SYN 6302 3BHE056302R0203
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
SYN 6302
3BHE056302R0203
SYNCHROTACT 6
Synchronizing devices and systems
24 to 250 VDC / 100 to 230 VAC
19.2 to 300 VDC / 75 to 300 VAC
3BHE056302R0203
SYNCHROTACT 6
Synchronizing devices and systems
24 to 250 VDC / 100 to 230 VAC
19.2 to 300 VDC / 75 to 300 VAC
Technical specifications for SYN 6302 3BHE056302R0203
-
Product ModelSYN 6302 3BHE056302R0203
-
Product ParametersSynchronizing device
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
Estimated Shipping Size44.3x15.5x20.2cm
-
ManufacturerABB
-
Weight7 kg
-
Nominal voltage range24 to 250 VDC 100 to 230 VAC
-
Permissible voltage range19.2 to 300 VDC 75 to 300 VAC
-
READY OPERATING2x22 W/35 VA 2x24 W/37 VA
-
Nominal voltage range50 to 130 VAC
-
Voltage range0 to 130 %Un
-
Frequency range10 to 100 Hz
-
Current consumption≤ 2 mA
-
Maximum contact voltage250 VAC/250 VDC
-
Limiting continuous current10 A
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the ABB SYN 6302?+It is part of the SYNCHROTACT 6 series, acting as a high-reliability automatic synchronization device used to match the voltage, frequency, and phase of a generator to the grid before closing the circuit breaker.
-
What is the purpose of the dual-channel design in SYN 6302 3BHE056302R0203?+The dual-channel system (output contacts in series) ensures that the circuit breaker will not close under asynchronous conditions, thereby improving plant safety.
-
Can this device replace older models?+Yes, the SYNCHROTACT 6 is designed to be backward compatible with previous generations, allowing for easy, cost-effective retrofits.
-
How are multiple breakers handled?+A single SYN 6302 unit can manage up to 20 different breakers, simplifying complex substation setups.
-
How many circuit breakers can it manage?+A single unit can synchronize up to 20 different circuit breakers, making it highly efficient for complex plants.
Get a quick price fo SYN 6302 3BHE056302R0203
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Differences between SYN 6302 and SYN 6202
Features:
- Two automatic dual-channel devices
- One redundant system
- Up to 20 different circuit breakers synchronized by one single unit Unique dual-channel design
- Backwardly compatible with previous generations for easy and cost-effective retrofits
The SYNCHROTACT 6 single-channel synchronizing devices,which are very often used, offer a high degree of safety.However, safety can be significantly increased by means ofdual-channel systems with an independent synchrocheckconnected in series.
The SYN 6302 3BHE056302R0203 ABB Redundant automatic dual-channelsynchronizing system may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB SYN 6302 3BHE056302R0203 Redundant automatic dual-channelsynchronizing system Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Often, two redundant synchronizing systems are installedin a single plant so that if one system fails the other canbe used, thereby increasing availability. The second systemis often designed for manual synchronizing with or withoutsynchrocheck.In addition, with SYNCHROTACT 6 type SYN 6302, ABBoffers two automatic dual-channel devices, building oneredundant system. This makes it possible to dispensewith manual synchronizing.Advantages of such a solution:
Lower engineering and wiring costs for the additionalsecond device.
Further increased safety since all four output contactsare normally operated in series.
- Power Generation Facilities:Syncs hydro/gas/steam/diesel generators with grid/island
- Substations & Transmission:Paralleling synchronous/asynchronous power lines
- Industrial Power Plants:Syncs industrial generators with public line
- Renewable Energy:PV/wind/BESS grid connection; meets IEEE 1547
- Manufacturing Plants:Synchronous operation of production lines
- Transportation:Synchronous control for traffic signals/infrastructure
- Emergency Power/Infrastructure:Synchro-check blocks incorrect closing during maintenance/failures
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
The SYN 6202 is a dual-channel system with two differentlystructured independent channels used as one functionalsystem.SYN 6302 consists of two “SYN 6202” dual-channel devicesused as a redundant system. The output contacts of bothdevices are normally wired in series (four channels!). If onedevice fails, a safe switchover to the other device is possibleby bypassing it. This allows paralleling to be carried outfully automatically and with maximum safety at all times.If repair or replacement of the defective device is needed,it can easily be removed from the system.Remark: the simpler SYN 5100 from the SYNCHROTACT 5family is not replaced. It can however be used in combinationwith the SYNCHROTACT 6 devices.
