Digital input submodule

Rated Voltage:24 V DC (18 … 30 V)
Input Current:4 mA @ 24 V
Thresholds:ON ≥ 15 V, OFF ≤ 5 V, 2 V hysteresis
Minimum Pulse:200 µs
Isolation:500 V AC channel-to-back-plan

120V Cabinet Fan Assembly

Supply Voltage:120V AC (±10%), 50/60 Hz
Power Consumption:20 - 40 W
typical for a multi-fan assembly
Motor Type:Single-Phase
Brushless DC or AC Induction

FTA I/O Cable (5 m)

POWER CABLE
5 METER
FTA I/O Cable

DIGITAL OUTPUT CARD

MC-TDOY62
DIGITAL OUTPUT CARD
24 VDC

DIGITAL INPUT MODULE

PC BOARD
DIGITAL INPUT
MC-TDID72
24VDC

Analog Output Module

51204174175
ANALOG OUTPUT
16 CHANNELS
FTA CARD

Redundant Power Supply

AC-Only
Redundant Power Supply
120 Vac (16 A) MU
32-channel digital-input processor

DIGITAL OUTPUT RELAY

DIGITAL OUTPUT RELAY
125-240 VAC
16 POINT
COMPATIBLE IOP - MU/MC-PDOY22

ANALOG OUTPUT PROCESSOR CARD

ANALOG OUTPUT PROCESSOR CARD
16 CHANNELS
4-20 MA
MC-PAOY22

HIGH LEVEL ANALOG INPUT MODULE

PLC MODULE
SIZE A
HIGH LEVEL ANALOG INPUT
16 INPUTS
SCREW TERMINALS
USED W/ MU-PAIH03/ MC-PAIH03 IOP

POWER SUPPLY

TK-FPCXX2
POWER SUPPLY
120/240 VAC

Fibre optic cable

Fibre optic cable
Length:1 m (standard)
Fibre Type:62.5/125 µm multimode
Core / Clad:2 cores (duplex)
Attenuation:≤ 3.0 dB km⁻¹ @ 850 nm

CONTROL PROCESSOR MODULE

CONTROL PROCESSOR MODULE
C200
EXPERION PKS
24 VDC
CONFORMAL COATING
(51404305-475)

FEEDER PROTECTION AND CONTROL

Three-phase non-directional overcurrent protection
Double earth-fault protection
Non-directional earth-fault
Non-directional sensitive earth-fault
Directional earth-fault protection
Transient/intermittent earth-fault protection
Negative-phase-sequence protection
Phase discontinuity
Three-phase transformer inrush detector
Three-phase thermal overload, lines and cables
Circuit breaker failure protection
Electrically latched lockout relay

I/O BUS CPCHAS TO IOCHAS Module

FS-IOBUS-CPIO
IO Bus from Controller Chassis
to IO Chassis
UL, CSA
34 pole latch (female)

IO bus from the Controller chassis

IO bus (34-wire flat cable)
from the Controller chassis
Characteristic Impedance:100 Ω ±10%
Max. Data Rate:100 Mbps
Dielectric Withstand:500V AC

I/O Bus cable

Characteristic Impedance:100 Ω ±10%
Max. Data Rate:100 Mbps
Conductor Gauge:24-26 AWG
DC Loop Resistance:< 100 Ω per 100m
Dielectric Withstand:500V AC

Coverplate

FS-BLIND-CHA3HE
Coverplate
Coverplate/Blind Module
Covers unused ports or slots

Coverplate

FS-BLIND-CHA1HE
Coverplate
Coverplate/Blind Module
Covers unused ports or slots

Coverplate

FS-BLIND-CHA4HE
Coverplate
Coverplate/Blind Module
Covers unused ports or slots

POWER DISTR.CABLE 1ST

FS-PDC-IOX05-1
POWER DISTR.CABLE 1ST
Operating Voltage:24V DC
Max Current Rating:5A
Conductor Gauge:16-20 AWG
Insulation Resistance:>100 MΩ
Dielectric Withstand:500V AC

Power Distribution Cable

Operating Voltage:24V DC (Nominal)
Max Current Rating:5A
Conductor Gauge 16-20 AWG (typical for power)
Insulation Resistance:>100 MΩ @ 500V DC
Dielectric Withstand:500V AC

Bus terminator

Termination Impedance:100 Ω
Power Rating:0.25 W (typical)
Capacitance:< 10 pF (typical)
Maximum Working Voltage:30V DC

Power Supply

NSD570
1KHW002144R0001
Additional items NSD570
G3LK, Power Supply 110-250 VDC/VAC NSD570

MAIN RACK POWER TRANSISTOR DEVICES

51399930-100
MAIN POWER RACK
100-240VAC
47-63HZ
10A
