REPLACEMENT IPD CARD
SINAMICS S120
Replacement IPD card
for air-cooled Basic Line Module
710kW 380-480V 3AC/1500A
Interface Module
SIMATIC ET 200SP
PROFIBUS bundle IM
IM 155-6DP HF, max
32 I/O modules and 16 ET 200AL modules
Multi-hotswap
bundle consists of: Interface module (6ES7155-6BU01-0CN0)
Server module (6ES7193-6PA00-0AA0)
PROFIBUS connector (6ES7972-0BB70-0XA0)
SINAMICS S120 CONTROL UNIT
SINAMICS S120
CONTROL UNIT CU310-2 PN
WITH PROFINET INTERFACE
WITHOUT COMPACTFLASH CARD
Variable Speed Drives
SINAMICS G120C
rated power: 45.0 kW with 150%
overload for 3 s.
380-480 V 3AC +10/-20% 47-63 Hz
unfiltered I/O interface: 6 DI, 2 DO, 1 AI, 1 AO
Safe Torque Off integrated fieldbus
integrated: PROFINET-PN degree of protection IP20/UL
external 24 V
Adapter Cable
SINAMICS S120
C/D Type Adapter Cable
FOR MOTOR CONNECTION
2,5MM2 FOR MOTOR MODULES 3-18A
GH180 Power cell
SINAMICS PERFECT HARMONY
GH180 Power cell 200 A GenIV
Power supply unit SL10 230 V
AC/48V DC Pulse
Smart Line Module
SINAMICS S120
Smart Line Module
380-480V 3AC, 50/60 Hz
Output: 510-650 V DC, 1300 A
Rated power: 630kW Built-in unit
IP00 Internal air cooling
incl. Drive-CLiQ cable
CompactFlash card
SINAMICS S120
CompactFlash card
incl. performance expansion
V5.2 Service Pack 3
Replacement power block
SINAMICS Replacement power block
for 380-480V 3AC, 50/60 Hz
1700A Smart Line Module
rectifier Painted modules
and nickel-plated busbars
Replacement power block
SINAMICS Replacement power block
for 380-480V 3AC, 50/60 Hz
1300 A Smart Line Module
rectifier Painted modules
and nickel-plated busbars
Touch operation
SIMATIC HMI
KTP700 SINAMICS
SINAMICS PERFECT HARMONY
Key/touch operation, 7" TFT display
65536 colors, PROFIBUS interface
Power Stack Adapter
SINAMICS S120 Drive System
Voltage Support:510–720 V DC
Maximum Resolution: 16-bit digital I/O handling
Operating Temperature: 0°C to +55°C
Compatible SINAMICS S120 Modules
Smart Line Module
SINAMICS S120
Smart Line Module
380-480V 3AC, 50/60 Hz
Output: 510-650 V DC,
1700A Rated power: 800kW
Built-in unit IP00 Internal air cooling
incl. Drive-CLiQ cable
SERIES PRESSURE SWITCH
PRESSURE SWITCH
0-50BAR FOR AIR-COOLED
SINAMICS FOR AIR-COOLED
SINAMICS GM150(IGBT)
Adjustable Threshold Range: 0–50 bar
Switch Type: SPDT
Max Voltage: 250 VAC/24 VDC
Current Rating: 6 A resistive load
Operating Temperature: –25°C to +60°C
SINGLE MOTOR MODULE
SINAMICS S120
SINGLE MOTOR MODULE
INPUT: DC 600V
OUTPUT: 3-PH 400V, 3A
FRAME SIZE: BOOKSIZE D-TYPE INTERNAL
AIR COOLING OPTIMIZED PULSE SAMPLE AND
SUPPORT OF THE EXTENDED
SAFETY INTEGRATED FUNCTIONS
INCL. DRIVE-CLIQ CABLE
Thyristor Trigger Board
Input Voltage:24 VDC (±10%)
Isolation: ≥2500 VAC opto-isolation
Synchronization: Matched to 3-phase AC supply
Operating Temperature: 0°C to +55°C
Relative Humidity: Max. 95% (non-condensing)
AC DRIVE
MICROMASTER 440
without filter 380-480 V
3 AC +10/-10% 47-63 Hz
constant torque 22 kW
overload 150% 60 s, 200%
3 s square-law torque 30 kW
520x 275x 245 (HxWxD)
degree of protection IP20
ambient temperature -10+50 °C
without AOP/BOP
Touch Screen
Robicon A5E39206479
DEV CONTROL SIMATIC HMI
Screen Size:8.4-inch
Brightness:300–400 cd/m²
Power Supply:24 VDC
Power Range: +15%/-20%
Operating: 0–55°C
Storage: -30°C to +70°C
STANDARD MODULE
Normalizing module
ABO For devices
DC 890-930V, 650A
Nominal: 890–930 V DC
Rated Current: 650 A
Braking Power Dissipation: 400–500 kW
synchronous servo motor
SIMOTICS S
synchronous servo motor
1FT6 27 Nm, 100K, 2000 rpm naturally cooled
IP65 IM B5 (IM V1, IM V3)
incremental encoder sin/cos
1 VSS 2048 S/R (encoder I-2048)
for power/signal connectors:
Outlet direction axial DE without holding brake
POWER MODULE
POWER MODULE
SIMODRIVE 611 POWER MODULE
2-AXIS
15 AMP
INTERNAL COOLING
SUCCESSOR: 6SN1123-1AB00-0AA2
