Technical specifications for DSSB-01C 68300746
-
Product ModelDSSB-01C 68300746
-
Product ParametersControl Board for DSU Unit
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size32.8x18.2x6.2cm
-
ManufacturerABB
-
Weight1.7 kg
-
Power Supply+5V DC, +3.3V DC
-
Power ConsumptionTypically < 10 W
-
Operating Temperature-20°C to +60°C
-
Storage Temperature-40°C to +85°C
-
Humidity5% to 95% (non-condensing)
Description
The ABB DSSB-01C (part number 3AFE68300746 / 68300746) is a main control board for DSU (Diode Supply Unit) systems, manufactured by ABB. It serves as the core processing and coordination module for ABB ACS800 series medium-voltage AC drive systems, managing the rectifier stage and ensuring stable DC link operation.
This control board functions as the "brain" of the inverter/rectifier system, executing all control algorithms, communication management, and fault diagnostic functions. It is responsible for controlling the drive's rectifier stage, converting AC input power to DC power for the subsequent inverter stage that drives the motor. The board utilizes a 32-bit microcontroller with PWM (Pulse Width Modulation) control to precisely regulate power conversion, fault detection, and external system communication.
This control board functions as the "brain" of the inverter/rectifier system, executing all control algorithms, communication management, and fault diagnostic functions. It is responsible for controlling the drive's rectifier stage, converting AC input power to DC power for the subsequent inverter stage that drives the motor. The board utilizes a 32-bit microcontroller with PWM (Pulse Width Modulation) control to precisely regulate power conversion, fault detection, and external system communication.
Alternative Names
DSSB 01C
DSSB01C
DSSB-0IC
DSSB-O1C
DSSB OIC
Information
Overview
Manuals
Application Notes
Product Applications
Wiring and Connections
Features:
- CONTROL UNIT
- PC BOARD KIT
- MAIN CONTROL BOARD FOR DSU UNIT
The DSSB-01C 68300746 ABB Main Control Board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB DSSB-01C 68300746 Main Control Board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The ABB DSSB-01C (Product ID 68300746) is a main control board kit designed for Diode Supply Units (DSU) in ABB ACS800-07 cabinet-built AC drives. Acting as the interface between power electronics and control logic, it ensures stable, high-precision performance, typically in industrial, heavy-duty applications. The board should be treated as a sensitive electronic component; often provided as a PC board kit.Limits exist on DC capacitor charging; avoid exceeding five power-ups in ten minutes.
- Pulp & Paper: For rollers, winders, and process control.
- Metals & Mining: For drilling rigs, rolling mills, and heavy conveyors.
- Oil, Gas & Chemical: For specialized pump and compressor management.
- Power & Water: For water treatment facilities and power generation peripherals.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Signal Integrity: Use shielded control cables to prevent interference. Ensure the shield is properly terminated at the grounding shelf.
Phase Order: When reconnecting motor cables, verify that the phase order is correct to prevent reverse rotation.
Digital I/O: The board handles signals in the 0–24 VDC range. Ensure input/output levels match these specifications to avoid damaging the 16 available channels.
Technical notes
The board features robust protection mechanisms including 4000 V electrical interface lightning protection, 1.5 A overcurrent protection, 600 W surge protection, and DC 1500 V voltage isolation. Dual power supply redundancy is supported with DC 9-36 V input range and reverse polarity protection. These features ensure reliable operation in demanding industrial environments.
FAQs
-
what is ABB DSSB-01C 68300746 ?
+The ABB DSSB-01C (Part Number: 68300746) is a specialized Main Control Board primarily used in ABB's industrial inverter drive systems. It functions as a central processing unit for managing digital signals and communication within specific motor drive units. -
Where is DSSB-01C 68300746 used?
+It is a critical spare part for ACS800-07 cabinet-built drives and is sometimes part of an ACS800DSUV3 kit. -
What should I do if the DSSB-01C indicates a fault?
+If the board distorts or incorrectly indicates an earth fault when none is present, ABB troubleshooting guides suggest checking the earth fault settings or replacing the board entirely. -
Which drive models are compatible?
+It is a spare part for various ACS800-07 drive models and is often included in the ACS800DSUV3 kit. -
What is the function of the DSSB-01C?
+It serves as the main control board for the Diode Supply Unit (DSU) in industrial drives, managing digital inputs and monitoring for faults such as earth leakage or overheating.
