ABB

I/O Transceiver Assembly

I/O Transceiver Assembly

Drive

Inverter Drive

AC Inverter Drive

Ground Leak Monitor

Power Supply/Servo Drive Case Unit

ABB Axodym Power Supply

Field Kit

Field Kit

ANALOG I/O EXTENSION

Input Signal Types: Voltage (0-10V, ±10V)
Accuracy: ±0.1% of full scale
Output Resolution: 12-bit or 16-bit
Output Load Resistance: 500Ω max
Voltage Supply Range: 24V DC nominal
Power Consumption: < 10 W
Operating Temperature:-20°C to +60°C
Storage Temperature:-40°C to +85°C

Field Kit

HTL encoder interface

Differential push-pull HTL encoders
Single-ended push-pull HTL encoders
Open collector HTL encoders
Open emitter HTL encoders
+15 V DC ± 20% 200mA (max.)
+24 V DC ± 20% 200mA (max.)

Resolver Interface Module

Power Supply Voltage: 24 VDC ± 10%
Power Consumption: Typically less than 2 W
Resolver Excitation Voltage: 4-8 V RMS
Resolver Frequency Range: 2 kHz to 15 kHz
Input Channels: 1 Resolver input
Resolution: 12-bit to 16-bit resolution depending on configuration
Accuracy: ±0.05 degrees

Field Kit

TTL encoder interface

Output voltages:
+5.5 V DC -5%, -8%, 180 mA
+24 V DC ±15%, 150 mA
Maximum cable length:
30 m with a 5 V encoder
(0.5 mm2 cable for power supply)
CH A, CH B, CH Z, CH U, CH V, CH W: RS-422/485,

EtherCat Adapter Module

Field Kit

Dual 3.5 disk drive

Single 3.5" Floppy DRV/Conformal coat 720K byte

Floppy Disk Connection Module

Floppy Disk Controller

Field Kit

Connection External Unit

DSTY 101
