          PRODUCT DESCRIPTION

          1746-IM16 16-Point AC Input Module

          1746-IM16 is a 16-point AC input module in the Allen-Bradley SLC 500 family. It connects nominal 200/240 V AC discrete signals to a compatible SLC controller.

          Sixteen inputs share a common, with removable terminal connections and optical isolation from the control logic. The input circuits operate from 170 to 265 V AC at 47 to 63 Hz and apply the documented on/off delays. Field signals must meet the voltage, current and inrush specifications; the backplane powers the module logic.
          BEFORE YOU BUY

          Confirm the complete 16-point ac input module

          Send a label photo for review >>
          ACTUAL APPLICATIONS

          Application context for 1746-IM16

          1746-IM16 accepts AC discrete inputs within compatible SLC 500 configurations for industrial manufacturing, chemical processing and food production. Field voltage, frequency, common wiring and input-device inrush compatibility determine the supported signal arrangement.
          • 01 · INDUSTRIAL MANUFACTURING

            Industrial Manufacturing and Production Automation

            Discrete Manufacturing and AssemblyIndustrial Production and Processing
          • 02 · CHEMICAL PROCESSING

            Chemical Manufacturing and Process Production

            Chemical Manufacturing and ProcessingIndustrial Chemical Production Processes
          • 03 · FOOD & BEVERAGE

            Food Manufacturing and Beverage Processing

            Food Production and ProcessingBeverage Processing and Packaging

          Technical specifications for 1746-IM16

          • Product Model
            1746-IM16
          • Spare Model
            1746IM16
          • Product Parameters
            16-Point AC Input Module
          • In stock
            8 units
          • Manufacturer
            Allen-Bradley
          • Input points
            16
          • Points per common
            16
          • Nominal input voltage
            200/240 V AC
          • Operating voltage
            170 to 265 V AC
          • Input frequency
            47 to 63 Hz
          • 5 V backplane current
            85 mA
          • 24 V backplane current
            0 mA
          • On-state delay
            35 ms maximum
          • Off-state delay
            45 ms maximum
          • Off-state voltage
            50 V AC maximum
          • Off-state current
            2 mA maximum
          • Nominal input current
            12 mA at 240 V AC
          • Input inrush current
            1.6 A maximum for 0.5 ms
          • Operating temperature
            0 to 60℃
          • Maximum heat dissipation
            6.00 W with all points on
          View all additional
          Ask for Quote

          Alternative Names

          1746-IM16 SLC 500 16-Point AC Input Module 500 16 input points
          SYSTEM & REPLACEMENT CHECK

          Information needed before ordering

          Three direct checks to secure your system integration and minimize ordering risks.

          Information

          System integration Replacement check Manuals & support
          SYSTEM INTEGRATION

          Integrate 1746-IM16 16-point ac input module

          1746-IM16 is a 16-point ac input module in the SLC 500 platform. Match the exact article and hardware revision to the installed backplane and controller configuration before allocating channels, connections or network resources.
          Compare input points (16), points per common (16) and nominal input voltage (200/240 V AC) with the project requirements. Use the applicable terminal assignments, power budget and grounding requirements from the manufacturer documentation.
          Configure the supported operating modes for 1746-IM16, then verify the affected signals or communications in the approved controller project. Record configuration changes, diagnostic results and the completed functional checks with the equipment record.

          Features:

          • Input points: 16
          • Points per common: 16
          • Nominal input voltage: 200/240 V AC
          The 1746-IM16 16-point ac input module requires appropriate configuration before system integration and commissioning.
          INTERCHANGEABILITY

          Verify 1746-IM16 16-point ac input module

          Replace 1746-IM16 after comparing the complete label, hardware revision and SLC 500 role with the installed article. Confirm connector allocation and the supported controller configuration before exchanging the module.
          Preserve the controller project and relevant channel or communication settings before removing 1746-IM16. Photograph field connections and grounding, identify connected circuits, and isolate the required power supplies according to the manufacturer procedure.
          Restore the approved configuration after fitting 1746-IM16. Check module status indications, the affected I/O or network connections and the required operating responses, then retain the replacement identity and final acceptance results.

          Features:

          • Input points: 16
          • Points per common: 16
          • Nominal input voltage: 200/240 V AC
          The 1746-IM16 16-point ac input module requires replacement verification against the complete installed configuration and current manufacturer documentation.
          DOCUMENTATION STATUS

          Browse the Manuals, Datasheets, Official Documents, Links

          Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.

          Features:

          • Verify document identity before procurement or installation
          • Match the complete order to the manufacturer document scope
          • Accessories are supplied only when listed in the quotation
          Documentation for the 1746-IM16 16-point ac input module must be checked for document applicability before installation or commissioning.

          Also searched as

          1746-NO4V 1747-L532 1746-NR8 1746-IO12 1746-NIO4V

          Important notice

          Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
          This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
          BUYER INFORMATION

          Commercial terms without hidden steps

          Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
          • 01

            Shipping & delivery

            Dispatch
            Eligible stock: same / next day
            Carriers
            DHL, FedEx or UPS
            Ship from
            Xiamen, China
            Packed size
            3.5 × 13 × 14.5cm
            Shipping weight
            0.25kg
          • 02

            Payment & customs

            Payment
            Bank transfer (T/T)
            Currencies
            USD · EUR · GBP · RMB
            Credit cards
            Not accepted
            HS reference
            8538900000
            Origin
            United States
          • 03

            Warranty & returns

            Warranty
            12 months from AMIKON
            Inspection
            Label, condition and packing checks
            Returns
            Prior RMA authorisation required
            Compatibility
            Confirm before order
            OEM warranty
            Does not apply
          Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.

          • Part checked

            Full suffix recorded

          • Condition checked

            Label and appearance

          • Packing checked

            Antistatic protection

          • Tracking supplied

            Established couriers

          • Sandy Lin

            Dedicated account manager · 15+ years
          FREQUENTLY ASKED QUESTIONS

          Questions buyers ask about 1746-IM16

          Direct answers about identity, compatibility, stock, warranty, payment and shipping.

          • Is the IM16 intended for 24 V DC field signals?

            No. It is a 200/240 V AC input module with a 170 to 265 V AC operating range.

          • How many AC inputs share one common connection?

            The 1746-IM16 has sixteen inputs per common.

          • What mains frequency range is permitted for its input circuits?

            The supported input frequency is 47 to 63 Hz.

          • How long are the specified AC input on and off delays?

            Maximum delays are 35 ms on and 45 ms off.

          • What input-current surge must the connected AC device tolerate?

            The module specifies a maximum 1.6 A inrush for 0.5 ms; verify the field-device compatibility.

          • What nominal current flows at a 240 V AC input?

            The documented nominal input current is 12 mA at 240 V AC.

          • Which AC signal details are needed for an IM16 replacement order?

            Provide the exact 1746-IM16 article, field voltage and frequency, terminal arrangement and quantity.

          • What must be checked on an incoming AC input module?

            Verify the IM16 label, AC rating, removable terminals and connector condition against the approved order.
          READY TO VERIFY YOUR PART?

          Get a 1746-IM16 quote with price, lead time and revision check.

          Request a quote
