ABB

Contactor

220-230V 50Hz / 230-240V 60Hz
Model Number: A30-30-10
Rated Operational Current (Ie): 30 A
Rated Operational Voltage (Ue): Up to 690 V AC
Control Voltage: 24-230 V AC/DC
Poles: 3 (3-phase)
Mechanical Life: Up to 10 million operations
Electrical Life: Up to 1 million operations
Enclosure Rating: IP20

Frequency converter

ACS510-550 Frequency converter
Model Number: 3X4K7 10028493B
Input Voltage: 3-phase, 380-480 V AC
Output Voltage: 0-480 V AC
Frequency Range: 0-400 Hz
Rated Power: 7.5 kW (10 HP)
Current Rating: 16 A
Enclosure Rating: IP20 (suitable for panel mounting)
Cooling Method: Air-cooled

Main Circuit Interface Board

Manufacturer: ABB
Model: RINT-6512C
Type: Main Circuit Interface Board
Function: Interfaces between control logic and power circuits in drives/inverters.
Voltage Rating: 24V DC
Temperature Range: -20°C to +70°C.
Humidity: Up to 95% (non-condensing).

Driver board

RINT-6421C
68638721C
Supply Voltage:24 V DC (±10%)
Power Consumption:1.5 W
Isolation:500 V AC

FAN

Voltage: 230V AC
Frequency: 50/60 Hz
Current Consumption: Approximately 0.3A
Power Consumption: Around 65W
Airflow: Approx. 280 m³/h (165 CFM)
Speed: 2650 RPM
Noise Level: Approx. 55 dB(A)

Processor board

AC 800M series systems
Voltage Supply: Typically 24 VDC
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range: -40°C to +85°C.
Humidity: 5% to 95%

IGBT Module

Voltage Rating: 1200 V
Current Rating: 450 A
Configuration: Sixpack
Technology: IGBT3 – E3
Package Type: EconoPACK™ + B

VSC power board

1VCR017053G0006
V-Contact VSC contactors
VSC power board

Current Monitor Board

Power Supply:  24V DC
Type: Current Monitor Board
Operating Temperature: Ranges from 0°C to 60°C
Communication Interface: RS-232, RS-485, or similar

CONVERSOR CONTROL BOARD

3BHE014070R0101
PPC905AE101
230VAC to 480VAC
CONVERSOR CONTROL BOARD

DIODE FAILURE DEFECTION BOARD

FOUNDATION Fieldbus Linking Device
Number of channels :4
Transfer rate:31.25 kbit/s
DIODE FAILURE DEFECTION BOARD

AO module

Channel Type:AO
Number of Output Channels:16
Long Description:4-20mA, 1-5VDC
2x8 Ch Group Isolated
Use Base xBS01-EPD

Field Exciter Power Module

Input Voltage: 500 VAC or 420 VDC
Current Rating: 50 A
Frequency Compatibility: 50/60 Hz
Output Control Mode: Pulse Width Modulation (PWM)
Operating Temperature Range: -20°C to +70°C
Protection Rating: IP20

Bus Connection Module

Auxiliary power supply Powered from host device (5V dc)
Burden ~ 0.4 W Max
Max data transfer rate 1.25 Mbps
Operating temperature range -10...55°C
Storage temperature range -40...70°C

Power interface board

Application: DCS800 DC Drives
Operating Temperature:0°C to +55°C
Storage Temperature:-25°C to +70°C
Humidity:Up to 95%, non-condensing

AC-DC/DC-DC Power supply Converter Moudle

Range: 85 V to 264 V AC
Frequency: 50/60 Hz
Primary DC Output Voltage: 24 V DC
Total Output Power: 160 W
Primary Output Current: 6.7 A
Storage Temperature: -20°C to 85°C
Operating Temperature: 0°C to 60°C

Synchron Transformer

Rated Power: 5 VA (Volt-Ampere)
Primary Voltage: 110 V (Volts)
Secondary Voltage: 9 V (Volts)
Rated Power Capacity: 5 VA
Frequency: 50/60 Hz

Synchron Transformer

Rated Power: 10 MVA
Primary Voltage: 7 kV
Secondary Voltage: 0 kV
Frequency: 50 Hz or 60 Hz

Rigi Crowbar Drive PCB

Power Supply:24V
Operating Temperature Range
Typically -20°C to +60°C
Storage Temperature Range
-40°C to +85°C

Interface Board

24 VDC
Low power design
typically <10 W
Multiple I/O ports for
interfacing with sensors
actuators, and controllers.
Optimized for high-speed
communication to minimize latency

Prog.Logic Controller

Memory Size:642 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Analog Inputs:2
Analog Outputs:1
Number of Digital Inputs:6
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

3-phase Contactor

Type: 3-phase contactor
Rated Operational Voltage (Ue): 690 V AC
Control Circuit Voltage: 100-250 V AC/DC
Rated Current: 10 A
Rated Insulation Voltage (Ui):1000 V AC
Operating Temperature:-40°C to +70°C
Storage Temperature:-40°C to +80°C

Processor Module

PM564RPETH
1SAP121000R0001
2AMP
120-240VAC
24VDC
4W

Current measurement scaling board

Function: 4-20 mA
Input impedance: Typically 250 Ω
Accuracy: ±0.5% of full scale
Voltage supply : Typically +24V DC (±10%)
Operating Temperature Range: Typically -20°C to +60°C.
Storage Temperature Range: Typically -40°C to +85°C

CPU Ccontrol I/O Board

Digital Inputs: 24V DC
Analog Inputs: 4-20mA or 0-10V
Power Supply:24V DC
Operating Temperature Range:0°C to +60°C
