- 8V1022.001-2
In Stock
Ships by Sunday, August 16
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 8V1022.001-2
-
Product Model8V1022.001-2
-
Product ParametersSERVO DRIVER
-
Tariff Code8537101190
-
Country of originAustria
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size7.2x23.5x37.5cm
-
ManufacturerB&R
-
Weight3.8 kg
-
B&R ID code0xA099
-
Slots for plug-in modules4
-
Permissible power mains formsTT, TN
-
Mains input voltage3x 400 VAC to 480 VAC ±10%
-
Frequency50 / 60 Hz ±4%
-
Installed load Max3 kVA
-
Starting current at400 VAC 4 A
-
Switch-on interval>10 s
-
Power loss at max. device power without brakingresistorApprox. 120 W
-
DC bus capacitance235 µF
-
Input voltage24 VDC ±25%
-
Input capacitance8200 µF
-
Peak power output3.5 kW
-
Continuous power130 W
Description
The B&R 8V1022.001-2 SERVO DRIVER is a high-performance ACOPOS servo drive for precision motion control applications in industrial automation. 8V1022.001-2 delivers 1 kW of output power with a continuous current of 2.2 A effective and a peak current of 14 A effective, making 8V1022.001-2 suitable for controlling synchronous and asynchronous servo motors in packaging, robotics, material handling, and machine tool applications.
8V1022.001-2 accepts mains input voltages of 3× 400 V AC to 480 V AC ±10% or 3× 230 V AC ±10%, with a frequency range of 50/60 Hz ±4%. The installed load of 8V1022.001-2 is rated at a maximum of 3 kVA, with an inrush current of 4 A at 400 V AC and a switch-on interval requirement of greater than 10 seconds. The integrated line filter of 8V1022.001-2 complies with EN 61800-3 category C3, ensuring electromagnetic compatibility without requiring additional external filtering components. The power dissipation of 8V1022.001-2 at nominal power without braking resistor is approximately 120 W.
8V1022.001-2 accepts mains input voltages of 3× 400 V AC to 480 V AC ±10% or 3× 230 V AC ±10%, with a frequency range of 50/60 Hz ±4%. The installed load of 8V1022.001-2 is rated at a maximum of 3 kVA, with an inrush current of 4 A at 400 V AC and a switch-on interval requirement of greater than 10 seconds. The integrated line filter of 8V1022.001-2 complies with EN 61800-3 category C3, ensuring electromagnetic compatibility without requiring additional external filtering components. The power dissipation of 8V1022.001-2 at nominal power without braking resistor is approximately 120 W.
Information
Overview
Manuals
Application Notes
Product Applications
Insertion & Mechanical Mounting
Features:
- Modular mechanical design using plug-in modules
- Integrated line filte
- Integrated braking resistor
- All connections are made using plug-in connectors
- Integrated electronic restart inhibit
The drive features a modular mechanical design with 4 plug-in module slots for communication interfaces, encoder interfaces, and I/O expansion. All connections are made using plug-in connectors for tool-free installation and maintenance. The .001-2 suffix indicates partially-coated printed circuit boards, providing enhanced protection against environmental influences such as dust, moisture, and corrosive atmospheres compared to the non-coated .00-2 variant.
The 8V1022.001-2 B&R SERVO DRIVER may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
B&R 8V1022.001-2 SERVO DRIVER Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Integrated functions include an EMC line filter per EN 61800-3 Category C3, an internal braking resistor for dynamic braking energy dissipation, and an electronic safe restart interlock for safety-compliant machine restart prevention. The DC bus capacitance is 235 µF, and the 24 V control supply accepts ±25% tolerance with a maximum consumption of 2.5 A plus motor holding brake current.
The drive achieves IE2 energy efficiency classification with power dissipation ranging from 3.8% to 4.7% of continuous apparent power depending on operating point. Standby losses are 13.2 W. At nominal power without braking resistor, total power dissipation is approximately 120 W.
- Packaging: Drives smart-conveyor feeds, capping systems, and labeling axes
- Textile: Regulates tension controls, yarn feeders, and material winding mechanisms
- Pick-and-Place: Powers Cartesian arms and delta robots for electronics assembly
- Printing/Converting: Manages alignment, cutting, and registering axes in low-tonnage presses
- Material Handling: Operates high-speed diverters and gating on logistics sorting lines
- Medical: Controls fluid pumping arrays and laboratory sample sorting grids
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Mounting Orientation: The drive must be installed in a hanging vertical or vertical standing orientation. Horizontal mounting (face up) is only permissible with temperature derating.
Clearance: Ensure at least 100 mm of clearance above and below the drive to allow adequate airflow.
Module Slots: The drive features four expansion slots for fieldbus modules and I/O cards. Always ensure modules are securely seated and tightened before powering on.
Alternative Names
8V1022.001-Z
8V1022.00I-2
8V1022.0O1-2
8V1022.O01-2
8V102Z.001-2
8V10Z2.001-2
8V1O22.001-2
8VI022.001-2
BV1022.001-2
8V1022.001 2
8V1022.001 Z
8V1022.00I 2
8V1022.OO1 2
8V10ZZ.001 2
8V1022.0012
Technical notes
The DC bus connection of 8V1022.001-2 features a DC bus capacitance of 235 µF. The 24 V DC control power supply of 8V1022.001-2 accepts input voltages of 24 V DC ±25%, with an input capacitance of 8200 µF and a maximum current consumption of 2.5 A plus the current required for the motor holding brake. This dual-power architecture of 8V1022.001-2 ensures that control electronics remain powered even when the main AC supply is disconnected, maintaining position feedback and safety status information.
FAQs
-
What is the 8V1022.001-2 ?
+The B&R 8V1022.001-2 is a modular ACOPOS servo drive featuring 3 x 400 - 480 V input, 2.2 A current, and 1 kW power -
What does the 001-2 suffix signify?
+The .001 indicates that the drive features partially-coated printed circuit boards (PCBs), offering higher durability and resistance to environmental influences (like moisture or dust) compared to standard models. The -2 indicates hardware generation/variant. -
What are the specific power and current ratings?
+The drive operates on a 3-phase 400 to 480 V mains supply. It has a rated output of 2.2 A and delivers 1 kW of continuous power. -
What are the minimum clearance requirements for installation?
+For adequate air circulation, you must provide a vertical clearance of at least 80 mm above and below the servo drive. A horizontal spacing of at least 100 mm is recommended to prevent overheating.
