1SFA898111R7000 PSTX170-600-70
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
PSTX17060070
SOFT START
600V MAIN VOLTAGE
100-250 VAC CONTROL SUPPLY VOLTAGE
50/60 HZ
IN-LINE
BUILT-IN MODBUS RTU
SOFT START
600V MAIN VOLTAGE
100-250 VAC CONTROL SUPPLY VOLTAGE
50/60 HZ
IN-LINE
BUILT-IN MODBUS RTU
Technical specifications for 1SFA898111R7000 PSTX170-600-70
-
Product Model1SFA898111R7000 PSTX170-600-70
-
Product ParametersSoftstarter
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
Estimated Shipping Size8.9x24.1x18.5cm
-
ManufacturerABB
-
Weight2.8 kg
-
Rated Operational Voltage208 ... 600 V AC
-
Rated Control Supply Voltage (Us)100 ... 250 V AC
-
Rated Control Circuit Voltage (Uc)24 V DC
-
Rated Frequency (f)50/60 Hz
-
Rated Operational Current - Inside Delta Connection300 A
-
Starting Capacity at Maximum Rated Current Ie4xIe for 10s
-
Ramp Time1 ... 120 s
-
Initial Voltage During Start10 ... 99 %
-
Step Down Voltage Special Ramp100 ... 10 %
-
Current Limit Function1.5 ... 7.5 xle
-
Analog Outputs0…10 V, 0…20 mA, 4…20 mA
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the PSTX170-600-70?+The ABB PSTX170-600-70 (1SFA898111R7000) is an advanced, compact 3-phase softstarter. Rated for 170 Amps, 208-600V main voltage, and 100-250V control voltage, it includes a built-in bypass and extensive motor protections—making it a complete starting solution for pumps, fans, and compressors.
-
What is the continuous operational current and power rating?+It features a maximum rated operational current of 170 A. At 400V, its rated operational power is 90 kW.
-
Does the PSTX170-600-70 include a bypass?+Yes, it has a built-in bypass. This reduces energy consumption, heat generation, and saves rack space.
-
What special application functions are built-in?+It comes heavily equipped with advanced motor controls, including torque control (for preventing water hammer), pump cleaning (kick-start and reverse), motor heating, electronic overload protection (EOL), jog, and emergency/fire pump mode.
-
What communication protocols are supported?+It includes built-in Modbus RTU. For networks like Profinet, Profibus, Modbus TCP, or Ethernet/IP, you can easily add the relevant Anybus modules.
Get a quick price fo 1SFA898111R7000 PSTX170-600-70
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Mechanical Installation
Features:
- High-Current Power Capability
- Advanced Voltage and Torque Control
- Integrated Bypass Circuitry
- Versatile Communications Suite
- Multi-Application Special Features
The PSTX has functions such as current limit, kickstart, analog output, EOL, motor heating and pump cleaning. PSTX also features features jog, braking, stand-still brake, diagnostics, sequence start and emergency/fire pump mode as standard.To interact with PSTX, it has a detachable full graphic display with IP66 and 4x outdoor rating.
The 1SFA898111R7000 PSTX170-600-70 ABB Soft Starter may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB 1SFA898111R7000 PSTX170-600-70 Soft Starter Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
There are four ways to communicate with PSTX. It can be done by hardwire inputs Start/Stop/Reset of fault, and by three programmable digital inputs. Another popular option is the built-in Fieldbus communication Modbus RTU and incl optional ANYBUS modules with every major protocol such as for example Profinet, Profibus, Modbus TCP, Ethernet IP and others.
Another way to communicate with PSTX is to use an external adaptor and a Fieldbus plug. PSTX is the complete alternative for any motor starting application. It’s suitable for medium to large-sized three-phase motors with nominal currents from 30...1250 A inline connection or 52...2160 A inside delta connection. Typical applications are, for example, pumps, fans, compressors, and conveyors.
- Pumps:Torque control prevents water hammer; pump cleaning reverses to clear blockages
- Fans & Blowers:Smooth ramp-up reduces mechanical stress on high-inertia fan belts
- Conveyors:Smooth starting prevents material spillage & drive chain snapping
- Compressors:Limits inrush current to protect grid during heavy load startup
- Industrial Mills & Mixers:High-torque capability for ball mills & large mixers
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Mounting Type: Use the keyhole mounting slots to secure the unit vertically to a flat, vibration-free surface.Clearance: Ensure adequate air space around the unit for cooling; typically, this means leaving at least 100 mm (4 inches) above and below and 10 mm (0.4 inches) on the sides.Environment: The device is rated IP00 (main circuit) and IP20 (enclosure), meaning it must be installed within a protective panel to prevent contact with live parts
