      Product Information

      Product Describe
      1771DS
      LATCHING INPUT MODULE
      8 INPUT
      LOGIC 1 - 10-27 V DC
      LOGIC 0 - 0-5 V DC
      OPEN STYLE
      RACK MOUNTABLE

      Specifications

      • Product Model
        1771-DS
      • Product Parameters
        LATCHING INPUT MODULE
      • Tariff Code
        8537101190
      • Country of origin
        USA
      • Place of shipment
        Xiamen, China
      • Estimated Shipping Size
        3x15.2x26cm
      • Manufacturer
        Allen-Bradley
      • Weight
        0.4 kg
      • Inputs
        8
      • Module Location
        1771 I/O chassis
      • Pulse Capture Time
        0.1, 0.5, 1.0, 2.5, or 5.0 ms
      • Input Voltage Range
        10 to 27V DC for a logic 1 /0 to 4V DC for a logic 0
      • Reverse Voltage Protection
        240V DC max
      • Maximum Off-State Current
        1mA @ 4V DC
      • Nominal Input Current
        20mA @ 27V DC typica
      • Opto-Electrical Isolation
        1500V
      • Backplane Current
        375mA typical
      • Operating Temperature
        0 to 60°C (32 to 140°F)
      • Storage Temperature
        40 to 85°C (40 to 185°C)

      • Factory New

        These are new and current items that are procured from the manufacturer.

      • New No Package

        These parts are new. They have not been used, but their original packaging is no longer available.

      • New In Opened Package

        These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged.

      • New In Sealed Package

        Parts are new. They have not been used and still have their original package seal intact.

      • New in Original Package

        These parts are new. The packages were not originally sealed by their original manufacturer.

      Warranty Period & Disclaimer

      Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.

      FAQs

      • What is the 1771-DS Module?+
        The 1771-DS is a Latching Input Module designed by Allen-Bradley for the PLC-5 system. It is an 8-input, rack-mountable module that operates within a 1771 I/O chassis, commonly used to capture fast pulses
      • What are the input voltage levels?+
        Logic 1 is 10-27V DC, and Logic 0 is 0-5V DC.
      • What sensors are compatible?+
        It is designed for optical sensors with isolated pulse or gate outputs. The off-state leakage current of the sensors must not exceed 1mA @ 4V DC
      • What is the modern replacement?+
        When upgrading from PLC-5 to ControlLogix (1756), users often replace it with high-speed modules like the 1756-IB16IF (Fast DC Input) or the 1756-IB16ISOE (Sequence of Events) to maintain fast response times.
