80190-560-01-R
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
This image is for reference only product style, specific date of manufacture and product version, please refer to the actual product delivery!
Product Information
Product Describe
CONTROL BOARD
Controller Circuit Board
FOR POWERFLEX 7000
FOR AC DRIVE
PWM ONLY
PCB BOARD
Analog Control Board for 18 Pulse Drive
Controller Circuit Board
FOR POWERFLEX 7000
FOR AC DRIVE
PWM ONLY
PCB BOARD
Analog Control Board for 18 Pulse Drive
Specifications
-
Product Model80190-560-01-R
-
Product ParametersController Circuit Board
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen,China
-
Estimated Shipping Size38.6x28.3x5cm
-
ManufacturerAllen-Bradley
-
Weight0.85 kg
-
Board Supply24 V DC
-
Current Draw50 mA typ. / 70 mA max
-
Power Consumption1.2 W
-
Analog Inputs4 channels, 0/4-20 mA or 0/1-5 V
-
Analog Outputs2 channels, 0/4-20 mA or 0/1-5 V
-
Resolution12-bit ADC / DAC
-
Accuracy±0.1 % FSR
-
Isolation1500 V AC
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
Do you have it in stock?+Yes, right now we have AB 80190-560-01-R in stock ready for shipment, we can support video inspection
-
What is the function of the 80190-560-01-R board?+This board is a critical component of the PowerFlex 7000 drive, responsible for handling analog signals to ensure precise regulation and smooth operation. It supports voltage ranges from 2400V to 6600V
-
Do you provide warranty as standard?+We provide a full 12-month warranty for the 80190-560-01-R. So, if you have any problems within 12 months from the date of delivery, then you can contact our Team who will be happy to help and explain what your next steps should be.
-
What is the 80190-560-01-R？+The Allen-Bradley 80190-560-01-R is an Analog Control Board (ACB) specifically designed for the PowerFlex 7000 Medium Voltage AC Drive.
-
ow to check the "DC Fault" signal on the 80190-560-01-R?+Monitor terminals J18 through J21. For example, under normal conditions, a 5V DC voltage should be measured at terminal J18 (pins 2-3); 0V indicates a fault condition.
Get a quick price fo 80190-560-01-R
