Technical specifications for 1769-IF4XOF2
-
Product Model1769-IF4XOF2
-
Spare Model1769IF4XOF2 1769-IF4XOF2/A
-
Product ParametersANALOG I/O MODULE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size16x13x5.3cm
-
ManufacturerAllen-Bradley
-
Weight0.25 kg
-
Storage Temperature-40°C to +85°C (-40°F to +185°F)
-
Operating Temperature0°C to +60°C (32°F to +140°F)
-
Operating Humidity5% to 95% non-condensing
-
Current Draw (max.)120 mA at 5V dc160 mA at 24V dc
-
ESD Immunity4 kV contact, 8 kV air, 4 kV indirect
-
Response Speed per Channel5 ms
-
Rated Working Voltage(2)30V ac/30V dc
Description
COMPACT COMBINATION
ANALOG I/O MODULE
COMPACTLOGIX
2 HIGH SPEED SINGLE ENDED OUTPUTS
VOLTAGE: 0 TO 10VDC
CURRENT: 0 TO 20 MA
ANALOG I/O MODULE
COMPACTLOGIX
2 HIGH SPEED SINGLE ENDED OUTPUTS
VOLTAGE: 0 TO 10VDC
CURRENT: 0 TO 20 MA
Information
Overview
Manuals
Technical notes
Product Applications
Wiring and Grounding
Features:
- 4 Analog Inputs + 2 Analog Outputs in One Compact Module
- 8-Bit Resolution with Successive Approximation ADC
- Standard Industrial Signal Ranges (0–10V DC / 0–20 mA)
- Fast 5 ms Input / 0.3 ms Output Response Speed
- 500V AC Isolation with Reinforced Insulation
The 1769-IF4XOF2 Allen-Bradley COMPACT COMBINATION ANALOG I/O MODULE may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1769-IF4XOF2 COMPACT COMBINATION ANALOG I/O MODULE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The input conversion stage utilizes a successive approximation register (SAR) analog-to-digital converter with 8-bit plus sign resolution. While this resolution is lower than 12-bit or 16-bit alternatives, it is specifically optimized for process control applications where ±0.5–0.7 % accuracy is sufficient and cost sensitivity is paramount. The converter produces a binary value stored in an 8-bit register, which the controller retrieves cyclically or via program trigger. Raw data requires scaling within the control program to convert counts into engineering units.
Input signal ranges are 0 to 10V DC and 0 to 20 mA, with full-scale capability extending to 10.5V DC and 21 mA. An over-range flag bit is set in the input data word when the signal exceeds the normal operating range, enabling the control program to detect sensor faults or process excursions without halting data conversion. The module automatically resets the flag when the signal returns to the valid range.
- Level and Volume Control:Monitors fluid levels; controls filling valves
- Basic Speed Regulation:0-10V DC reference signal for VFD speed control
- Environmental Monitoring:Temp/humidity/draft tracking for HVAC/building
- Material Handling & Conveyors:Tensioning, feeder speed & dancer loops
- Damper & Actuator Positioning:Modulates dampers, valves & louvers
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Shielded Cable: Use Belden 8761 or equivalent shielded, twisted-pair cabling for all I/O lines.
Grounding Shields: Terminate the cable shields to a chassis ground point, not to the module terminals.
Grounding Pole: Connect only one end of the cable shield to ground to prevent ground loops.
Routing: Keep all analog signal wires separated from high-voltage AC power lines.
FAQs
-
What is the 1769-IF4XOF2?
+The Allen-Bradley 1769-IF4XOF2 is a combination analog input/output module for CompactLogix and MicroLogix 1500 systems -
Should I jumper unused channels on the 1769-IF4XOF2?
+Yes. Allen-Bradley recommends jumpering unused input channels directly to the Analog Common (ANLG COM). This provides a stable reference and prevents electrical cross-talk and jumping values caused by floating channels. -
What is the resolution of this module?
+The module features 8-bit plus sign resolution. Because of this low resolution, the values jump in larger steps (typically increments of 128 bits), making it ideal for standard process monitoring but less suitable for precision positioning systems like hydraulic cylinders. -
What are the supported signal ranges?
+It supports normal operating ranges of 0 to 10V DC for voltage and 0 to 20 mA (as well as 4–20 mA) for current on both inputs and outputs.
