PRODUCT DESCRIPTION
Armored imperial proximity probe
Bently Nevada 330102-08-15-10-02-00 carries the 330102 designation for an armored 3300 XL 8 mm proximity probe. The unambiguous option segments indicate a one-meter total probe length and standard cable with a miniature coaxial ClickLoc connector, supplied without a connector protector.
Within a correctly matched transducer system, this probe family supports non-contact shaft vibration, position and rotational reference measurements. The mechanical length combination in this recorded order remains unconfirmed, so installation dimensions are withheld until the nameplate and applicable manufacturer configuration are checked.
Within a correctly matched transducer system, this probe family supports non-contact shaft vibration, position and rotational reference measurements. The mechanical length combination in this recorded order remains unconfirmed, so installation dimensions are withheld until the nameplate and applicable manufacturer configuration are checked.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Where 330102-08-15-10-02-00 Fits Across Industrial Application Areas
Industrial uses span production and utility equipment, subject to verified product compatibility, installation requirements and operating conditions.
-
01 · MINING & MINERALS
Mining Operations and Mineral Processing
Ore crushers and grinding mills at mineral processing plants.Process pumps and conveyors serving mineral processing plant operations. -
02 · METALS & MINING
Steel Production and Metallurgical Plant Utility Equipment
Rolling mills and extraction fans in steel production plants.Coke oven compressors and combustion blowers serving steel plants. -
03 · PULP & PAPER
Pulp Manufacturing and Paper Production
Pulp refiners and process pumps in integrated pulp mills.Paper machine press rolls and winders in papermaking facilities.
Technical specifications for 330102-08-15-10-02-00
-
Product Model330102-08-15-10-02-00
-
Product ParametersArmored imperial proximity probe
-
In stock5 units
-
ManufacturerBently Nevada
-
Mounting thread3/8-24 UNF-2A
-
Lead protectionFlexible stainless steel armor with FEP outer jacket
-
Nominal total probe length option1.0 m
-
Connector and cable option02: miniature coaxial ClickLoc, standard cable, no protector
-
Agency approval option00: not required
-
Probe tip diameter8.0 mm
-
Probe tip materialPolyphenylene sulfide (PPS)
-
Probe case materialAISI 303 or 304 stainless steel
-
Nominal probe DC resistance7.59 ohms +/-0.50 for the 1 m configuration; center to outer conductor
-
Standard probe temperature range-52 to +177 degrees C; operating and storage
View all additional
Alternative Names
330102 08 15 10 02 00
330102-08-15-10-02-00 armored proximity probe
330102-08-15-10-02-00 3300 XL 8 mm probe
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
ARMORED IMPERIAL PROXIMITY PROBE
Verify the recorded probe configuration
The 330102 family is the armored imperial-thread version of the 3300 XL 8 mm proximity probe. Read the unchanged complete order against the delivered label. The unresolved mechanical length combination is not presented here as a verified installation dimension.
The confirmed electrical-length option is one meter. Match the probe, any extension cable and Proximitor Sensor to the documented total system length. A one-meter system does not use an extension cable; a different configured system must be checked as a complete chain.
Standard cable option 02 uses a miniature coaxial ClickLoc connector without a protector. The manufacturer recommends connector protection for environmental resistance. Correct lead routing, target clearance and mechanical fit remain necessary; armor does not validate the disputed mounting dimensions.
Features:
- Confirm the actual mechanical configuration
- Match the complete electrical length
- Protect and support cable connections
The 330102-08-15-10-02-00 armored proximity probe requires verified mechanical fit before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Do not treat a similar 330102 code as an unconditional substitute for 330102-08-15-10-02-00. Confirm the recorded model against its physical label and manufacturer configuration, then compare mounting dimensions, electrical length, cable construction and connection protection.
The manufacturer describes interchangeability between specified XL and non-XL 3300 five- and eight-millimeter components. Mixed systems are limited to the non-XL performance specification. This family-level guidance does not establish the mechanical suitability of an unconfirmed order configuration.
No exact-order hardware revision, discontinuation date or designated successor is confirmed by the reviewed material. Datasheet revision AM is a publication revision, not a hardware revision. No replacement model or lifecycle date is inferred for this record.
Features:
- Keep the complete recorded model
- Verify dimensions before substitution
- Require official replacement evidence
The 330102-08-15-10-02-00 armored proximity probe requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: Amikong-hosted reference documents cover verified probe-family information and readable order options. The mechanical length combination remains unconfirmed; these PDFs do not validate exact installation dimensions. Consult the controlled manufacturer instructions before use; additional documents are supplied only when listed in the quotation.Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the 330102-08-15-10-02-00 armored proximity probe must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size1.5x1.3x113cm
-
Shipping weight0.1 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference9031809090
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 330102-08-15-10-02-00
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
What can be identified from 330102-08-15-10-02-00?
The family designation identifies an armored 3300 XL 8 mm imperial-thread probe. The last three option groups identify one-meter length, standard ClickLoc cable without a protector and no requested agency approval. The mechanical length combination remains unconfirmed and must be checked against the delivered label. -
What does this probe measure in a complete system?
The compatible 3300 XL 8 mm transducer system measures static distance and dynamic movement between the tip and a conductive target. The probe is the sensing element; the Proximitor provides signal conditioning and the distance-proportional voltage output. -
Does a one-meter configuration require an extension cable?
The manufacturer specifies that a one-meter system does not use an extension cable. For any other documented total system length, match the probe, extension cable and Proximitor as a complete chain rather than judging compatibility by connector fit alone. -
Which machinery monitoring applications does the series support?
Official series documentation lists shaft vibration and position measurements on fluid-film bearing machinery, plus Keyphasor reference and speed measurements. Tachometer or overspeed applications require the manufacturer's dedicated guidance and appropriate receiving equipment; they are not established by the probe code alone. -
Can the disputed mechanical dimensions be used for installation?
No verified mechanical length values are published for this recorded combination. Confirm the physical label and applicable manufacturer configuration before machining a mount or ordering a replacement. The complete model remains unchanged; no alternative length code has been substituted. -
Does option 02 include a connector protector or FluidLoc cable?
No. The ordering table defines option 02 as a miniature coaxial ClickLoc connector with standard cable, without a connector protector. FluidLoc options are identified separately. The manufacturer recommends connector protectors to improve environmental protection. -
What resistance check applies to the one-meter probe option?
The manufacturer's nominal probe DC resistance is 7.59 ohms with a tolerance of plus or minus 0.50 ohm, measured from the center conductor to the outer conductor. This is a probe reference value, not the extension cable resistance or a complete system calibration result. -
Can this standard probe be treated as an extended-temperature version?
No. The standard probe's published operating and storage range is -52 to +177 degrees C. Extended-temperature probes are specified separately. The manufacturer also warns that exposure below -34 degrees C may cause premature pressure-seal failure; temperature range alone does not prove containment suitability.
