumption:6W (typical)
Isolation:1500V AC
Range:4-20mA / 0-20mA
Resolution:16-bit
Accuracy:±0.05% of span
Load Capacity:≤750Ω
Update Rate:5ms per channel

Analog Signal Input Module

Current Inputs: 0–20 mA / 4–20 mA
Voltage Inputs: ±10 V DC, 1–5 V DC
Voltage Inputs: ±10 V DC, 1–5 V DC
Input Sharing: Supports HART communication
Accuracy: ±0.1% of span
Sampling Frequency: >300 scans/sec
Input Impedance: 250 Ω for current
Group isolation: 200 V RMS
Inter-track isolation: 250 V RMS continuous

70 AS 47b-E Module

Power Supply: 24V DC (±10%)
Power Consumption: 3.5W (typical)
Number of Channels: 8
Current Output Range: 4-20mA
Voltage Output Range: 0-10V
Resolution: 16-bit
Accuracy: ±0.1% of span
Current: ≤750Ω
Voltage: ≥1kΩ

Bus Coupler

Supply Voltage: 24V DC (19.2-30V DC)
Power Consumption: 1.5W
Current Capacity: 6A
Isolation Voltage: 500V AC
Fieldbus Protocol:PROFIBUS DP-V1
Data Rate:Up to 12 Mbps
Address Range:1-125 (PROFIBUS)
I/O Connection:S800 I/O bus

Bus Coupling Module

XS311 Insulating Converter Module

UV 7379a-E Module

Procontrol P13 Cardfile

Procontrol P13 Cardfile

Procontrol P13 Cardfile

Procontrol P13 Cardfile

Procontrol P13 Cardfile

Procontrol P13 Cardfile

Procontrol P13 Cardfile

Procontrol P13 Cardfile

Procontrol P13 Cardfile

Relay Mod. for Protect 2 NO 2NC

Relay Module for Protect. 4 NO

Backplane for Rack's 31-slots

BypassTurbine Controller Module

Turbine Controller Test and Indicator Unit

Power Supply Module

Power Supply Module

Control Module for Test Funct
