Technical specifications for 1771-OB
-
Product Model1771-OB
-
Spare Model1771-OB/A, 1771-OB/B, 1771-OB/C
-
Product ParametersDigital DC Output Driver Module
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size3x15.2x26cm
-
ManufacturerAllen-Bradley
-
Weight0.6 kg
-
Outputs per Module8
-
Module Location1771 I/O chassis
-
Output Voltage Range10 to 27V dc
-
Output Current (maximum)1.5A per output8A per module
-
Surge Current (maximum peroutput)4A for 1ms, repeatable every 1s
-
Off-state Leakage Current(maximum)1mA per output @ 27V dc, 25oC
-
On-state Voltage Drop (maximum)2V dc
-
Output Signal Delay10ms on/off
-
Maximum Power Rating3W per output
-
Thermal Dissipation57.6 BTU/hr (max.), 3.0 BTU/hr (min.)
-
Fuses2A 8AG (one per output)
Description
1771OB
OUTPUT MODULE
8-POINT
192 VA
12-24 V DC
OUTPUT MODULE
8-POINT
192 VA
12-24 V DC
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Application Notes
Product Applications
Field Wiring Connection
Features:
- 16-point DC output module
- 10-60V DC operating voltage range
- 0.5 A maximum output current per point
- Backplane isolation of 1500V AC (rms)
The 1771-OB provides 1500V AC (rms) backplane isolation, tested for one minute, separating the field-side output circuits from the PLC backplane electronics. The module includes individually fused output groups to provide protection for the field wiring and output circuitry. Status indicators located on the front of the 1771-OB allow maintenance personnel to monitor output operation during system diagnostics and troubleshooting.
The 1771-OB Allen-Bradley Ouput Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1771-OB Ouput Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 1771-OB is intended for installation in standard 1771 I/O chassis used with PLC-5 programmable controllers. The module receives output commands from the processor through the chassis backplane and switches external DC loads according to the application program. Wiring connections are made through the compatible 1771 wiring arm, allowing field wiring to remain in place during module replacement.
The 1771-OB is suitable for industrial control systems in manufacturing, packaging, material handling, water treatment, automotive production, and process automation. As a member of the Allen-Bradley 1771 PLC-5 I/O family, the 1771-OB provides sixteen DC sourcing outputs, high electrical isolation, fused output protection, and reliable switching performance for distributed industrial control applications.
- Material Handling Systems: Tracks package positioning on conveyors via proximity sensors
- HVAC Control Systems: Monitors safety switches, pressure sensors, and thermostat states
- Packaging Machinery: Interfaces with limit switches to confirm mechanical gate positions
- Assembly Lines: Verifies component presence using PNP photoelectric sensors
- Food & Beverage Processing: Operates valves, emergency stop buttons, and panel switches
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Use the wiring arm (typically Cat. No. 1771-WA) which attaches to the pivot bar at the bottom of the I/O chassis.
Swing the arm into position on the front of the module; it allows you to remove the module later without disconnecting field wires.
Supply DC power to the designated power terminals on the wiring arm according to the specific module loading and surge requirements.
Observe correct polarity for DC connections; applying reverse polarity or AC voltage can permanently damage the unit.
Alternative Names
1771-0B
1771-O8
1771 OB
1771OB
1771-Ob
1771 0B
Technical notes
The 1771-OB is intended for installation in standard 1771 I/O chassis used with PLC-5 programmable controllers. The module receives output commands from the processor through the chassis backplane and switches external DC loads according to the application program. Wiring connections are made through the compatible 1771 wiring arm, allowing field wiring to remain in place during module replacement.
FAQs
-
What is the 1771-OB?
+It is a 12-24V DC (10-27V range) 8-output digital module designed for the 1771 Universal I/O structure, commonly used for controlling devices like motor starters, solenoids, and pilot lights. -
What are the output ratings?
+The module provides 1.5A per output, with a maximum of 8A per module. -
What is the maximum output surge?
+4A for 1ms, repeatable every 1 second. -
Is this product brand new?
+Yes, AB 1771-OB is brand new, original, unused, and factory sealed -
How do I get the price of 1771-OB?
+Please contact our sales director Ms. Sandy for a discount exclusive quote, Email info@amikon.cn Mob/Whatsapp: +86-18020776786.
