Technical specifications for 3BHE013299R0002 LTC743 CE02
-
Product Model3BHE013299R0002 LTC743 CE02
-
Product ParametersPower Card
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
Estimated Shipping Size20x10.5x5cm
-
ManufacturerABB
-
Weight0.35 kg
-
Input Voltage Range100-240 V AC
-
Max Inrush25 A peak for 2 ms @ 230 V AC
-
Output 1 – Logic24 V DC ±1 %, 2.5 A
-
Output 2 – Gate drivers±15 V isolated, 0.3 A
-
Output 3 – Brake IGBT24 V, 0.2 A
-
Hold-up Time≥ 20 ms @ 24 V / 2 A
-
Efficiency87 % typ. @ 230 V AC, 2 A load
-
Operating Temperature-40 °C to +70 °C
-
Storage Temperature-40 °C to +85 °C
-
Relative Humidity5-95 % RH non-condensing
Description
3BHE013299R0002
LTC743 CE02
Drive board Card
Power Card
LTC743 CE02
Drive board Card
Power Card
Information
Overview
Manuals
Technical notes
Product Application
Physical Rack Mounting
Features:
- Wide Universal AC Input Range
- Triple Isolated DC Output Channels
- Extended Industrial Temperature Range
- Comprehensive Built-In Protection
The 3BHE013299R0002 LTC743 CE02 ABB Control board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB 3BHE013299R0002 LTC743 CE02 Control board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Accepting a wide 100–240 V AC input, the power card eliminates the need for regional voltage variants and accommodates fluctuating plant power conditions. Its robust front-end circuitry limits inrush current to 25 A peak for 2 ms at 230 V AC, protecting upstream breakers and distribution networks during cold-start events. The unit delivers three independent output rails: a primary 24 V DC ±1 % logic supply rated at 2.5 A, a ±15 V isolated gate-driver supply at 0.3 A for IGBT or MOSFET power stages, and a dedicated 24 V / 0.2 A output for brake IGBT control. A hold-up time of ≥ 20 ms at 24 V / 2 A ensures brief mains dips do not trigger processor resets or communication timeouts.
- Inverter Control & Power Driving:Driver board for frequency inverters & VSDs
- Analog/Digital Signal Acquisition:Gathers temp, pressure & vibration data
- Functional Isolation:Independent modules limit interference & improve fault tolerance
- Oil and Gas Facilities:Manages VFDs for pumps, compressors & fluid transport
- Industrial Automation & PLC Environments:Monitors factory sensors & robotic control panels
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
ESD Safety: Wear a grounded wrist strap before unboxing or touching the circuit board to protect sensitive components.Card Slot Alignment: Carefully align the edges of the PCB with the guiding tracks of the subrack slot.Insertion: Slide the card backward with stable pressure until the backplane multi-pin Eurocard connector matches securely. Do not force the board.Locking Mechanism: Fasten the front panel retaining screws to anchor the module against factory-floor vibrations.
FAQs
-
What is the 3BHE013299R0002？+The ABB 3BHE013299R0002 (also marked as LTC743 CE02) is an industrial inverter control board and power driver.
-
What equipment does this board belong to?+This specific board is an internal control panel and driver board commonly used within ABB industrial drives and automation equipment.
-
What exactly is the primary function of the LTC743 CE02 board?+The board acts as an integrated controller and driver system. It handles high-level logic processing, power device drive switching, and communication routing between the central processing unit of a drive/inverter system and external power switching components.
-
Which systems are compatible with this board?+It is part of ABB's high-performance excitation and power converter families, frequently used alongside the AC800PEC series or Unitrol systems.
