Technical specifications for 2711P-K12C4A8
-
Product Model2711P-K12C4A8
-
Product ParametersPanelview Plus 6 1250 Operator Terminal
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size41.5x28.2x7.5cm
-
ManufacturerAllen-Bradley
-
Weight2.95 kg
-
Display size12.1 in
-
Luminance300 cd/m2 (Nits)
-
Keypad function keys40 function keys F1...F20 and K1...K20
-
Operator inputKeypad
-
Power consumption160VA max, 65VA typical
-
Display typeColor active-matrix TFT
-
Supply voltage AC 50 Hz100 V
-
Supply voltage AC 60 Hz100 V
-
Keypad, operating force340
-
Keypad, actuation1 mon presses
Description
The Allen-Bradley 2711P-K12C4A8 is a PanelView Plus 6 1250 operator terminal for industrial HMI applications, providing robust operator interface capabilities for machine-level control and monitoring. The 2711P-K12C4A8 features a 12.1-inch color active-matrix TFT display with 800 x 600 pixel resolution and 18-bit color graphics, delivering clear and vivid visualization of process data, alarms, and operator screens.providing ample screen real estate for complex HMI applications.
The 2711P-K12C4A8 provides keypad input with a stainless-steel membrane for protection against harsh industrial environments. The keypad of the 2711P-K12C4A8 includes function keys F1 to F20, numeric keys 0–9, special characters, Backspace, Enter, Left and Right Tab keys, and Shift keys, all rated for 1 million presses. This durable keypad design of the 2711P-K12C4A8 ensures reliable operator interaction in environments where touchscreens may be impractical.
The 2711P-K12C4A8 provides keypad input with a stainless-steel membrane for protection against harsh industrial environments. The keypad of the 2711P-K12C4A8 includes function keys F1 to F20, numeric keys 0–9, special characters, Backspace, Enter, Left and Right Tab keys, and Shift keys, all rated for 1 million presses. This durable keypad design of the 2711P-K12C4A8 ensures reliable operator interaction in environments where touchscreens may be impractical.
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Application Notes
Product Applications
Mechanical Mounting
Features:
- 12.1-inch Color TFT Display with Keypad Input
- Windows CE 6.0 Operating System (Standard Features)
- High Memory Capacity
- Integrated Ethernet and RS-232 Communication Ports
- Two USB 2.0 High-Speed Host Ports and SD Card Slot
Powered by the Windows CE 6.0 operating system with standard features (catalog numbers ending in "8"), the terminal includes an FTP server, VNC client/server, ActiveX controls, third-party device support, and a built-in PDF reader. It is equipped with 512 MB RAM and 512 MB nonvolatile memory (approximately 79 MB free user memory), ensuring robust performance for demanding HMI applications.
The 2711P-K12C4A8 Allen-Bradley Operator Interface may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 2711P-K12C4A8 Operator Interface Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 2711P-K12C4A8 offers flexible connectivity with a 10/100 Base-T auto-negotiating Ethernet port for controller communication and an RS-232 serial port for file transfers, printing, and controller communication. It also includes two USB 2.0 high-speed host ports (Type A) for connecting peripherals such as mice, keyboards, printers, and USB flash drives, plus a hot-swappable Secure Digital (SD) card slot supporting 1784-SDx and 1784-SDHCx cards for file transfer, firmware upgrades, and data logging.
The terminal operates on 100…240V AC power and features a modular design that allows for field replacement of the logic module, display module, communication modules, bezel, and backlight. FactoryTalk® View Machine Edition Station runtime software (version 6.0 or later) is preloaded and activated on each terminal, while HMI applications are developed using FactoryTalk View Studio for Machine Edition software (purchased separately).
- Manufacturing & Assembly:Robotic lines, packaging & conveyors
- Heavy Industry:Mining, pulp/paper & power generation
- Energy & Utilities:Oil/gas, water/wastewater & waste mgmt
- Logistics & Warehousing:Warehouse fulfillment & sorting systems
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Inspect Gasket: Ensure the sealing gasket is flat and fully seated in the terminal channel.Insert Terminal: Slide the unit into the panel cutout from the front.Engage Clips: Slide the mounting clips into the slots around the bezel.Torque Screws: Tighten the mounting screws evenly in an alternating pattern to 1.1 N·m (10 lb·in). Do not overtighten.
Alternative Names
2711P-K12C4AB
2711PK12C4AB
271IPK12C4A8
27IIP-KI2CAAB
2711P-K12CAA8
2711PK12CAA8
27I1P-K12C4A8
27IIPKI2C4A8
2711P-KI2C4A8
2711PKI2C4A8
27I1PK12C4A8
27IIPKI2CAAB
2711PK12C4A8
271IP-K12C4A8
27IIP-KI2C4A8
Technical notes
The 2711P-K12C4A8 runs the Windows CE 6.0 operating system with FactoryTalk View Machine Edition runtime software pre-installed and activated, providing a stable and secure embedded platform for HMI runtime applications. The 2711P-K12C4A8 is shipped as a closed system restricting access to the desktop, with the first startup launching FactoryTalk View ME Station Configuration mode where operators can change startup options and allow desktop access if required.
FAQs
-
What is the 2711P-K12C4A8?
+The Allen-Bradley 2711P-K12C4A8 is a discontinued PanelView Plus 6 Model 1250 graphic terminal. It features a 12.1-inch color display with keypad input, 100-240V AC power input, Ethernet and RS-232 communication ports, and runs on the Windows CE 6.0 operating system. -
How much memory does the terminal have?
+It comes equipped with 512 MB of RAM and 512 MB of non-volatile Flash memory (leaving about 79 MB available for user applications). -
What is the operator input method and screen size?
+This terminal features a Keypad for operator input and has a 12.1-inch colored display with a maximum resolution of 800 x 600 pixels. -
How do I program or create applications for this PanelView?
+You create and manage HMI applications for this terminal using FactoryTalk View Studio for Machine Edition software. Older applications (from PanelBuilder 32) can be imported using the Machine Edition Import Wizard.
