Technical specifications for 1771-RTP4
-
Product Model1771-RTP4
-
Spare ModelTYP UMK-SE11,25-1902-RTP
-
Product ParametersRemote Termination Panel
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size7.6x7.6x15.2cm
-
ManufacturerAllen-Bradley
-
Weight0.2 kg
-
FunctionField Wiring Interface and Signal Distribution
-
SeriesPLC-5
-
Number of Slots4 slots
-
MountingPanel or wall mount
-
Backplane Type1771 I/O backplane
-
Operating Temperature0 to 60°C
-
Storage Temperature−40 to 85°C
-
Relative Humidity5% to 95% (non-condensing)
Description
The 1771-RTP4 is an Allen Bradley Remote Termination Panel designed for use with 1771-N Series High Resolution Isolated Analog I/O modules in PLC-5 control systems. The 1771-RTP4 is specifically designed for use with 1771-NOC (1) High Resolution Isolated Analog Output modules, providing proper signal termination and routing for current output applications. The 1771-RTP4 connects to 1771-N Series I/O modules via 1771-NC6 (6ft) or 1771-NC15 (15ft) cables, enabling flexible installation distances between the I/O module and the remote termination panel.
The 1771-RTP4 is for mounting on standard DIN 1 or DIN 3 mounting rails, facilitating organized and professional control cabinet installations. The 1771-RTP4 includes spare terminals (W1, W2, W3) used for field wire convenience, providing additional connection points for wiring flexibility. The 1771-RTP4 can be used in conversion solutions from 1771-N Series I/O to 1756 ControlLogix I/O via 1492-CONACAB cables, allowing system upgrades without removing existing field wires from the termination panel.
The 1771-RTP4 is for mounting on standard DIN 1 or DIN 3 mounting rails, facilitating organized and professional control cabinet installations. The 1771-RTP4 includes spare terminals (W1, W2, W3) used for field wire convenience, providing additional connection points for wiring flexibility. The 1771-RTP4 can be used in conversion solutions from 1771-N Series I/O to 1756 ControlLogix I/O via 1492-CONACAB cables, allowing system upgrades without removing existing field wires from the termination panel.
Revisions
Revision Part #
Also known as
Alternative Names
1771-RTPA
177IRTP4
I77I-RTPA
1771RTP4
I771-RTP4
I77IRTP4
1771RTPA
I771RTP4
I77IRTPA
177I-RTP4
I77I-RTP4
Information
Overview
Manuals
Application Notes
Product Applications
Field Wiring
Features:
- Compatible with 1771 I/O systems
- Supports PLC-5 architectures
- Simplifies field wiring installation
- Improves maintenance and troubleshooting efficiency
The 1771-RTP4 connects to 1771-N Series I/O modules via 1771-NC6 (6ft) or 1771-NC15 (15ft) cables, enabling flexible installation distances between the I/O module and the remote termination panel. The 1771-RTP4 is designed for mounting on standard DIN 1 or DIN 3 mounting rails, facilitating organized and professional control cabinet installations.
The 1771-RTP4 includes spare terminals (W1, W2, W3) used for field wire convenience, providing additional connection points for wiring flexibility. The 1771-RTP4 can be used in conversion solutions from 1771-N Series I/O to 1756 ControlLogix I/O via 1492-CONACAB cables
The 1771-RTP4 Allen Bradley Remote Termination Panel may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen Bradley 1771-RTP4 Remote Termination Panel Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Allen-Bradley 1771-RTP4 Remote Termination Panel is a field wiring interface for 1771 I/O and PLC-5 systems, providing centralized signal termination between field devices and I/O modules. Its panel-mounted design simplifies installation, improves wiring organization, and facilitates maintenance in industrial automation applications.
- Process Control: Routes voltage/current signals reliably to automation equipment in continuous processes
- Water/Wastewater: Terminates flow meters, pressure transducers, and valve positioners with clean isolation
- Power Generation: Monitors engine/facility temperatures using RTD inputs
- Legacy Modernization: Maps PLC-5 field wiring to modern ControlLogix systems via conversion modules
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Wire Stripping: Strip the insulation off your field wires according to specifications (typically 6–8 mm).
Terminal Connections: Connect your field device wires directly to the screw terminals on the RTP. Be sure to follow your specific module’s wiring diagram to correctly assign the I/O signals, Commons, and Grounds.
Torque Rating: Tighten the terminal screws firmly. Most 1771 termination panels require a torque of 0.5 Nm (7 lb-in).
Shielding: If using shielded cables, ensure that the cable shield is connected to the ground terminal at the RTP or I/O module end (not both) to prevent ground loops.
Technical notes
The 1771-RTP4 serves as an interface module for current output signals, with proper shield grounding and signal routing capabilities for analog output applications. The 1771-RTP4 is part of the 1771-N Series I/O wiring system that includes variations of remote termination panels (RTP1, RTP3, RTP4) depending on the type of module used. The 1771-RTP4 provides a reliable interface between field devices and the 1771-NOC analog output module, ensuring proper signal integrity and ease of maintenance in industrial control applications.
