Technical specifications for 80026-044-06
-
Product Model80026-044-06
-
Product ParametersPOWER SUPPLY SWITCHING
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size30.4x29.8x7.4cm
-
ManufacturerAllen-Bradley
-
Weight4 kg
-
Input Voltage100-240V AC
-
Input Frequency47-63Hz
-
Output Voltage24V DC (±1%)
-
Output Current6A (Continuous)
-
Efficiency>88% (Typical)
-
Power Rating144W
Description
8002604406
POWER SUPPLY SWITCHING
IGCT UP TO 6600 V
10 AMP
50 VDC
OUTPUT / 6 X 3 AMP / 20 VDC
REPLACED BY 80026-044-06-R
POWER SUPPLY SWITCHING
IGCT UP TO 6600 V
10 AMP
50 VDC
OUTPUT / 6 X 3 AMP / 20 VDC
REPLACED BY 80026-044-06-R
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
Protection Functions
Between 80026-044-06 and 80026-044-06-R
Features:
- 24-60VDC input range 24-60VDC
- Six secondary outputs
- 3000VDC isolation rating
- 5g shock withstand capability
The 80026-044-06 Allen-Bradley power supply module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 80026-044-06 Power supply module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Safety features include an impressive isolation voltage rating of 3000 VDC, ensuring that the device operates reliably, even in demanding conditions. The shock specification allows it to withstand impacts up to 5 g, making it suitable for environments where vibrations or shocks may occur.
This module is configured for single-phase power connections and is typically surface-mounted, enabling easy integration into existing systems. The operation of the 80026-044-06 is rated for vibrations within the range of 5 to 32 Hz to accommodate installations with movement. Furthermore, it functions effectively in humidity ranges from 5% to 95% (non-condensing), ensuring stable performance in a variety of settings.
- Oil and Gas: Power supply and safety interlock for control systems
- Electricity and Energy: As protection relays in power plant monitoring systems
- Chemical and Pharmaceutical: Monitoring and controlling density measurement of chemicals
- Mining and Heavy Machinery: Mine infrastructure, rock drilling machines, excavators and conveyor systems
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Overcurrent Protection: Limits the output current to prevent damage during demand spikes or overload conditions.
Built-in Thermal Protection: Features integrated sensors to detect overheating, ensuring safe operation in high-temperature or demanding environments.
Short Circuit Protection: Automatically shuts down or limits power in the event of a short circuit in the output circuit to prevent permanent hardware failure; often specified at 20A.
Isolated Outputs: Provides electrical isolation between the six output channels (typically 20V DC each) to enhance safety and reduce electrical noise interference.
Status: The original 80026-044-06 is discontinued by the manufacturer.
Compliance: The -R version is explicitly listed as RoHS compliant, meeting specific environmental and regulatory standards for hazardous substances.
Physical Specifications: While electrically identical, the -R version may have slight variations in weight or dimensions depending on the supplier's technical data (e.g., approximately 9.35 lbs for the -R vs. 8.95 lbs for the original).
FAQs
-
What is the 80026-044-06 ?
+The 80026-044-06 (also listed as 80026-044-06-R) is a switching power supply module manufactured by Allen-Bradley (Rockwell Automation). This specific part is often used in high-voltage industrial applications, such as the PowerFlex 7000 medium voltage AC drives -
What is the rated power of the 80026-044-06?
+It provides 10A of output current at 50VDC. Some versions are available for IGCTs up to 6600V. -
What are the output configurations of the 80026-044-06?
+This module typically has a 6 x 3A @ 20VDC output. -
What is the function of component 80026-044-06?
+It is a switching power supply board designed to provide a stable 50VDC 10A output. -
What is the difference between 80026-044-06 and 80026-044-06-R?
+The "R" suffix typically denotes a newer revision or a direct replacement for the original part number.
