- 8BVI0055HWD0.000-1
In Stock
Ships by Friday, July 17
Fast Shipping Available
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 8BVI0055HWD0.000-1
-
Product Model8BVI0055HWD0.000-1
-
Product ParametersMULTI INVERTER ACUPUS
-
Tariff Code8537101190
-
Country of originAustria
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size5.2x15.6x35.5cm
-
ManufacturerB&R
-
Weight2.78 kg
-
B&R ID code0x20B5
-
Slots for plug-in modules2
-
Voltage750 VDC
-
Continuous power consumption11.19 kW
-
DC bus capacitance330 µF
-
VariantACOPOSmulti backplane
-
Input voltage25 VDC ±1.6%
-
Input capacitance23.5 µF
-
Continuous current per connection1.1 A
-
Max. internal resistance0.5 Ω
-
Extinction potentialApprox. 30 V
-
Max. extinction energy per switching operation1.5 Ws
-
Max. switching frequency0.5 Hz
Description
The B&R 8BVI0055HWD0.000-1 is an ACOPOSmulti inverter module (two-axis module) for servo motion control applications. The 8BVI0055HWD0.000-1 belongs to the B&R ACOPOSmulti motion control series and integrates two independent motor inverter channels in a compact wall-mounted module. It supports two motor connections with a continuous current of 7.6 Aeff per axis and a continuous power rating of 5.5 kW per motor connection, providing a compact solution for multi-axis automation systems.
The B&R 8BVI0055HWD0.000-1 uses an ACOPOSmulti backplane connection and supports a nominal DC bus voltage of 750 VDC. The module includes integrated functions such as motor holding brake connection, temperature sensor connection, overload protection, short-circuit protection, ground fault protection, and functional safety support. The unit is designed for wall mounting with natural heat dissipation through the mounting structure.
The B&R 8BVI0055HWD0.000-1 uses an ACOPOSmulti backplane connection and supports a nominal DC bus voltage of 750 VDC. The module includes integrated functions such as motor holding brake connection, temperature sensor connection, overload protection, short-circuit protection, ground fault protection, and functional safety support. The unit is designed for wall mounting with natural heat dissipation through the mounting structure.
Alternative Names
8BVI0055HWD0.000-I
8BVI0055HWD0.OOO-1
8BVI0055HWDO.000-1
8BVIOO55HWD0.000-1
8BV10055HWD0.000-1
88VI0055HWD0.000-1
BBVI0055HWD0.000-1
8BVI0055HWD0.000 1
8BVI0055HWD0-000 1
Information
Overview
Manuals
Application Notes
Product Applications
Mechanical Insertion
Features:
- Integrated uncontrolled standstill and safe stop
- Integrated connection for motor holding brake and temperature sensor
- 2 slots for ACOPOSmulti plug-in modules
- Two fully independent power inverters in one inverter module contained in 2-axis modules
The 8BVI0055HWD0.000-1 features integrated uncontrolled standstill and safe stop functionality, ensuring safe operation and compliance with applicable safety integrity requirements. Achievable safety classifications for the 8BVI0055HWD0.000-1 are documented in the user's manual under the safety technology section. The 8BVI0055HWD0.000-1 also provides integrated connections for motor holding brake and temperature sensor, simplifying motor wiring and enhancing overall system integration.
The 8BVI0055HWD0.000-1 B&R MULTI INVERTER ACUPUS may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
B&R 8BVI0055HWD0.000-1 MULTI INVERTER ACUPUS Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The ACOPOSmulti system utilizes POWERLINK real-time Ethernet for communication between drives, controllers, and I/O systems, achieving a control cycle time of 50 µs for current, speed, and position control loops. Basic motion functions can be switched within 400 µs, enabling seamless transitions between point-to-point positioning, electronic gearing, electronic cams, flying saws, CNC, and other motion profiles.
Environmental ratings include an operating temperature range of 5°C to +40°C (up to +55°C with derating), 5% to 85% non-condensing relative humidity, and installation altitudes up to 500 m (up to 4,000 m with derating). The module carries IP20 protection and is rated for Pollution Degree 2 and Overvoltage Category III.
- Packaging: Controls VFFS, flow wrappers, cartoning, and labeling systems
- Material Handling/Robotics: Drives delta robots, articulated arms, gantries, and AGVs with tight synchronization
- Plastics: Manages injection molding, extrusion pullers, and blow molding with temperature feedback
- Printing/Paper: Used in web handling, cutters, and register controls for ultra-fast response
- Textile: Powers spinning, weaving, and knitting with constant tension and high positioning accuracy
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Module Alignment: Align the rear of the 8BVI0055HWD0.000-1 with the mounting rail and the bus module on the backplane.
Engaging the Backplane: Press the module straight back into the mounting frame so that the DC bus, 24 VDC supply, and communication connections on the rear fully engage.
Securing: Once fully seated, secure the module to the cabinet frame using the integrated mounting screws at the top and bottom of the unit to ensure a robust ground and mechanical stability.
Technical notes
The 8BVI0055HWD0.000-1 operates with a DC bus voltage of 750V and a nominal switching frequency of 5kHz. B&R recommends operating the 8BVI0055HWD0.000-1 at its nominal switching frequency, as operating at higher switching frequencies reduces the continuous current and increases CPU utilization. When using 2-axis modules like the 8BVI0055HWD0.000-1, the increased CPU utilization reduces the functionality of the drive, and if this is not taken into account, the computing time can be exceeded in extreme cases.
FAQs
-
What is the 8BVI0055HWD0.000-1 ?
+The B&R 8BVI0055HWD0.000-1 is a dual-axis inverter module from the B&R ACOPOSmulti servo drive family. -
What accessories are required to install this module?
+To safely wire and mount the drive, you will need the matching terminal block sets, typically the 8BZVI0055D0.000-1 screw clamp set, which includes specific terminal blocks like the 8TB2112, 8TB2108, and 8TB2104. -
What is the life cycle status of ACOPOSmulti drives?
+B&R assigned a "Classic" status to older ACOPOS generations. While many specific ACOPOSmulti parts (like the 8BVI0055HWD0.000-1) are still available or kept in stock, you should consult B&R's official life cycle information for long-term obsolescence and replacement planning. -
Why does the manual recommend a line contactor for the power supply?
+B&R advises connecting the drive system to the mains via an external line contactor to minimize contact chatter and prevent premature component wear or unexpected tripping of residual current protection devices.
